16–6 Chapter 16: Deinterlacer II MegaCore Function
Signals
Video and Image Processing Suite January 2013 Altera Corporation
User Guide
Signals
Table 16–3 lists the input and output signals for the Deinterlacer II MegaCore
function.
Table 16–3. Deinterlacer II Signals (Part 1 of 4)
Signal Direction Description
av_st_clock
In
The main system clock. The MegaCore function operates
on the rising edge of the
av_st_clock
signal.
av_st_reset
In
The MegaCore function asynchronously resets when you
assert
av_st_reset
. You must deassert this reset signal
synchronously to the rising edge of the
av_st_clock
signal.
av_mm_clock
In
Clock for the Avalon-MM interfaces. The interfaces operate
on the rising edge of the
av_mm_clock
signal.
(3)
av_mm_reset
In
Reset for the Avalon-MM interfaces. The interfaces
asynchronously resets when you assert
av_mm_reset
. You
must deassert this reset signal synchronously to the rising
edge of the
av_mm_clock
signal.
(3)
din_data
In
din
port Avalon-ST
data
bus. This bus enables the
transfer of pixel data into the MegaCore function.
din_valid
In
din
port Avalon-ST
valid
signal. This signal identifies the
cycles when the port must input data.
din_startofpacket
In
din
port Avalon-ST
startofpacket
signal. This signal
marks the start of an Avalon-ST packet.
din_endofpacket
In
din
port Avalon-ST
endofpacket
signal. This signal
marks the end of an Avalon-ST packet.
din_ready
Out
din
port Avalon-ST
ready
signal. This signal indicates
when the MegaCore function is ready to receive data.
dout_data
Out
dout
port Avalon-ST
data
bus. This bus enables the
transfer of pixel data out of the MegaCore function.
dout_valid
Out
dout
port Avalon-ST
valid
signal. The MegaCore function
asserts this signal when it outputs data.
dout_startofpacket
Out
dout
port Avalon-ST
startofpacket
signal. This signal
marks the start of an Avalon-ST packet.
dout_endofpacket
Out
dout
port Avalon-ST
endofpacket
signal. This signal
marks the end of an Avalon-ST packet.
dout_ready
In
dout
port Avalon-ST
ready
signal. The downstream device
asserts this signal when it is able to receive data.
control_address
In
control
slave port Avalon-MM
address
bus. This bus
specifies a word offset into the slave address space.
(4)
control_write
In
control
slave port Avalon-MM
write
signal. When you
assert this signal, the
control
port accepts new data from
the
writedata
bus.
(4)
control_writedata
In
control
slave port Avalon-MM
writedata
bus. These
input lines are used for write transfers.
(4)
control_read
In
control
slave port Avalon-MM
read
signal. When you
assert this signal, the
control
port outputs new data at
readdata
.
(4)
