4”TFT-LCD MONITOR V141 Series USER’ S MANUAL www.viewera.com Rev 1.
CONTENTS 1. Introduction Page 3 Product Description ....................................................... Page 3 Package Contents .......................................................... Page 3 Product Features …....................................................... Page 3 Screen Cleaning Techniques ......................................... Page 4 Additional ..................................................................... Page 4 2. Control Functions Page 6 Function Selection .........
1. Introduction Product Description Congratulations on your purchase of the ViewEra V141 series LCD monitor. It incorporates high quality display into a small light-weighted module. It has power-saving capabilities and emits no radiation. You will certainly benefit from this monitor in lots of ways; to name some of them: comfort, safety, space-saving and environmental protection.
Screen Cleaning Techniques 1. Gently clean the screen with a clean camel hair lens brush, or a soft, clean, lint-free cloth, to remove dust and other particles that can scratch the screen. 2. Do not apply pressure to the screen surface when wiping it clean. 3. Do not pour or spray any liquid directly onto the screen or casing. Chemical cleaners have been reported to damage the screen or case of the LCD monitor. Additional Read all of these instructions and save them for later use.
If the product does not operate normally when the operating instructions are followed. Adjust only those controls that are covered by the operating instructions. Improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician. If the product exhibits a distinct change in performance, service may be required. 4. Power and extension cords Do not allow anything to rest on the power cord.
2. Control Functions The monitor digital control functions are located on the front panel. They are shown in the figure below and described in the following paragraphs. 1. Power switch with indicator LED 2. Function Keys Function Selection 1. Press the “ 1” knob to show the OSD menu. Then use the “ △”and “ ▽” knobs to select a function. Press the “ 2”knob to close the OSD menu. 2. With the “ △”and “ ▽”knobs, you can adjust the speaker volume on the monitor.
2. Video Brightness - Adjust the luminance level of the image. Contrast - Adjust the contrast level of the image. Black Level - Adjust the black Level of the image. Exit - Close the Video OSD menu. 3. Audio Volume - Adjust the speaker volume Balance - Adjust the speaker volume to right side or left side. Exit - Exit the Audio OSD menu. 4. Color Color Temperature User - Adjust the R.G.B. gain level. 6500K - Select color temperature of 6500°K. 9300K - Select color temperature of 9300°K.
6. Language - Set the language of the OSD windows. 7. Tools OSD Control OSD Timer - Setting the OSD menu display time. OSD H. Position - Adjust the horizontal position of the OSD menu. OSD V. Position - Adjust the vertical position of the OSD menu. Exit - Close the OSD Control OSD menu. Recall - Recall the factory default setting. Sharpness - Adjust the picture more clearly. Exit - Close the Tools OSD menu. 8. Exit - Close the OSD menu. 3.
Installing the Base Follow these steps to install the base: 1. Turn the monitor down. 2. Assembly the base to the arm with screw. 3. Tighten the screw with a coin. Installing the Monitor This monitor is equipped with an auto sensing DC power adapter for voltage ranges of 100-240VAC, 60/50Hz. Follow these steps to install the monitor: 1.Before you connect the cables, made sure that the monitor and the system unit power switches are off. 2.
User Setting Area The user settings by the user on the last display mode maintain in the memory of the micro-controller. You can change the settings or add a nonstandard mode. The micro-controller always detects and displays the last mode stored in the user setting area when the monitor is turned on. Factory Presetting Area There are some preferred display modes preset in the micro-controller. These display modes are preset at the factory and include the most popular display modes currently available.
15-pin Mini D-type Male Connector 1 2 3 4 5 Pin Assignment Red Video 6 Green Video 7 Blue Video 8 Ground 9 No Connection 10 Red Ground Green Ground Blue Ground No Connection Sync Ground 11 Ground 12 Serial Data/I/O 13 H. Sync 14 V. Sync 15 Serial Clock Input 6. Power Saving Features When the power saving is active, the power indicator LED will be from Green Light to Amber. The power saving feature complies with these VESA power saving modes: Mode H. Sync. V. Sync.
7. Product Specifications Model Features Panel Type: Size: Pixel Pitch: Brightness: Contrast Ratio: Response Time: Viewing Angle(H / V) Max. Resolution: Display Color Maximum Viewable Size Anti-glare, active TFT-LCD 14.1”diagonal 0.279 (W) ×0.279 (H) mm 150 cd/㎡ (typical) 300:1 (typical) 23 ms (typical) 80° / 50° 1024 (W) x 768 (H) @ 60 Hz (non-interlace) 262K 14.1 inch (35.8cm) Video Input Analog:15-pin, D-sub connector Display Area 11.2 (W) x 8.
8. Dead Pixel Policy Dead pixels on the TFT LCD panel are sometimes inevitable. ViewEra guarantees that the monitor will be replaced if the number of dead pixels on our monitor exceeds 5 pixels. 9. Warranty & Customer Service Warranty ViewEra warrants the V141 TFT-LCD monitor for three years for parts and labor, one year for LCD panel from the date of purchase. For detail warranty information, please refer to our website – http://www.viewera.com/warranty.
10. Windows setup For the best view, please set the monitor type in Windows.
11. Trouble Shooting 1) Power on but no picture → Make sure the VGA cable is tightly connected from the video output connector on the video card to the video input connector on the monitor. → Make sure you are using the standard power adapter coming with the monitor. → Check your video card if the driver is correctly installed. If there is no video signal from the video card, “ NO INPUT SIGNAL”will show on the screen.
6) Residue image → If an image remains on the screen for an extended period of time, it may be imprinted in the screen and leave a residue image. It is characteristic of liquid crystal and is not malfunction or deterioration of the liquid crystal. The residue image will disappear after a period of time. It is recommended to set up the screen saver for your LCD monitor.
