Connecting ECRs to
the VX 520
The VX 520 terminal also supports Electronic Cash Registers (ECR). Contact
your VeriFone representative or visit the online store at www.store.verifone.com
for information on these devices.
Figure 27 provides an example of a peripheral connection to the USB port.
Figure 27 VX 520 D/E Sample ECR Connection
Figure 28 VX 520 GPRS Sample ECR Connection
CAUTION
ECRs require a separate power source. Before connecting a check reader or
similar device, remove the power cord from and ensure that the indicator LED is
not lit.
