VCM7000 Series-Installation Guide1 |

Contents

Description 2

Models Available 2

Installation 3

Module Installation 3

Specications 4

VCM7000 Series

Accessory Communication Module

Installation Guide

For VT(R)7000 Series Controllers

May 16th 2011 / 028-0344-R1

PAGE 1
VCM7000 Series Accessory Communication Module Installation Guide For VT(R)7000 Series Controllers May 16th 2011 / 028-0344-R1 Contents Description Models Available Installation Module Installation Specifications 1 | VCM7000 Series-Installation Guide 2 2 3 3 4
PAGE 2
Description All current “Network Ready” Viconics VT(X)7000 ( 5000 Series ) controllers purchased after July 2010 are capable of being retrofit in the field with accessory communication adapters that enables the controllers to be integrated into virtually all leading building automation system. This approach allows the flexibility to add network communication strategies as budgets allow or as the buildings needs change.
PAGE 3
Installation Remove the security screw on the bottom of Terminal Equipment Controller cover. • Open unit by pulling on the bottom side of Terminal Equipment Controller (fig. 1). • Remove power to the unit by disconnecting to top left terminal block. • Ensure power is down by confirming the local display is not operating. Module Installation 1. Align module connector and the 2 retaining pins on their respective insertion points of the controller base. 2.
PAGE 4
Specifications Operating conditions: 0 °C to 50 °C ( 32 °F to 122 °F ) 0% to 95% R.H. non-condensing Storage conditions: -30 °C to 50 °C ( -22 °F to 122 °F ) 0% to 95% R.H. non-condensing Approximate shipping weight: 0.75 lb ( 0.34 kg ) Agency Approvals all models: UL: UL 873 (US) and CSA C22.2 No.
