Specifications

UVP ... [phone] | [phone] | [phone] | UVP.com
Selection of each wavelength is by an easy turn of the dial
located on one end of the housing
The uniquely designed reflectors mounted behind each tube
provide maximum UV for fluorescence applications
Lightweight plastic and ergonomically-designed housing for
handheld or stationary use
This innovative 3UV lamp (patented) houses three UV wavelengths
in one lamp.
Lamp Dimensions:
3UV-34: 9.5L x 3W x 4.5D in. (241 x76 x114mm)
3UV-36: 12.5L x 3W x 4.5D in. (318 x76 x114mm)
3UV-38: 15.5L x 3W x 4.5D in. (394 x76 x114mm)
3UV model houses three UV wavelengths (254nm shortwave,
302nm midrange and 365nm longwave) in one unit, reducing
the need to purchase multiple lamps
Easily switch among the three UV wavelengths as required for
your application
EL Series UV Lamps are lightweight and easy to
handle (left to right: UVLMS-38, UVLS-28, UVL-14).
2UV
TM
models include two different UV wavelengths in one lamp.
Refer to ordering information for selection of wavelengths.
3UV and 2UV Lamp Ordering Information
UVLMS-38 8-watt, 3UV
365nm/302nm/254nm
95-0252-01 (115V)
95-0252-02 (230V)
UVLM-28 8-watt, 2UV
365nm/302nm
95-0251-01 (115V)
95-0251-02 (230V)
UVLS-28 8-watt, 2UV
365nm/254nm
95-0201-01 (115V)
95-0201-02 (230V)
UVLM-26 6-watt, 2UV
365nm/302nm
95-0278-01 (115V)
95-0278-02 (230V)
UVLS-26 6-watt, 2UV
365nm/254nm
95-0279-01 (115V)
95-0279-02 (230V)
UVLS-24 4-watt, 2UV
365nm/254nm
95-0271-01 (115V)
95-0271-02 (230V)
Replacement Tubes
Tube, 8-watt, 365nm
Tube, 8-watt, 302nm
Tube, 8-watt, 254nm
Tube, 6-watt, 365nm
Tube, 6-watt, 302nm
Tube, 6-watt, 254nm
Tube, 4-watt, 365nm
Tube, 4-watt, 254nm
34-0006-01
34-0042-01
34-0007-01
34-0034-01
34-0044-01
34-0013-01
34-0005-01
34-0003-01
Lamp Dimensions:
4-Watt: 9.8L x 3.8W x 2.5D in. (249 x 97 x 64mm)
6-Watt: 12L x 3.8W x 2.5D in. (305 x 97 x 64mm)
8-Watt: 14.8L x 3.8W x 2.5D in. (376 x 97 x 64mm)
Ordering Information
3UV-34 4-watt
254nm/302nm/365nm UV
95-0341-01 (115V)
95-0341-02 (230V)
3UV-36 6-watt
254nm/302nm/365nm UV
95-0342-01 (115V)
95-0342-02 (230V)
3UV-38 8-watt
254nm/302nm/365nm UV
95-0343-01 (115V)
95-0343-02 (230V)
The 3UV
TM
EL Lamp model is available with 8-watt tubes.
EL Series Lamps are fabricated of extruded metal with a scratch-
resistant powder paint finish. EL Series UV lamps are available with
4, 6, or 8-watts and a selection of UV wavelengths and white light
combinations. A lamp can be placed in the J-138 stand (see p. 5)
for hands-free use.
For replacement tubes: see bottom of page.
3UV Lamps hold
longwave,
shortwave and
midrange UV in
one lamp (8-watt
model pictured).
EL Series Lamps
UV is used in many applications. Refer to the catalog
back cover for examples of uses.
37
4
Protective eyewear is
essential for anyone
using UV equipment.
See page 7 for UV
blocking eyewear.
Ultraviolet Lamps Advanced Imaging Systems
BioSpectrum Imaging Systems
Built-in epi illumination sources: 365nm UV,
460-470nm blue and white light
Motorized five-position emission filter
wheel with EtBr, SYBR Green and SYBR
Gold filters included; additional filters
are available
LED white light tray supplies uniform light
for colonies, Coomassie Blue and Silver
stained gels; place the tray in the side
pocket when not in use
VisionWorks
®
LS software allows image
acquisition, enhancement, documentation,
printing, publishing and analysis
BioSpectrum Darkroom
is light tight and automated
with all functions controlled
via VisionWorksLS software
Motorized platform tray
height is adjustable (manual
lift platform also available)
Configure the system with a high
specification 20” touch screen
computer/monitor (order separately)
Unique viewer window
allows UV-safe viewing
without opening the door
Access port for connecting
the external BioLite high
intensity multispectral light
source (optional)
Scientific Grade CCD Camera mounted
in the darkroom
Select from single or multiple
UV wavelength Benchtop
Transilluminators
The BioSpectrum System with its advanced, automated capabilities enables a
wide range of imaging applications. Select from cooled or non-cooled cameras
configured for specific applications and budget requirements.
* Applications listed may require additional accessories.
Systems includes: Camera/lens, darkroom, 3 emission filters, epi white/UV/blue, UV
transilluminator, LED white light plate, VisionWorksLS Software. System configurations
may vary by country. Contact UVP for details.
BioSpectrum 810 with class-leading image resolution, cooled CCD camera
(MegaCam 810) with 8.1 MP resolution. Camera enables shorter exposure
times in chemiluminescence, fluorescence and colorimetric applications.
BioSpectrum 610 deeply cooled CCD camera (OptiChemi 610) with 3.2 MP
resolution and extended exposure times for IR/NIR, multiplex and
chemiluminescence applications.
BioSpectrum 510 with cooled CCD camera (BioChemi 510) with 2.1 MP
or 4.1 MP resolution** delivers affordable, high sensitivity for chemilumines-
cence, fluorescence and colorimetric applications.
BioSpectrum 310 with a high resolution CCD camera (GelCam 310)
with 2.0 MP resolution for fluorescence and colorimetric research.
System Selection
System Specifications:
Cameras/Lens: See specifications p. 39
Darkroom: Light tight
Motorized or manual platform
Wide access door
Sliding transilluminator tray
Gel viewing window
Chemi tray (chemi capable
systems only)
Epi Light: White Light, 365nm, 460-470nm
Transillumination: Single or Multiple UV
Filter sizes: 21x26 or 25x26cm
Emission Filters: Three included
Five position filter wheel
Other filters available
Software: VisionWorksLS capture/analysis
BioSpectrum Applications*
Advanced Imaging Systems
Ultraviolet Lamps
®
Dimensions: 17.5W x 17.5D x 32H in.
(44.5 x 44.5 x 81.3cm)
3UV and 2UV EL Series Lamps
3UV
TM
Multi-Wavelength UV Lamps
** 2.1 MP with zoom lens, 4.1 MP with fixed lens
