VEC021ST START-IT ™ JUMPSTART SYSTEM & POWER SUPPLY PORTABLE, CORDLESS, RECHARGEABLE 12-VOLT DC POWER SUPPLY COMPLETELY PORTABLE, SAFE AND CONVENIENT INCLUDES INSTRUCTIONS FOR 110 VOLT AC POWER INVERTER OPTION THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USE, READ AND UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS, PLUS YOUR VEHICLE’S BATTERY MANUFACTURER GUIDELINES.
TABLE OF CONTENTS WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 CAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 YEAR LIMITED WARRANTY PROGRAM This limited warranty program is the only one that applies to this product, and it sets forth all the responsibilities of Vector Manufacturing, Ltd., regarding this product. There is no other warranty, other than those described herein. This Vector Manufacturing, Ltd. product is warranted, to the original purchaser only, to be free of defects in materials and workmanship for two years from the date of purchase without additional charge.
1 WARNINGS WARNING STATEMENTS IDENTIFY CONDITIONS OR PRACTICES THAT MAY RESULT IN PERSONAL INJURY OR LOSS OF LIFE 1. WHEN WORKING WITH LEAD ACID BATTERIES, ALWAYS MAKE SURE IMMEDIATE ASSISTANCE IS AVAILABLE IN CASE OF ACCIDENT OR EMERGENCY. 2. ALWAYS USE PROTECTIVE EYEWEAR WHEN USING THIS PRODUCT: CONTACT WITH BATTERY ACID MAY CAUSE BLINDNESS AND/OR SEVERE BURNS. BE AWARE OF FIRST AID PROCEDURES IN CASE OF ACCIDENTAL CONTACT WITH BATTERY ACID. 3.
2 CAUTIONS CAUTION STATEMENTS ADVISE AGAINST CERTAIN CONDITIONS AND PRACTICES THAT MAY RESULT IN DAMAGE TO VEHICLES, APPLIANCES, AND/OR THE START-IT™ JUMPSTART SYSTEM. 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. IMPORTANT: ALTHOUGH THIS UNIT IS DELIVERED IN A PARTIALLY-CHARGED STATE - YOU MUST FULLY CHARGE IT WITH THE SUPPLIED 110/120-VOLT AC CHARGER FOR A FULL 24 HOURS, BEFORE USING IT FOR THE FIRST TIME. IMPORTANT: DO NOT OVERCHARGE UNIT, THIS WILL REDUCE BATTERY LIFE.
11 CAUTION: DO NOT USE THIS UNIT TO OPERATE APPLIANCES THAT DRAW MORE THAN 200 WATTS OR EXCEED MAXIMUM WATTAGE OF INVERTER. 5. EMERGENCY/WORK LIGHT Bulb Replacement You will need a small Phillips screwdriver 1. Replacement bulbs are available from Vector® Customer Service Department; call (954) 584-4446 EXT. 19 or toll-free (866) 584-5504 2. Remove two Phillips screws from the lens. 3. Lift off the lens assembly. 4. Remove the burned-out bulb. 5. Replace with a new bulb (12-volt 0.4 amp Krypton bulb). 6.
10 4. OPERATION AS A PORTABLE POWER SUPPLY 4.1 Operation as a 12-volt DC Power Supply NOTE: Make sure that the unit ‘s safety ON/OFF switch is ALWAYS in the OFF position when using the 12-volt DC accessory outlet. 1. Lift up the cover of the unit ‘s 12-volt DC cigarette lighter-type receptacle (See Figure 1, #1). 2. Insert the 12-volt DC plug from the appliance into the receptacle on the unit. 3. Switch on the appliance, and operate as usual.
3 Figure 1 1 10 11 3 1. 12-Volt DC Charger/Output Socket, with Overload Protection 4 9 2 2. Safety ON/OFF Power Switch (No Key Required) 3. Charge Status Button 4. Heavy-Duty Copper Welding Cables 5. Heavy-Duty, 400 Amp Copper Clamps 6 6. Exclusive, Quick-Release, Spring-Loaded Clamp Holsters 7. 110/120-Volt AC/DC Charging Adapter Cord 8 8. 12-Volt DC/DC Charging Adapter Cord 9. Built-in Emergency Worklight 10. Light ON/OFF Switch 5 11.
4 NOTE: The Start-It Jumpstart System is equipped with an audible Reverse Polarity Alarm. This feature is only active when the Safety Switch is turned OFF. After both battery clamp connections are made during jump-start procedures, if you hear a buzzing sound, DO NOT TURN ON THE SAFETY SWITCH. You must swap the clamp connections before continuing. If the buzzer does not sound, it is safe to turn on the Safety Switch and follow the Jumpstart procedure.
9 2. Insert one end of the DC/DC charging cord into the 12-volt DC cigarette lighter receptacle on the vehicle or boat. 3. Insert the plug at the other end of this power cord into the 12-volt DC receptacle on the front panel of the unit. 4. Charge the unit until the green FULL indicator lights when Charge Status Indicator Button is pressed. DO NOT EXCEED 3-4 HOURS MAXIMUM. 5. When charging is completed, remove the power cord and store in a safe place. 3.3 110/120 VAC Charging Using VEC070 1.
8 clamps together—this can cause dangerous sparks, power arcing and/or explosion. FIRST AID: • Skin: If battery acid comes in contact with skin, rinse immediately with water, then wash thoroughly with soap and water. If redness, pain, or irritation occurs, SEEK IMMEDIATE MEDICAL ATTENTION. • Eyes: If battery acid comes in contact with eyes, flush eyes immediately– for minimum of 15 minutes — SEEK IMMEDIATE MEDICAL ATTENTION. 3.
5 1. INTRODUCTION Congratulations on selecting the Vector® START-IT™ JUMPSTART SYSTEM & 12-VOLT DC POWER SUPPLY. Please read this guide carefully before use to ensure optimum performance and avoid damage to the unit or items that you are using it with. The Vector® START-IT™ JUMPSTART SYSTEM & 12-VOLT DC POWER SUPPLY is a compact, durable and portable jumpstart system for vehicles and boats that have a standard 12-Volt battery system.
6 2. USING THE START-IT™ AS A JUMPSTART SYSTEM CAUTIONS: 1. 2. 3. 4. 5. 6. 7. 8. 9. Before using this system to jumpstart any vehicle or boat, read and understand all instructions, safety tips, warnings, cautions and first aid information provided in this manual and on the product labeling. Additional important information may also be provided by the vehicle‘s battery system manufacturer. BE AWARE OF FIRST AID PROCEDURES BEFORE ATTEMPTING JUMPSTART PROCEDURE.
7 TERMINAL OR MOVING PART. IF AUDIBLE ALARM SOUNDS - DO NOT TURN ON SAFETY SWITCH! REVERSE POLARITY OF CLAMP CONNECTIONS POSITIVE GROUND SYSTEMS NOTE: In the rare event that the vehicle to be started has a Positive Grounded System (positive battery terminal is connected to chassis): Replace step 3 above with the following steps, and then proceed to steps 4-6 below. 3a. Connect negative (-) black clamp to vehicle battery ‘s negative terminal. 3b.
VECTOR MANUFACTURING, Ltd. 4140 S.W. 28th Way Ft.
