BROADBAND Mini WiFi Modem MF62 User Guide
IS YOUR ACCOUNT ACTIVATED? Pre-Paid Customers Table of contents First up, you need to activate your service: Is your account activated 2 CLICK virginmobile.com.au/activate NB: You’ll need a different internet connection to activate online. Welcome to Virgin Mobile! 4 What's in the box 4 See page 8 for the final steps to get online. System requirements 5 Post-Paid Customers Your first connection 6 Your service is already activated, so head to page 8 for the final steps to get online.
Welcome to Virgin Mobile! System requirements Congratulations! That cool gadget you’ve got in your hands is going to let you take the internet with you, so you’ll never have to miss a beat. • Windows XP Service Pack 2, Windows Vista or Windows 7. • Mac OS X 10.5 and 10.6 with the latest updates installed. • The hardware of your computer must meet or exceed the recommended system requirements for the installed version of OS.
Your First Connection The first time you connect, you’ll be taken to a special page to register your broadband service. Enter your first and last names and set up your primary Virgin Broadband email address, which we’ll use to contact you from time to time. Make a note of this email address & password – you’ll need them to check your usage. You can delete, edit and manage your existing email addresses or create up to 4 new ones through the following page: mybroadbandusage.virginbroadband.com.au.
Managing Your Account Checking your data usage & topping up your account To check your usage, go to mybroadbandusage.virginbroadband. com.au and log in using your full Virgin Broadband email address and password. Need more data? If you’re getting a bill each month, you can top-up by logging into My Account (virginmobile.com.au/myaccount) with your service number & 6-digit PIN. The top-up will be added to your next bill.
General Information Quick Reference Section Browser home page http://virginmf62.com or http://192.168.0.1 (via wireless connection only) Administrator Password admin Default SSID Virgin Wifi xxxxxx. Details printed under your battery. Default Security Key 10 characters which are case sensitive. Details printed under your battery. Restore defaults From the powered up state: Press & hold the power key and the WPS key simultaneously.
damages. The user should refer to the enclosed warranty card for full warranty and service information. RoHS Declaration (Restriction of Hazardous Substances) RF Safety Information ZTE declares that the Wireless Router is free from hazardous materials and complies with EU directive 2002/95/EC (commonly known as the RoHS Directive) and the amendments. The router has an internal antenna. For optimum performance with minimum power consumption do not shield the device or cover with any object.
2.1 Insert your USIM 2 Getting started Antenna Port OLED Display 2.1 Insert your USIM 1. thethe back cover down to open. 1. Slide Slide back cover 2.1 Insert your USIMdown to open. 2. Insert the (U)SIM with the gold contacts facing down and the bevelled 1. Slidecard the back cover down to open. 2. Insert the (U)SIM card with the gold contacts facing down and Power microSD slot TM WPS USB Charging Port 1. Power Key - Press and hold the for three seconds to switch on or off. 2.
For these situations it is recommended that, in addition to the charger being connected, the battery is 2.2 Charge your Wireless Router 1. Insert the charger lead carefully into the socket at the base of the router. 2. The plug only fits one way. Do not use excessive force to insert o the socketthe at plug. the base of the router. 3. Check the plug is the right way round and insert it gently. se excessive force to insert the plug. 4.
2.4 Low Power Mode (Standby Mode) 3 Using the Wireless Router With no WiFi device connected the wireless router will go into low power mode after 10 minutes. 3.1 Preparation • The display will extinguish, the WiFi SSID broadcast will switch off. Before using the wireless router, make sure that: • Press the Power or WPS key to exit from Low Power Mode. • The (U)SIM card is inserted. • The device is On and the display is visible. • Search for available Wireless Networks on your computer and connect.
3.4 WAN Connection Always On The modem will connect to the cellular network automatically. Always on does not refer to the WiFi connection status. To operate as ‘always on’ for WiFi make sure there is a WiFi device connected that does not itself go into sleep mode. Manual Select Manual mode to manually control when the unit connects to the cellular data service. Select Connect or Disconnect and press Apply to make the selected action. When you login, the Home Page is displayed 3.5 Phone Book 3.
3G Settings WiFi Security Settings Wireless info View network status Network Select Select your preferred network mode. Only change if instructed by your service provider. APN Setting Select or change your APN settings. Only change if instructed by your service provider. WiFi Settings Station List View number of connected WiFi devices Security Select or change your WiFi security mode and password WPS WPS uses a PIN number to share with compatible devices.
Firewall Settings Firewall settings are intended for advanced users and network administrators. There is usually no need to apply any settings in a home environment. Note: You can set up to a maximum of 10 filter items for MAC/IP/ Port Filtering and Port Forwarding. MAC / IP / Port filtering • Default Policy: Set how to handle the packet if none of the rules match. • MAC address: Set the MAC address to be filtered. • Destination IP Address: Set the destination IP address to be filtered.
Port Forwarding Settings You can set up virtual servers to provide internet services. Select Firewall > Port Forwarding > Enable to configure the Virtual Server Settings. • See your warranty card for warranty and service information. • View Frequently Asked Questions on line: www.zte.com.au/ virgin IP Address: Set the IP address for the virtual server. Port Range: Set the port numbers for the virtual server. Protocol: Set the protocol for the virtual server.
4 Troubleshooting Symptoms Possible Problems/ Solutions Symptoms Possible Problems/ Solutions I cannot access the internet at all. Check the LCD display which shows the number of active connections. If this is 0 or x then WiFi is notconnected. Verify your password is correct. Make sure your SIM card is inserted correctly. Check you have network coverage in your area. Check that your SIM card is active and enabled with data services. Please wait 1 - 2 minutes for the router to initialize.
5 Technical Specifications • Network & Frequency Band WCDMA: 900, 2100MHz • GSM 850, 900, 1800, 1900MHz • Data Services HSDPA Downlink: up to 21.6Mb/s* • HSUPA Uplink: up to 5.76Mb/s* • WiFi working range approx 25m radius in free space • WiFi Connections supports up to 8 users • Dimensions (W×H×D) 99.6 x 54 x 14.
8. The router and charger are for indoor use only. 9. Use an antistatic cloth to clean the router. Do not use harsh chemicals solvents or abrasive cleaners as these could damage the case. Got a question we haven’t answered here ? • Try virginmobile.custhelp.com or • Email virginmobile.com.
