2.8.8 Technical Data
CAN channels
Max. 4,
configurable via Piggybacks, up to 2 Mbit/s
LIN channels
Max. 4,
configurable via Piggybacks, up to 330 kbit/s
K-Line channels
Max. 2
with LINpiggy 7269mag at CH1/CH2
J1708 channels
Max. 4,
configurable via Piggybacks
Analog input
10 bit
Input 0...18 V
Voltage tolerance up to 32 V
Sampling rate up to 1 kHz
Digital input
Range 0...32 V
Schmitt trigger high 2.7 V, low 2.2 V
Hysteresis 0.5 V
Input frequencies up to 1 kHz
Digital output
Open Drain
External supply up to 32 V
Current max. 500 mA
Short circuit / over voltage protected
Temperature range
Operating: -40 °C...+70 °C
Shipping and storage: -40 °C...+85 °C
Relative humidity of ambient air
15 %...95 %, non-condensing
Operating system requirements
Windows XP (SP3)
Windows Vista (SP1)
Windows 7 (32 Bit / 64 Bit)
Windows 8 (64 Bit)
Dimensions (LxWxH)
Approx. 83 mm x 110 mm x 44 mm
Weight
330 g (without accessories)
Power consumption
Approx. 2.5 W
