Installation Guide

HARDWARE USED
M6 Nut x 1
II
HARDWARE USED
x 4
4.
5
CC
ASSEMBLY INSTRUCTIONS
3. Insert 1 M6x45 bolt (EE) into the hole on the neck bearing found on the motor (D) and into the
top of the upper connecting pole (E), then secure them together using a bushing (DD) and M6
nut (CC). Insert 1 M8x45 bolt (HH) through the hole in the neck bearing and into the top of the
upper connecting pole, then secure them using 1 bushing (GG) and 1 M8 nut (FF).
φ18 Bowl Washer
JJ
φ5 Spring Washer
x 4
KK
M5×3.5 Nut
x 4
DD
HH
EE
FF
GG
φ15 Bushing x 1
M6x45 Bolt x 1
DD EE
M8 Nut x1
FF
φ12 Bushing
x 1
GG
M8x45 Bolt x 1
HH
CC
3
Attach the rear guard (C) to the screws found on the motor (D), then secure them together using
4 bowl washers (II), four spring washers (JJ) and four M5x3.5 nuts (KK).
4
BB
C
II
JJ
KK
