User Manual

Let’s talk technical Accessories
Removing blockages from the brushbar
Replacing the belt or brushbars
Threads caught in the
brushbar can be cut out
with scissors.
CAUTION: Do not open the motor cover.
Turn machine on its side
and use a crosshead
screwdriver to remove
the eight screws.
Remove the two part belt
cover from unit. NOTE: Wheel
is intended to be removed
with belt cover.
Pull both brushbars
towards user to remove
from unit.
Remove and dispose
of old belt.
To replace belt, slip the
brushbars through the
belt. NOTE: Place belt
on rounded areas of
brushbars without bristles.
With the belt in place, pull
and slide the brushbars
into the unit, making sure
the brushbar end caps are
in the correct position.
Place new belt on motor
shaft. Replace the two part
belt cover and secure by
replacing all screws.
To reduce the risk of electric
shock, turn the machine o and
unplug from electrical socket
before performing maintenance/
troubleshooting checks.
CAUTION
