Mineralight® 225D Display Lamps provide hours of UV
illumination for fluorescence, sterilization or inspection
applications with 25-watt UV
The lamp is manufactured with adjustable handles and
mounting brackets for hanging the lamp
225D Lamp Dimensions:
18.5L x 4.5W x 3.5H in. (470 x 114 x 89mm); Weight: 10 lb (4.6 kg)
Ordering Information
UVL-225D
365nm UV, 25-watt
Replacement Tube
95-0190-01 (115V)
95-0190-02 (230V)
34-0060-01
UVS-225D
254nm UV, 25-watt
Replacement Tube
95-0191-01 (115V)
95-0191-02 (230V)
34-0073-01
UVLS-225D
365nm/254nm UV, 25-watt
Replacement Tube 365nm
Replacement Tube 254nm
95-0192-01 (115V)
95-0192-02 (230V)
34-0060-01
34-0073-01
UVM-225D
302nm UV, 25-watt
Replacement Tube
95-0189-01 (115V)
95-0189-02 (230V)
34-0072-01
UVGD-68
254nm UV grid
Replacement grid
95-0026-07 (115V)
95-0026-08 (230V)
77-0001-04
225D 25-Watt Mineralight Display Lamps can be mounted
by brackets for overhead use.
UVGD-68 quartz shortwave UV grid lamp is rated at
20,000 hours of use with unlimited on/off capability
The UVG Long-Life Filter is included
Excellent for large gem and mineral displays
UVGD-68 Dimensions:
18.5L x 4.75W x 5H in. (470 x 114 x 89mm) Weight: 10 lb (4.6 kg)
UVGD-68 uses a high intensity, shortwave (254nm) quartz
grid lamp.
Blak-Ray
® XX-Series bench lamps - longwave (365nm),
BLB (black light) or midrange (302nm) UV and Mineralight
®
(shortwave 254nm) bench lamps are available in a selection
of 15, 20 and 40-watt housings.
Durable aluminum housings are painted with a scratch
resistant powder finish
Lamp uses include sterilization, NDT, fluorescence
display, as well as benchtop inspection stations
225D Mineralight Lamps
UV Display and Bench Lamps
10
XX-Series UV Bench Lamps
UVGD Mineralight Lamp
XX-15S Lamp shown with brackets for downward
illumination of a work area.
UV blocking eyewear is critical for anyone using UV.
See page 7 for UV blocking eyewear.
31
Ultraviolet Lamps
Basic Imaging Systems
Ultraviolet Lamps
High resolution digital color camera captures
brilliant color images
Exclusive software controls the camera and
enables image capture, enhancement, annotation
and archiving
Quickly see live preview of gel images on the
computer monitor
Select a large format High Performance UV
Transilluminator; for gels up to 25x30cm, select
the DigiDoc-It with the TFM-30V Transilluminator
** For current camera specifications go to UVP.com or
contact UVP.
DigiDoc-It System
with the optional
drawer (right) and
Benchtop UV
Transilluminator
(ordered separately,
see pages 23-24 for
transilluminators)
DigiDoc-It
Ò
Imaging Systems
Ordering Information
DigiDoc-It Imaging System with
TFM-20V Transilluminator (20x20cm)
97-0243-01 (100-115V)
97-0243-02 (230V)
DigiDoc-It Imaging System with
TFM-26V Transilluminator (21x26cm)
97-0244-01 (100-115V)
97-0244-02 (230V)
DigiDoc-It Imaging System with
TFM-30V Transilluminator (25x30cm)
97-0246-01 (100-115V)
97-0246-02 (230V)
DigiDoc-It Imaging System
(No Transilluminator)
97-0105-01 (100-115V)
97-0105-06 (230V)
Drawer (order Benchtop
Transilluminator separately)
98-0068-01
The DigiDoc-It System is economically designed for image capture
and documentation of gels and plates. UVP’s exclusive software
loads on the user’s PC, controls the camera functions and offers
many image enhancement and reporting features.
Lightweight molded
hood enclosure with
handles
DigiCam camera
mounts under the
protective cover
Viewport for
seeing the
fluorescent gels
Hood sits on the
Transilluminator
Digi Cam Camera Specifications
CCD Imager:
High resolution megapixel
camera**
Interface: USB connector
Power Supply: AC Adapter Kit
High Performance UV Transilluminators
feature 25 watt, 302nm UV
Systems include: Digi camera, hood, EtBr filter; capture/control software
(Windows XP or higher), with or without a UV transilluminator
Drawer Dimensions:
19.1W x 7.7H x 15.1D
(485 x 196 x 384mm)
Hood Dimensions:
17.75W x 16.6 x 12D in. (451 x 422 x 305mm)
Doc-ItLS Software is designed for analysis of 1D gels. The analysis
module compliments the capture software package included with the
DigiDoc-It, MultiDoc-It and ChromaDoc-It systems.
Generate easy to interpret quantitative data of lanes and bands
Measure angles, areas and lengths with the Measurement Tool
Detect straight, curved or slanted lanes and bands
Create histograms for detailed visual analysis
In addition to analysis functions, users can set preferences and
generate reports. The software supports 21 CFR Part 11 compliance.
Doc-It
Ò
LS Analysis Software
DigiDoc-It
Applications*
Basic Imaging Systems
Access door
XX-Series Lamps are available in 15-watt, 20-watts and
40-watt models.
Ordering Information
1D Analysis Software (compatible with
Windows XP or higher)
97-0185-02
