Viconics VWG-50 Wireless Gateway Guide Specification

Part 1 – General

1.01 System Description – The VWG-50 when utilized in conjunction with the Viconics VT7000xxxxxW

series and VZ7000xxxxxW wireless communicating controllers shall offer the integrator simple BACnet IP

or BACnet MS/TP objects to integrate over standard building automation systems using familiar

integration toolsets. The Viconics communicating controllers and gateway with wireless field bus allows

the centralization of stand-alone equipment without the need to pass communication wiring.

1.02 Quality Assurance – The wireless gateway must have the following industry approvals and

specifications:

Specifications

Platform

• PowerPC 405EP 250 MHz processor

• 64MB SDRAM & 64 MB Serial Flash

• 128 KB Static RAM

• Battery Backup - 5 minutes typical - shutdown

begins within 10 seconds

• Real-time clock - 3 months backup max via

battery

Operating System

• QNX RTOS

• IBM J9 JVM Java Virtual Machine

• NiagaraAX

Wired Communications

• 2 Ethernet Ports – 10/100 Mbps (RJ-45

Connectors)

• 1 RS 232 Port (9 pin D-shell connector)

• 1 RS 485 non-isolated port (3 Screw

Connector on base board)

Wireless Communications

• Direct spread spectrum 2.4 GHz ISM bands

• Transmission power is under 1 mW at –0.4

dBm for channels 11 to 25 and –4.0 dBm for

channel 26

Power Supply

• VWG-PS-AC 120 VAC to 15 VDC power

supply for VWG with cord

Chassis

• Construction: Plastic, din rail or screw mount

chassis, plastic cover

• Cooling: Internal air convection

• Dimensions: 6.313” (16.04 cm) W x

4.820”(12.24 cm) H (including connectors) x

2.438” (6.19 cm) D

Environment

• Operating temperature range: 0° to 50°C (32°F

to 122°F)

• Storage Temperature range: 0° to 60°C (32°F

to 140°F)

• Relative humidity range: 5% to 95%, non-

condensing

Agency Listings

• UL 916, C-UL listed to Canadian Standards

Association

• (CSA) C22.2 No. 205-M1983 “Signal

Equipment”

• FCC Part 15 Subpart C

• C-tick (Australia)

Summary of content (2 pages)

PAGE 1
Viconics VWG-50 Wireless Gateway Guide Specification Part 1 – General 1.01 System Description – The VWG-50 when utilized in conjunction with the Viconics VT7000xxxxxW series and VZ7000xxxxxW wireless communicating controllers shall offer the integrator simple BACnet IP or BACnet MS/TP objects to integrate over standard building automation systems using familiar integration toolsets.
PAGE 2
Part 2 – Equipment 2.01 General – The VWG-50 Wireless Gateway shall provide a simple way in which to integrate Viconics wireless communicating controllers into today’s building automation systems using either BACnet MS/TP or BACnet IP open protocols.         The Viconics Wireless Gateway and related VT7000xxxx Wireless Communicating Controllers shall be supplied with a factory mounted wireless adapter and operate using ZigBee/IEEE 802.15.4 physical layer for communication.
