ViewSonic ® PJ556D DLP Projector - User Guide - Guide de l’utilisateur - Bedienungsanleitung - Guía del usuario - Guida dell’utente - Guia do usuário - Användarhandbok - Käyttöopas - Pyководство пользователя - 使用手冊 (繁體) - 使用手冊(简体) Model No. : VS11664 Downloaded From projector-manual.
Compliance Information For U.S.A. This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
Important Safety Instructions 1. Read these instructions completely before using the equipment. 2. Keep these instructions in a safe place. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this equipment near water. Warning: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. 6. Clean with a soft, dry cloth. If further cleaning is required, see “Cleaning the Display” in this guide for further instructions. 7.
Declaration of RoHS Compliance This product has been designed and manufactured in compliance with Directive 2002/95/EC of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Proposed Maximum Concentration Actual Concentration Lead (Pb) 0.1% < 0.1% Mercury (Hg) 0.
Copyright Information Copyright © ViewSonic® Corporation, 2007. All reserved. Macintosh and Power Macintosh are registered trademarks of Apple Computer, Inc. Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and other countries. ViewSonic, the three birds’ logo, OnView, ViewMatch, and ViewMeter are registered trademarks of ViewSonic Corporation. VESA is a registered trademark of the Video Electronics Standards Association.
Safety Instructions Read all of these instructions before you operate your projector and save for future reference. 1. Check that the operating voltage of your unit is identical with the voltage of your local power supply. 2. Should any liquid or solid object fall into the cabinet, unplug the unit and have it checked by the qualified personnel before operating it further. 3.
13. For ventilation reasons, the fan continues to operate after the projector has been powered off. Please do not unplug the power cord until the fan stops. 14. The projector is equipped with ventilation holes (intake) and ventilation holes (exhaust). Do not block or place anything near these slots, or internal heat buildup may occur, causing picture degradation or damage to the projector. 15. When you replace the projector lamp, never touch the new bulb with your bare hands.
Notes on AC Power Cord AC Power Cord must meet requirement of country where you use a projector. Confirm an AC plug type with graphics below and proper AC Power Cord must be used. If supplied AC Power Cord does not match your AC outlet, contact your sales dealer. This projector is equipped with a grounding type AC line plug. Make sure that your outlet fits the plug. Do not defeat the safety purpose of this grounding type plug.
CONTENTS Introduction..............................................................................................................6 Projector Features..............................................................................................6 Package Contents..............................................................................................7 Projector Overview.............................................................................................8 Using the Product.......................
Introduction Projector Features The projector integrates high-performance optical engine projection and a user-friendly design to deliver high reliability and ease of use. The projector offers the following features: Single chip 0.55” Texas Instruments DLP® technology XGA (1024 x 768 pixels) 1.2X manual zoom lens Auto image re-sizing (Auto-Sync.
Package Contents When you unpack the projector, make sure you have all these components: Projector with Lens Cap S-Video Cable Remote Control (IR) with Lithium battery AC Power Cord Composite Video Cable Projector Carrying Case VGA Cable (D-SUB to D-SUB) Audio Cable User’s Manual Quick Start Guide Optional Accessory: VGA (D-SUB) to HDTV (RCA) Cable RS232 Cable USB Cable Save the original shipping carton and packing material; they will come in handy if you ever to ship your unit.
Projector Overview Front View 9 1 1 2 3 4 5 2 3 Ventilation holes Projection lens Front IR remote control sensor Lens cap Elevator foot 8 7 4 5 6 7 8 9 Downloaded From projector-manual.
Rear View 1 2 3 4 5 6 7 8 Rear IR remote control sensor Ventilation holes Connection ports Elevator button 1 Elevator foot Speaker AC power socket Kensington lock 2 3 8 7 2 6 5 4 Bottom View 1 Lamp cover 2 Ceiling mount 2 2 2 1 This projector can be used with a ceiling mount for support. The ceiling mount is not included in the package. ViewSonic PJ556D Downloaded From projector-manual.
Using the Product Control Panel LED 1 Lamp LED indicator Refer to “LED Indicator Messages”. 2 Power LED indicator Refer to “LED Indicator Messages”. 1 2 3 4 8 5 7 6 Button Function 3 Power Refer to “Powering On/Off the Projector”. 4 Keystone / Adjusts image distortion caused by tilting the projector. 5 Auto Automatically adjusts frequency and phase. This function is available for computer mode only. 6 Menu Displays or exits the on-screen display menus.
Connection Ports 1 2 3 4 5 6 1 SERIAL When operating the projector via a computer, connect this to the controlling computer’s RS-232C port. 2 USB Connector (Service purpose) This connector is for firmware update. 3 COMPUTER IN Connects image input signal (analog) to this jack. 4 S-VIDEO Connects S-Video output from video equipment to this jack. 5 VIDEO Connects composite video output from video equipment to this jack. 6 AUDIO IN Connects an audio output from video equipment to this jack.
