Specifications

UVP ... [phone] | [phone] | [phone] | UVP.com
HM-4000 Multidizer
TM
Hybridization Oven Accessories
Bottle, small, 35 x 150mm
Bottle, large, 35 x 300mm
07-0194-01
07-0194-02
Rocker Tray (HM-4000, HL-2000, HB-1000)
12.5W x 10D in. (318 x 254mm)
Tray moves at 7 cycles/min and up to 14
cycles/min on the highest speed
98-0067-03
Orbital Tray (HM-4000, HL-2000, HB-1000)
Dimensions: 10.3W x 8D in. (318 x 254mm)
Motion: 30 rpm at 2
o
angle
98-0067-04
Carousel, Acrylic (HM-4000)
Rests on rollers, rotate: 10 - 20 rpm
Carousel holds up to eight 35 x 150mm; four
35 x 300mm bottles or eight 50ml conicals
76-0089-01
Carousel, Metal fits ten 50ml conicals, replaces
rotary wheel (HB-1000, HL-2000, HM-4000)
76-0075-01
Carousel Kit for oversized bottles 76-0066-02
Lower chamber:
Variable speed control in lower chamber and other features
are the same as the HB-1000
Multiple bottle sizes and offset bottle positioning
Upper chamber:
Uses a roller action to operate the shaker tray (included)
or optional acrylic carousel or orbital tray
Shaker tray is designed for placement of flasks or other
containers
Ordering Information
HM-4000 Hybridizer
Hybridization Oven
95-0340-01 (115V)
95-0340-02 (230V)
Upper Chamber
Temperature Range:
Heating Element:
Shaker Tray Dimension:
Shaker Tray Speed:
Carousel Rotation:
Ambient +10
o
C to 80
o
C (stability/
uniformity same as HB-1000)
500 Watts
10W x 6D in. (254 x 152mm)
54 - 106 cycles/min.
12 - 20 rpm
Lower Chamber
Temperature Range:
Heating Element:
Rotary Wheel Variable Speed:
Bottle Capacity:
Bottle Included:
Ambient +10
o
C to 99.9
o
C (stability/
uniformity same as HB-1000)
1250 Watts
10 - 15 rpm
Twenty 35 x 150mm
Ten 35 x 300mm
One 35 x 300mm with HM-4000
HM-4000 Multidizer Hybridization Oven is designed with two
separate chambers offering several motion functions: shaking,
orbital rocking and rotating all in one unit. Two chambers operate
independently and allow hybridization and blotting procedures
requiring different containers, motions or temperature settings.
HM-4000 Multidizer Two compartments operate
independently with shake, rock, roll and rotate motions
HM-4000 Dimensions:
17.5W x 28.5H x 15D in. (445 x 725 x 381mm)
The HB-500 Minidizer Hybridization Oven is designed as a
personal desktop unit ideal for use in laboratories with low use
and space requirements. LCD displays current temperature.
Rotation speed set at 12 rpm
Easy-clean stainless steel interior
3/8” thick b-blocking acrylic cover
Cover swings open for easy access to the carousel
HB-500 Minidizer
Compact and portable,
this unit is designed for
low throughput use.
HB-500 Dimensions:
9H x 13W x 8D in.
(229 x 330 x 203mm)
Ordering Information
HB-500 Minidizer
Hybridization Oven
95-0330-01 (115V)
95-0330-02 (230V)
Temperature Range:
Temperature Accuracy:
Temperature Uniformity:
Heating Element:
Speed:
Bottle Capacity:
Ambient +10
o
C to 80
o
C
+0.5°C at 78°C
+
0.1°C at 68°C
500 Watts
12 rpm
Four 35 x 150 mm or
Four 50 ml or Eight 15 ml
HB-500 Minidizer
TM
Hybridization Ovens
HL-2000 HybriLinker
TM
Hybridization Oven combines an HB-1000
Hybridization oven and UV Crosslinker (254nm UV) in one unit.
The Hybridization Oven and Crosslinker operate independently.
Hybridization ovens are replacing hybridization bags and
water baths for procedures involved in Southern, Northern
and in situ hybridization. UVP’s hybridization ovens
provide accurate temperature and rotation speed controls
plus variable bottle sizes and offset bottle positioning. The
dynamic mixing capability is ideal for
creating the optimum conditions
needed for cDNA library screenings,
primer synthesis and nucleic acid
hybridization. The interior stainless
steel construction is easy to clean.
Lower chamber - UV crosslinker (see additional details p. 22):
Shortwave 254nm, 8-watt, ultraviolet tubes
Preset and manual controls for ultraviolet or time exposures
Microprocessor measures and controls UV output, ensuring
maximum energy efficiency
Large LCD display continuously displays time or energy
settings
Window on the door allows viewing of the process yet blocks
UV radiation
HL-2000 HybriLinker
Hybridization oven
and UV Crosslinker in
one unit. The oven
has the same features
as the HB-1000.
The HB-1000 Hybridizer Hybridization Oven provides
uniform temperature and rotation controls for thorough
mixing of materials.
Variable rotary wheel speed control (10 to 15 rpm)
enables consistent saturation of samples
Microprocessor accurately controls temperature
Large LCD displays the current temperature inside
the chamber
Protective trays removable to allow easy cleanup
of spilled media
RPM knob adjusts speed control of the rotary wheel
Carousel holds twenty 35 x 150mm bottles, ten 35 x
300mm bottles or combination
Offset bottle positioning for thorough mixing
Carousel is removeable for use of the optional rocker
tray (stainless steel 12.5W x 10D in.)
Ordering Information
HL-2000 HybriLinker
Hybridization Oven/Crosslinker
Upper Chamber Oven:
Heating Element:
Rotary Wheel Variable Speed:
Bottle Included:
Bottle Capacity:
Lower Chamber Crosslinker:
UV Light Source:
95-0031-01 (115V)
95-0031-02 (230V)
1250 Watts
10 to 15 rpm
One 35 x 300mm
Twenty 35 x 150mm
Ten 35 x 300mm
254nm UV
HL-2000 Dimensions: 17.5W x 24H x 15D in. (445 x 610 x 381mm)
Variable speed
control
Large LCD display
Stainless steel
internal design
Precision
heated
hybridization
ovens
HB-1000 Hybridizer
HL-2000 HybriLinker
TM
HB-1000 Hybridizer
hybridization oven
features fast heat-up
capability. Units are
stackable for
maximizing lab space.
Hybridization Ovens
Ordering Information
HB-1000 Hybridizer
Hybridization Oven
Heating Element:
Rotary Wheel Variable Speed:
Bottle Included:
Bottle Capacity:
95-0030-01 (115V)
95-0030-02 (230V)
1250 Watts
10 to 15 rpm
One 35 x 300mm
Twenty 35 x 150mm
Ten 35 x 300mm
HB-1000 Dimensions:
17.5W x 16H x 15D in.
(445 x 406 x 381mm)
Hybridization OvensHybridization Ovens
Hybridization Ovens
Orbital Motional Tray (optional) plugs into
the hybridization oven for use with flasks and
other vessels. External stand-alone tray avail-
able; contact UVP for ordering information.
See next page for accessories available with the HB-1000 and HL-2000 hybridization ovens.
Upper chamber -
hybridization oven
(same features as
HB-1000 including):
20
21
Temperature Settings: HB-1000 and HL-2000 Ovens
Temperature: Ambient +10°C to 99.9°C
Temperature Stability: Inside Oven: +
0.3°C to 68°C
Inside Bottles: +0.1°C to 68°C
Temperature Uniformity: Inside Oven: +0.1°C to 68°C
Inside Bottles: +0.1°C to 68°C
