TERMINAL SETUP
VX 520 Setup
32 VX 520 INSTALLATION GUIDE
V
E
R
I
F
O N
E
C
O
N
F I
DE
N
T
I
A
L
TE
MP
LATE
R
EV
F
Connecting the PIN
pad or Smart Card
Reader to the VX 520
Use the following procedures to connect a PIN pad or smart card reader.
1 Remove the VX 520
terminal rear cover.
2 Insert the RJ-45-type connector of the PIN pad or smart card reader into the
port of the peripheral device.
To install a PINpad 101, PINpad 201, or PINpad 1000, position and insert the
grommet to secure the cable connection.
If a cable is not already connected to the smart card reader or PIN pad, insert
the small modular plug on one end of the interface cable into the optional
device’s modular jack.
NOTE
When the VX 520 terminal is powered via the corded power supply, the terminal
provides 4.0 A at 9.3V DC. This power will drive most VeriFone accessories.
Contact your local VeriFone representative for more information.
