Specification Sheet
OSLO FEATURES
—
DESCRIPTION Portable wireless loudspeaker
GENERAL SPECIFICATIONS
Dimensions Height/Width/Depth 268 mm / 181 mm / 90 mm
Net weight 2.4 kg
Frame One piece diecast aluminium
Enclosure Polycarbonate
Grilles Custom-made Kvadrat textile
Colors Pebble Grey, Anthracite Grey, Sunset Red
Sand Yellow, Ocean Blue, Ice Blue
TECHNICAL FEATURES Bluetooth 4.0
Powered by Qualcomm
®
aptX
™
audio
AUX 3.5 mm mini‐jack
NFC
Lithium Ion battery
Force Balanced Woofers
DSP crossover, optimized for low distortion and high precision
4 Channel digital pure path amplier
DRIVER UNITS
Full Range 2 X 50 mm Vifa driver unit with
aluminium cone and neodymium magnet
Woofer 2 X 65 mm Vifa driver units with at sandwich
cone and neodymium magnet. Mounted
mechanically back to back in a force balanced
conguration supported by 2 passive radiators.
Frequency response 55 Hz – 18 kHz @ +/– 3 dB
POWER CONSUMPTION
Input voltage, wall adaptor 100 Volt – 240 Volt 50/60 Hz 1500mA Max
Input voltage, loudspeaker 18VDC,2500mA
Standby power consumption Less than 0.5 watt when battery is fully charged
DESCRIPTION Portable wireless loudspeaker
GENERAL SPECIFICATIONS
Dimensions Height/Width/Depth 268 mm / 181 mm / 90 mm
Net weight 2.4 kg
Frame One piece diecast aluminium
Enclosure Polycarbonate
Grilles Custom-made Kvadrat textile
Colors Pebble Grey, Anthracite Grey, Sand Yellow,
Ocean Blue, Ice Blue
TECHNICAL FEATURES Bluetooth 4.0
Powered by Qualcomm
®
aptX™ audio
AUX 3.5 mm mini-jack
NFC
Lithium Ion battery
Force Balanced Woofers
4 Channel digital pure path amplifier
DSP crossover, optimized for low distortion
DRIVER UNITS
Full Range
Woofer
Frequency response
2 X 50 mm Vifa driver unit with aluminium cone and
neodymium magnet
2 X 65 mm Vifa driver units with flat sandwich cone
and neodymium magnet. Mounted mechanically
back to back in a force balanced configuration
supported by 2 passive radiators.
55 Hz – 18 kHz @ +/– 3 dB
POWER CONSUMPTION
Input voltage, wall adaptor 100 Volt – 240 Volt 50/60 Hz 1500mA Max
Input voltage, loudspeaker 18VDC,2500mA
Standby power consumption Less than 0.5 watt when battery is fully charged
