5 Operation
LED Status Indicators for Models SP00143, SP00180, SP00181 and SPC0187
LED
Charger Status
Yellow solid The charger is ON and is in Bulk Stage or Absorption Stage.
Green solid The charger is ON and is in Float Stage.
Red solid The charger is OFF because internal temperature is too high. Shutdown may
have been caused by high ambient temperature or by restricted cooling air flow.
The charger will automatically restart when internal temperature is acceptable.
Green
BLINKING
The charger is OFF. Either 120VAC is disconnected or battery is disconnected.
No LED’s The charger is OFF and is disconnected from both 120VAC and battery.
LED Status Indicators for Models SP00155, SPC0182 and SPC0184
LED
Charger Status
Yellow solid The charger is ON and is in Bulk Stage or Absorption Stage.
Green solid The charger is ON and is in Float Stage.
Red solid The charger is OFF because internal temperature is too high. Shutdown may
have been caused by high ambient temperature or by restricted cooling air flow.
The charger will automatically restart when internal temperature is acceptable.
Green
Blinking
The charger is OFF. The charger is connected to 120VAC but is disconnected
from battery.
No LED’s The charger is OFF because 120VAC is disconnected. (Battery connection
status is not defined.)
