Monitor: Local Display,
Output & BTU
DESCRIPTION
3000 and 3050 Series digital ow monitors are designed for HVAC submetering
applications. With panel and wall mounting options, these compact devices display
ow rate and ow total on an alphanumeric LCD display. Calibration, selection of
measurement units, and output programming are keypad controlled. Two pulse
outputs are available for connection to external systems.
The 3050 BTU monitor has all of the features and programming exibility of the
3000 ow monitor with the added ability to accept temperature inputs from 10 kΩ
Dale thermistors and a single pulse output for energy total. This monitor provides an
accurate measurement of total thermal energy along with temperature and liquid
ow in closed pipe systems.
APPLICATIONS
● Interfacing and displaying sensor data
● Energy monitoring, communication, and management
FEATURES
● Provides a display of energy rate, energy total, ow rate, and total ow with
user-congurable units for convenient viewing (U001-0015 only)
● Password-based access control for added security
● 2-line x 16-character backlit LCD for easy visibility
● Conforms to DIN 96 mm standard dimensions...compatible with existing panels
and enclosures
● NEMA 4 rated front panel...durable
● Information stored in non-volatile memory...no power required for memory
backup of calibration information, units of measure, and ow totals
● High level communication with optional USB, RS-485 Modbus,
and BACnet/MSTP
Displays Flow Rate,
Flow Total, and Energy
3000 Digital Flow Monitor
SPECIFICATIONS
Input Power +12-24VDC/VAC; limits: 8-35VDC, 8-28VAC
Input Frequency 0.4 to 160 Hz
Totalizer 0.000001 to 1,000,000
Operating Temperature -20° to 70°C (-4° to 158°F)
Storage Temperature -30° to 80°C (-22° to 176°F)
Maximum Sinking Current 150mA@+24VDC
Display 16 x 2 alphanumeric backlit LCD
Year
Warranty
1
