Preparation before Use
2-30
Specifying Paper Size and Media (Cassette Setting)
The default paper size setting for cassettes 1 and 2, for the multi purpose tray and for the optional paper feeder (cassettes
3 to 7) is [Auto], and the default media type setting is [Plain].
To fix the type of paper to be used in cassettes, specify the paper size and media type setting. (Refer to Specifying Paper
Size and Media Type for the Cassettes on page 2-30.)
To fix the type of paper to be used in multi purpose tray, specify the paper size setting. (Refer to Specifying Paper Size and
Media Type for the Multi Purpose Tray (MP Tray Setting) on page 2-33.)
Specifying Paper Size and Media Type for the Cassettes
To fix the type of paper to be used in cassettes 1 or 2 or the optional paper feeders (cassettes 3 to 7), specify the paper
size. Also, if you use a media type other than plain paper, specify the media type setting. To change to a media type other
than Plain, refer to Media Type Set. (Paper type settings) on page 6-23.
Selection Item Selectable Size/Type
Standard Sizes *
* Only A4, Letter, and B5 can be specified when the optional Large Capacity Feeder (1,500-sheet x 2) and the
optional Large Capacity Side Feeder (500, 1,500-sheet x 2) are used.
Select from the standard sizes. Selectable paper sizes are as follows.
Letter-R, Letter, Legal, A4-R, A4, B5-R, B5, A3, B4, Ledger, A5, Oficio II, 216×340 mm,
12×18", 8K, 16K-R, 16K, Statement, Folio
Media Type Plain, Preprinted**, Bond, Recycled, Vellum**, Rough**, Letterhead**, Color**,
Prepunched, Thick**, High Quality and Custom 1~8**
** This cannot be selected when the cassette paper weight is Heavy 5 or Extra heavy. Select at the Multi Purpose
Tray.
