2-33
Preparation before Use
Specifying Paper Size and Media Type for the Multi Purpose Tray (MP Tray Setting)
To fix the type of paper to be used in the multi purpose tray, specify the paper size. When using other than a plain paper,
specify the media type.
Item Description
Paper Size Select from the standard sizes. Selectable paper sizes are as follows.
Envelope Monarch, Envelope #10 (Commercial #10), Envelope DL,
Envelope C5, Executive, Letter-R, Letter, Legal, A4-R, A4, B5-R, B5, A3, B4,
Ledger, A5, A6, B6, Envelope #9 (Commercial #9),
Envelope #6 (Commercial #6 3/4), ISO B5, Custom*, Envelope C4, Hagaki,
Oufuku hagaki, Oficio II, 216×340 mm, 12×18", 8K, 16K-R, 16K, Statement,
Folio, Youkei 2, Youkei 4
* Refer to Registering a page size on page 2-36 for selecting Custom for Custom Paper Size.
Media Type Selectable media types are as follows.
Plain, Transparency, Preprinted, Labels, Bond, Recycled, Vellum, Rough,
Letterhead, Color, Prepunched, Envelope, Cardstock, Coated, Thick,
High Quality and Custom 1~8**
** Refer to Media Type Set. (Paper type settings) on page 6-23 for selecting Custom 1- 8 from Media Type.
Note To change to a media type other than Plain, refer to Media Type Set. (Paper type settings) on page 6-23.
