LOW ESR TANTALUM CAPACITORS
FROM LOW ESR TO VERY LOW ESR SMD, TANTALUM, AND POLYMER TECHNOLOGIES
IG12533871-1908
www.vishay.com
© 2019 VISHAY INTERTECHNOLOGY, INC. ALL RIGHTS RESERVED.
APPLICATIONS
PERFORMANCE CHARACTERISTICS
TR3, T55
INDUSTRIAL
CONSUMERTELECOM
T55 SERIES
TR3
Used for decoupling, smoothing, bulk energy
storage, and filtering in:
Solid State Drives (SSD)

Infrastructure equipment
 
Computer motherboards

Computer servers
 
Power conversion and
distribution
 
Gaming and video
 
Smart meters
 
Lighting

TR3
T55
Capacitance
and Voltage
ESR
TR3
Tantalum
From 4 V to 75 V
From 0.47 μF to 1000 μF
Down to
45 mΩ
A, B,
C, D,
E, W
T55
Polymer
From 2.5 V to 63 V
From 3.3 µF to 1000 µF
Down to
6 mΩ
J, P,
A, T,
B, Z,
V, D
Case Size
QUALITY
0.06 Ω
0.5 Ω0.25 Ω0.1 Ω0.1 Ω
ESR
min.
0.08 Ω0.06 Ω0.1 Ω
4 V
50 V
6.3 V
35 V25 V20 V
16 V10 V
Voltage Rating
Max. Capacitance
680 μF
10 μF47 μF100 μF150 μF330 μF470 μF
0.45 Ω
33 μF
63 V
4.7 μF
EIA-717
(TR3)
