Installation and User Guide VADDIO™ HOT-SHOT™ PRESET CAMERA CONTROLLER Automated Preset Controller for the Vaddio PTZ Cameras, Select Hardware Codecs & Control Systems Part Numbers: 999-1036-000 North America 999-1036-001 International © 2012 Vaddio - All Rights Reserved. Hot Shot Preset Camera Controller Installation and User Guide.
Hot Shot Preset Camera Controller Inside Front Cover - Blank Hot Shot Preset Camera Controller - Installation and User Guide - Document Number 342-0124 Rev D Page 2 of 16
Hot Shot Preset Camera Controller Contents Overview: ................................................................................................................................................................... 4 Intended Use: ......................................................................................................................................................... 4 Save These Instructions: .................................................................................................
Hot Shot Preset Camera Controller Overview: The Hot-Shot Preset Camera Controller is part of the Vaddio Automated Content Presentation System product line and is truly as simple as it is elegant.
Hot Shot Preset Camera Controller Unpacking: Carefully remove all of the parts from the shipping box. Unpack and identify the following parts for the Hot-Shot Preset Camera Controller: One (1) Hot-Shot Preset Camera Controller with three (3) 14-position Phoenix type spring cage connectors One (1) 12 VDC, 1.0 Amp PowerRite™ Power Supply with AC Cord Set Documentation (User Manual 342-0124) Hot-Shot Key Features: Each Hot-Shot can receive up to 36 physical trigger inputs from any trigger device.
Hot Shot Preset Camera Controller Diagram: Basic Connectivity featuring the Hot-Shot and C60 Codec Vaddio MicVIEW Mic AutoVIEW IR Sensor Push to Talk Student Mics StepVIEW Mat Instructor Location Preset Triggers HOT-SHOT Preset Camera Controller Audio Audio RS-232 Preset #’s RGBHV PC C60 Codec LAN DVI/HDMI Monitor 1 DVI/HDMI Video RS-232 Monitor 2 Daisy Chain RS-232 Student Camera HD Monitors - Simulated Video Feed PrecisionHD Cameras Instructor Camera Diagram - Advanced Connectivity: Three
Hot Shot Preset Camera Controller Diagram - New Application - Single Camera System: Hot-Shot and Vaddio HD-USB PTZ Camera, AutoVIEW IR Sensor, StepVIEW Mats StepVIEW Mats Teacher’s Locations Front and White Board AutoVIEW IR Sensors Other Room Locations Preset Triggers Learjet not included HD-USB PTZ Camera HOT-SHOT Preset Camera Controller 998-1001-232 Control Adapter PC with USB 2.0 Recording Application RS-232 Camera Presets USB.2.
Hot Shot Preset Camera Controller Table - Dip Switch Assignments: The following table identifies the dip switch settings in detail. Set these switches according to the application requirements of the installation.
Hot Shot Preset Camera Controller INSTALLATION Step-by-Step Example with Codec: This example is a room system using a Cisco C60 codec with two (2) cameras (student camera located in front and the instructor camera in the rear of the room). There are 18 students and 9 tables with two students to a table and each table has a push-to-talk microphone (9 total mics) set to momentary mode. The microphone mixer/switcher is the Vaddio MicVIEW.
Hot Shot Preset Camera Controller Vaddio IR Remote Commander INSTALLATION Example with Vaddio PTZ Cameras: Using the IR Remote Control to Set up to 6 Presets: Step 1: Find the Vaddio IR Remote Commander. Step 2: Set the first 6 presets with the IR remote by moving the camera to the desired location, touch and hold the preset button and while holding the preset button, touch a preset number 1 through 6 to store that preset. Step 3: After the presets are set, put Dip Switch 5 down.
Hot Shot Preset Camera Controller General Specifications: Hot-Shot Preset Camera Controller 999-1036-000 - North America Part Numbers 999-1036-001 - International (with UK and Euro AC Cord Set) Connectors & Controls 5.5mm OD and a 2.
Hot Shot Preset Camera Controller Warranty Information (See Vaddio’s Warranty Policies posted on vaddio.com for complete details): Hardware* Warranty: One year limited, non-transferable warranty on all parts. Vaddio warrants this product against defects in materials and workmanship to the original purchaser for a period of one year from the day of purchase from Vaddio.
Hot Shot Preset Camera Controller Compliance and CE Declaration of Conformity Compliance testing was performed to the following regulations: FCC Part 15, Subpart B ICES-003, Issue 4: 2004 EN 55022 A: 2006 + A1: 2007(CISPR 22:2005/A1:2005) AS/NZS CISPR 22: 2009 VCCI V-3/2010.
