Mixing Controller OWNER'S MANUAL

ManualsBrandsVestax ManualsMusical InstrumentMixing Controller

Professional Mixing Controller



OWNER'S MANUAL

VESTAX CORPORATION

2-37-1Kamiuma,Setagaya-ku,Tokyo154-0011Japan

Phone:03-3412-7011Fax:03-3412-7013

VESTAX MUSICAL ELECTRONICS CORPORATION

4240CSouthMobileCircle.Aurora.Colorado80015U.S.A.

Phone:303-766-5269Fax:303-766-2196

E-mail:vestax-corporation@msn.com

VESTAX

(

Europe

)

Ltd.

18st.ChristophersRoad,Haslemere,SurreyGU271DQEngland.

Phone:(0)1428-653117Fax:(0)1428-661021

Summary of content (8 pages)

PAGE 1
Professional Mixing Controller OWNER'S MANUAL VESTAX CORPORATION 2 3 7 1K a m i u m a ,S e t a g a y a k u ,T o k y o1 5 4 0 0 1 1J a p a n P h o n e : 0 3 3 4 1 2 7 0 1 1F a x : 0 3 3 4 1 2 7 0 1 3 VESTAX MUSICAL ELECTRONICS CORPORATION 4 2 4 0 CS o u t hM o b i l eC i r c l e .A u r o r a .C o l o r a d o8 0 0 1 5U . S . A . P h o n e : 3 0 3 7 6 6 5 2 6 9F a x : 3 0 3 7 6 6 2 1 9 6 E m a i l : v e s t a x c o r p o r a t i o n@ m s n .c o m VESTAX (Europe)Ltd. 1 8s t .
PAGE 2
CONGRATULATIONS！ Thank you for purchasing the VESTAX PMC -27MKII，Professional Mixing Controller．As The top of the line, the PMC-27MKII is a high specification mixer designed to meet the most professional requirements of the Dance Music DJ's. Please read this owner's manual carefully before you start to use your mixer, so that you will fully understand all of the special features and enjoy the full of use of the product. IMPORTANT PRECAUTIONS To prevent electric shock, do not remove the cover.
PAGE 3
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTl0N：TO REDUCE THE RlSK OF ELECTRlC SHOCK DO NOT REMOVE COVER（OR BACK） NO USER-SERVICEABLE PARTS INSIDE REFER SERVlCING T0 QUALIFIED SERVlCE PERSONNEL The lightning flash with arrowhead symbol，within an equilateral triangle，is intended to alert the user to the presence of uninsulated“dangerous voltage”within the product's enclosure that may be of sufficient magnitude to consitute a risk of electric shock to persons． The exclamation point within an equilateral t
PAGE 4
TOP PANEL PROGRAM INPUT SECTION PRO FESSIONAL MIXING CONTROLLER LINE 4 IN L PGM 1 SUB INPUT R INPUT LINE 2 PHONO 1 MIC LINE 4 PHONO 2 LINE 6 PHONO 3 LINE 3 TRIM MASTER INPUT LINE 1 MIC-1 PGM 2 LINE 5 TRIM +8 +5 +5 +3 +3 +1 +1 TRIM MIC-2 MIN MIC-1 MAX BAL MIN MAX BAL MIN MAX BAL MICROPHONE SUB INPUT SECTION MIN MAX L R L R EQ HI EQ HI MIC-2 L CUE +8 0 0 -1 -1 -3 -3 -5 -5 -7 -7 -10 -10 -15 -15 POWER POWER MASTER SECTION R EQ HI L R EFFE
PAGE 5
PROGRAM INPUT SECTION PGM 1 INPUT LINE 2 PHONO 1 1 LINE 1 TRIM 2 MIN MAX BAL 3 L R EQ HI -16dB +16dB MID 4 -12dB +12dB LOW -16dB +16dB EFFECT 5 PRE OFF POST CUE 6 OFF SIGNAL 10 9 8 7 6 7 5 4 3 2 1 ON PROGRAM INPUT SECTION 1. INPUT SELECTOR Used to select input (2line or 1phono) to be sent to each PGM channel. 2. TRIM CONTROL Adjusts the Input level of each channel. Set INPUT FADER to 7- 8position. adjust TRIM so that the INPUT LEVEL METER shows about 0dB. 3.
PAGE 6
MICROPHONE, SUB INPUT SECTION LINE 4 IN 9 L R MIC 10 MIC-1 MIC-2 MIC-1 MIN 11 MAX MIC-2 MICROPHONE, SUB INPUT SECTION 9. LINE INPUT JACK(LINE4) Input connectors for line level equipment such as CD players,tape decks ,DATs, or MDs ETC. 10. MIC INPUT JACK(MIC1,2) Input jacks of mic1, mic2. 11. MIC LEVEL Adjusts the input level from all of the microphone inputs. 12. MIC EQUALIZER(HI,LOW) Adjusts the HI and LOW frequencies for all of the microphone input. MASTER SECTION 13.
PAGE 7
ISOLATOR SECTION ISOLATOR SECTION 25, HI SWITCH Allows cutting off the sound of treble range. Sound volume will be cut when the switch is set downwards. When the switch is put back, the output volume returns to normal. Can be useful for cutting off the sound of the cymbals or high hats for example. 26, MID SWITCH Allows cutting off the sound of the middle range. Sound volume will be cut when the switch is downward position. When the switch is put back, the output volume becomes normal sound volume.
PAGE 8
Vestax Corporation
