SAFETY INFORMATION GO TO VAPAMORE.COM TO SEE THE MR-75 AMICO INSTRUCTIONAL VIDEO ! FAILURE TO FOLLOW SAFETY INFORMATION AND WARNINGS MAY CAUSE PERMANENT DAMAGE AND VOID PRODUCT WARRANTY. around water. use only with a grounded outlet. Only use distiled water. Using hard water can cause calcium or mineral build up and void the warranty. Vapamore in order to prevent a fire hazard.
PARTS OVERVIEW GO TO VAPAMORE.COM TO SEE THE MR-75 AMICO INSTRUCTIONAL VIDEO 5 6 7 8 9 10 11 12 13 14 15 16 PARTS LIST TECHNICAL SPECIFICATIONS Model: MR-75 Amico MR-75 Amico Power supply: 115 V - 60 Hz Steam hose and connector Heating element: 1000 W - 10 A Accessory tool adapter Steam Pressure: 3 bar- 43.5 psi Measuring cup / funnel Tank capacity: 200 ml - .21 qt Carrying case Heating time: 4 min.
FILLING & OPERATION GO TO VAPAMORE.COM TO SEE THE MR-75 AMICO INSTRUCTIONAL VIDEO GENERAL FUNCTION: The MR-75 Amico steamer uses a heated boiler tank filled with water to create steam. When first plugged in you will see the red power light showing that the unit is powered on and heating. Once at full temperature the light will turn green showing the steamer is ready for use. This light will change back and forth from red to green during use as the heater cycles on and off.
STEAM CLEANER ASSEMBLY GO TO VAPAMORE.COM TO SEE THE MR-75 AMICO INSTRUCTIONAL VIDEO Fig. 4 ! Carrying case for MR-75 and all accessories. Fig. 5 2 1 2 The carrying case can be used to store and transport the MR-75 Amico and all the accessories and tools. Fig. 4 Accessories twist lock onto the adapter. The accessory tool adaptor is required when using all accessories. Attach by aligning the arrow on the accessory with the arrow on the accessory tool adapter and twisting to lock in place. Fig. 5 Fig.
OPERATION GO TO VAPAMORE.COM TO SEE THE MR-75 AMICO INSTRUCTIONAL VIDEO Fig. 10 90 Deg. jet nozzle ACCESSORIES / DETAIL TTAIL AD APTOR ADAPTOR Tool adaptor The accessory tool adaptor can also be used on its own as a straight jet nozzle tool or along with the 90 degree jet nozzle attachment. These tools are great for removing soap scum in the bath, shower and around faucets. Also for cleaning tight areas such as toilet hinges where high pressure steam can reach and blow out dirt and debris.
OPERATION GO TO VAPAMORE.COM TO SEE THE MR-75 AMICO INSTRUCTIONAL VIDEO Fig. 15 THES - FFABRIC TOOL ACCESSORIES / CLOTHES 9 Start by installing the supplied cotton cover on the clothes - fabric / smooth surface tool. This tool can be used for steaming and sanitizing along with eliminating odors in garments, fabrics, furniture, curtains, drapes, etc. Fig. 15 BEDBUG - DUST MITES - ALLERGENS The Vapamore MR-75 Amico produces steam with an output temperature between 200˚ to 210˚deg rees.
REFILL / CLEANING / STORAGE GO TO V VAPAMORE.COM VAP APAMORE.COM AP AMORE.COM TO SEE THE MR-75 AMICO INSTRUCTIONAL VIDEO The tank must be filled up when the steam flow emitted starts to decrease. Turn off the MR-75 Amico by unpluging from the wall outlet. The red operation pilot light will be off. Allow the unit to cool down for at least 15 minutes. Press the steam trigger to release any remaining steam pressure. Open the tank cap by pressing down and turning counter - clockwise.
TROUBLESHOOTING GO TO VAPAMORE.COM TO SEE THE MR-75 AMICO INSTRUCTIONAL VIDEO PROBLEM? What do I do if the machine or an accessory becomes damaged or broken? Visit www.vapamore.com for a complete list of parts and accessories available for purchase or simply call us at 480-951-8900 or E-mail us at info@vapamore.com to purchase replacement parts or schedule a repair. WE ARE HERE TO HELP... IMPORTANT : Do not return to the place of purchase for warranty or repairs.
Lifetime Limited Warranty for the Vapamore MR-75 Amico Steam Cleaner Coverage: 1: Lifetime parts and labor on the boiler, heating element and all internal electronics. The Vapamore MR-75 Amico Steam Cleaner boiler tank, heating element and all internal electronic parts are lifetime warranted to be free from defects in material and workmanship when utilized for normal household use by the original purchaser only. 2: One (1) year parts and labor on accessories and housing.
