4.5.3 MOST
Device test
The operating test for MOST can be executed with the following devices:
> VN2610
> VN2640
MLoop.exe
This functional test requires a MOST fiber optic cable and a fiber coupler for HFBR
connectors.
1. VN2610
Start \Drivers\Common\MLoop.exe from the driver CD
VN2640
Start \Drivers\Common\M150Loop.exe from the driver CD.
2. Select the VN2610/VN2640 to be tested from the list of detected devices.
3. Click [Twinkle] and check if the power LED of the VN2610/VN2640 is blinking at
least for one second.
4. Connect the MOST fiber optic cable with the VN2610/VN2640 device, select
Master mode and check if the program displays the status Unlock. Check if red
light comes out of the TX fiber of the MOST fiber optic cable.
5. Connect both ends of the fiber with one fiber coupler to a ring and check if the
program displays the status Lock.
6. Close MLoop.exe with [Exit].
4.5.4 Ethernet
Device test
The operating test for Ethernet can be executed with the following devices:
> VN5610
1. Connect both Ethernet channels of the VN5610 with an Ethernet cable.
2. Start \Drivers\Common\ETHloop.exe from the driver CD.
3. Select an installed VN5610 from the list.
4. Press [Twinkle] and check if the LED Status blinks.
5. Start the test by pressing the button [Start Test]. The test is successful if no error
messages occur.