Remote Control 1 Power Refer to “Powering On/Off the Projector”. 2 Four directional buttons Use four directional buttons to select items or make adjustments to your selection. 3 MENU Displays or exits the on-screen display menus. 4 Laser Aim the remote at the viewing screen, press and hold this button to activate the LED light pointer. 5 Mute Cuts off the sound temporarily. Press again to cancel the Mute function. 6 Resync Automatically adjusts frequency and phase.
Battery Replacement 1. Open the battery cover in the direction shown. 2. Install batteries as indicated by the diagram inside the compartment. 3. Close the battery cover into position. Keep the batteries out of the reach of children. There is a danger of death by accidentally swallowing the battery. Remove batteries from remote control when not using for extended periods. Do not dispose of the used battery along with household waste. Dispose of used batteries according to local regulations.
Remote Control Operation Point the remote control at the infrared remote sensor and press a button. Operating the projector from the front 10 15 5m 5m 7m Frezze Light Volume Resync Volume + - Hide Operating the projector from the rear 10 15 5m 5m 7m Frezze Light Volume Resync Volume + - Hide The remote control may not operate when there is sunlight or other strong light such as a fluorescent lamp shining on the remote sensor.
Installation Connecting the Projector 1 2 3 4 RS232 Cable USB Cable VGA Cable (D-Sub to D-Sub) Audio Cable 5 Composite Video Cable 6 S-Video Cable 7 VGA (D-Sub) to HDTV (RCA) Cable Laptop type Desktop type 1 7 2 6 3 5 4 When connecting cable, power cords of both a projector and external equipment should be disconnected from AC outlet. The figure above is a sample connection. This does not mean that all of these devices can or must be connected simultaneously.
Powering On/Off the Projector Powering on the projector: 1. Remove the projector lens cap. 2. Complete the AC power cord and peripheral signal cable(s) connections. button to turn on the projector. 3. Press 4. Turn on your source (computer, notebook, DVD, etc.). The projector automatically detects your source. When searching message appears on the screen, ensure that the appropriate signal cable(s) are securely connected. The signal message will appear on the screen when the source is detected.
Adjusting the Projected Image Adjusting the Projector Height Elevator button Elevator foot The projector is equipped with an elevator foot to adjust the image height. To raise the image: 1. Press the elevator button. 2. Raise the image to the desired height angle, then release the button to lock the elevator foot into position. To lower the image: 1. Press the elevator button. 2. Lower the image, then release the button to lock the elevator foot into position.
Adjusting the Projector Zoom and Focus Zoom ring Focus ring 1. Focus the image by rotating the focus ring. A still image is recommended for focusing. 2. Adjust the image by rotating the zoom ring. Rotate to the right to reduce the image. Rotate to the left to enlarge the image. 17 Downloaded From projector-manual.
Adjusting Projection Image Size Refer to the graphic and table below to determine the screen size and projection distance. 275.00 137.40 82.40 256.00 57.70 128.00 27.50 76.50 53.70 25.60 1.0m (Min.) 2.1m 3.0m 5.0m 10.0m (Max.) PROJECTION 1.0 2.1 3.0 5.0 10.0 Wide 29.0 60 86.0 143 285 Tele 25.0 52 74.0 123 246 DISTANCE (METER) 4:3 SCREEN SIZEDIAGONAL (INCH) Position the projector in a horizontal position; other positions can cause heat build-up and damage to the projector.
Menu Operation The projector has multilingual On Screen Display menus that allow you to make image adjustments and change a variety of settings. 19 Downloaded From projector-manual.
How to operate 1. Press Menu button to open the OSD menu. 2. When OSD is displayed, use / buttons to select any feature in the main menu. After selecting the desired main menu feature, press button to enter sub-menu for feature setting. 3. Adjust the settings with / buttons. 4. To return to the main menu, toggle button. 5. To exit OSD, press Menu button. The OSD menu will close and the projector will automatically save the new settings. To exit OSD from the sub-menu, press Enter button.
Image (Computer / Video Mode) Contrast The contrast controls the degree of difference between the lightest and darkest parts of the picture. Adjusting the contrast changes the amount of black and white in the image. Press to decrease the contrast. Press to increase the contrast. Brightness Adjusts brightness of the image. Press to darken the image. Press to lighten the image. Keystone Adjusts image distortion caused by tilting the projector.
Red Manually adjusts red. Green Manually adjusts green. Blue Manually adjusts blue. Video (Video Mode) Saturation Adjusts a video image from black and white to fully saturated color. Press to decrease the amount of color in the image. Press to increase the amount of color in the image. Tint Adjusts the color balance of red and green. Press to increase the amount of green in the image. Press to increase the amount of red in the image. Sharpness Adjusts the sharpness of the image.
