TERMINAL SETUP
VX 520 Setup
VX 520 I
NSTALLATION GUIDE 23
V
E
R
I
F
O N
E
C
O
N
F I
DE
N
T
I
A
L
TE
MP
LATE
R
EV
F
To use the
connection ports
The connection ports offer multiple connectivity for the VX 520 terminal. Please
refer to the following list of peripheral devices for the connectivity options.
Host USB Port
• PP1000 USB
• V
x
810 USB
• Barcode reader
• Biometric reader
• USB flash disk
• USB keyboards
Ethernet Port
• Ethernet cable to router, hub or switch
Client USB Port
• PC
• ECR/Cash register
RJ-11 Port
• Telephone line
RS-232 Port
• PP1000
• V
x
810
• PC download cable
• Computer
• ECR
• Check reader
• CTLS reader
• Biometric reader
• Barcode reader
• Keyboard
For information on how to attach peripheral devices, see Connecting Optional
Devices.