Language (Computer / Video Mode) Choose the multilingual OSD menu. Use / to select your preferred language. Press “Menu” to finalize the selection. Advanced (Computer / Video Mode) Auto Source Select Automatically scans the input source. Press “Menu” to confirm or cancel the selection. Rear The image is reversed horizontally. Press “Menu” to confirm or cancel the selection. Ceiling The image is inverted vertically. Press “Menu” to confirm or cancel the selection.
Maintenance The projector needs proper maintenance. You should keep the lens clean as dust, dirt or spots will project on the screen and diminish image quality. If any other parts need replacing, contact your dealer or qualified service personnel. When cleaning any part of the projector, always switch off and unplug the projector first. Warning: Never open any of the covers on the projector. Dangerous electrical voltages inside the projector can cause severe injury.
Replacing the Lamp Projector lamps have a finite life. Replace the lamp when: The image becomes darker and hues become weaker after a lamp has been for a long period of time. The projector lamp LED indicator turns into amber. Refer to section titled “LED Indicator Messages” for further details. The lamp becomes high temperature after turning off the projector with the power button. If you touch the lamp, you may scald your finger.
1. Turn off the projector and unplug the AC power cord. 2. Place a protective sheet (cloth) beneath the projector. Turn the projector over so you can access the lamp cover. 3. Loosen the access panel screws and open the panel. 4. Loosen the screws on the bottom of the lamp assembly. 5. Grasp the lamp handle and pull the lamp assembly directly out of the projector. 6. Replace with the new lamp. 7. Tighten the screws on the bottom of lamp assembly. 8. Tighten the screws on the lamp cover.
Specifications Display Type Resolution (Pixels) Lens Aspect Ratio Screen Size Lamp Projection Type Video Compatibility Input Source Scanning Frequency Horizontal Frequency Vertical Frequency Digital Keystone Correction Integrated Speaker Remote Control OSD Language Storage Temperature Operation Temperature Operation Humidity Power Requirement Power Consumption Dimension (W x D x H) Weight Single 0.55” DLP panel 1024 x 768 Manual Zoom (1.
Appendix LED Indicator Messages Projector Status Standby Lamp LED Type Meaning Power LED Lamp LED Color Status Color Status Green Flashing The projector is powered and ready. Amber Solid - - ignition The projector system has some problems with its fan, so the failure projector cannot start up. Power on Amber Solid Green Solid The projector is in good condition and is projecting at maximum brightness.
Compatibility Modes Computer: Mode 480P VGA VGA VGA VGA VGA SVGA SVGA SVGA SVGA XGA XGA XGA XGA Mac16” SXGA SXGA 720P XGA XGA SXGA SXGA Mac 480-66A Resolution 640 x 480 640 x 480 640 x 480 640 x 480 720 x 400 720 x 400 800 x 600 800 x 600 800 x 600 800 x 600 1024 x 768 1024 x 768 1024 x 768 1024 x 768 832 x 624 1280 x 1024 1280 x 1024 1280 x 720 1024 x 768 1024 x 768 1152 x 870 1152 x 864 640 x 480 fH (kHz) 31.46 37.86 37.5 43.2 31.5 37.9 35.1 37.8 48.0 46.8 48.3 56.4 60.0 68.8 49.7 63.98 79.9 45.0 48.
Troubleshooting Refer to the symptoms and measures listed below before sending the projector for repairs. If the problem persists, contact your local reseller or service center. Please refer to “LED Indicator Messages” as well. Symptom No power. Power goes out during use. Cause The AC power cord is not plugged in. The AC power cord is not connected to the projector. The lamp cover is loose. The temperature is too high. The ventilation holes are blocked. No image appears The projector is not turned on.
Symptom Remote control doesn’t work. Cause Solution The battery could be weak. Replace with a new battery. The remote control is not Use the remote control within being used within the effective the effective range. range. There are some obstructions Check that there are not between the remote control obstructions between the and projector. remote control and projector.
Customer Support For technical support or product service, see the table below or contact your reseller. Note : You will need the product serial number. Country/ Region Web Site T=Telephone F=Fax T= 800 688 6688 E-mail service.us@viewsonic.com United States www.viewsonic.com/support/ Canada www.viewsonic.com/support T= 866 463 4775 service.ca@viewsonic.com www.viewsoniceurope.com/uk T= 0207 949 0307 service.eu@viewsoniceurope.
Limited Warranty VIEWSONIC® PROJECTOR What the warranty covers: ViewSonic warrants its products to be free from defects in material and workmanship, under normal use, during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components.
2. T o obtain warranted service, you will be required to provide (a) the original dated sales slip, (b) your name, (c) your address, (d) a description of the problem, and (e) the serial number of the product. 3. Take or ship the product freight prepaid in the original container to an authorized ViewSonic service center or ViewSonic. 4. For additional information or the name of the nearest ViewSonic service center, contact ViewSonic.
