PARTS

4.1

PART NAMES PART NUMBERS

1 Lava Stone

2 Stainless Steel Stone Bracket

3 Infrared Heat Exchanger

4 Gas Grill Burner Insert

4.1 Gas Grill Burner Insert Knob

4.2 Ignition Button Cap

5 Gas Hose with Quick

Disconnect Fitting

6 Gas Supply Hose Bracket (x2)

7 Match Ignition Tool

VGK-101R

VGK-BRACKET

VGC-GPIHE

VGC-GPBI-S

VGC-GPBIK

VGC-GPIBC

VGC-GHQD1

VGC-GPGSLC-2

VGC-MIT

4.2

SAFETY INFORMATION

PLEASE READ THE ENTIRE MANUAL BEFORE OPERATING YOUR VISION GRILLS KAMADO GRILL. PLEASE KEEP THIS MANUAL FOR FUTURE REFERENCE.

ATTENTION! Use caution when cooking as grill surfaces get hot. To avoid burns, always use protective gloves to adjust top and bottom vents when grill is in use. Do not

wear loose clothing near the grill.

ATTENTION! This barbecue will become very hot; do not move it during operation. For outdoor cooking use only. Do not operate grill indoors or in an enclosed space. Use

grill only in well ventilated area around the grill, free from combustible materials. Allow for at least 3 feet/1 meter of clearance around grill (house, other outdoor products,

hanging tree limbs, shrubs, etc.).

WARNING! Keep children and pets away from the grill at all times. Do not allow children to operate grill. Never leave grill unattended when in use.

Grill needs to be placed securely on a level base prior to use. Only operate grill on a hard, stable level surface (concrete patio, ground, etc.) capable of supporting the grill’s

weight when loaded with food. Never operate grill on wood support surface, wood deck or similar combustible support surfaces under any conditions. Never attempt to

move grill when it is in operation or cooling down. Never operate this grill within 25 feet/7.5 meters of any ﬂammable liquid. Never operate this grill within 10 feet/3

meters of a gas cylinder. The grill should not be placed under combustible structures, such as garage, porch, patio, or carport. Burning charcoal or propane gives off carbon

monoxide, which has no odor and can cause death.

The use of alcohol, prescription or non-prescription drugs may impair the operator’s ability to properly assemble or safely operate the grill. Do not use on boats or

recreational vehicles.

CAUTION: Never use lighter ﬂuid, gasoline, or other volatiles to start your charcoal, as they are dangerous and leave a residual taste in your food. NEVER use Charcoal

Briquettes that contain starting chemicals or additives. Use only ﬁrelighters complying to EN 1860-3. Use utmost care when adding charcoal to grill. Electric start-up is

recommended. Dispose of cooled ashes by placing them in aluminum foil, soaking with water and discarding in a non-combustible container.

When operating with gas, top vent MUST be open at all times, see instructions.

Professional Kamado Gas Insert

WELCOME TO VERSATILE KAMADO COOKING

Your new Kamado Quickchange Gas Insert completes your existing Vision

Grills Kamado, allowing you to sear, grill, bake, and smoke all types of food

with your choice of Charcoal or Gas.

For those times you want to quickly prepare a meal without the use of

charcoal, you have the Quickchange Gas Insert to help you. Simply pull out

the removable Ash Drawer and slide in the Gas Insert, position the Heat

Exchanger, and ﬁre it up!

Welcome to the newest innovation for versatile Kamado cooking! Before

beginning, make sure to read the following Manual completely for

instructions on operating with NATURAL GAS.

Patented

Summary of content (4 pages)

PAGE 1
Professional Kamado Gas Insert WELCOME TO VERSATILE KAMADO COOKING Your new Kamado Quickchange Gas Insert completes your existing Vision Grills Kamado, allowing you to sear, grill, bake, and smoke all types of food with your choice of Charcoal or Gas. For those times you want to quickly prepare a meal without the use of charcoal, you have the Quickchange Gas Insert to help you.
PAGE 2
SET UP STEP 1 Step 1: Attach Hose Brackets Step 3: Connect to Gas Source • Attach the two hose brackets (used to hold gas hose), with eyelets facing in, onto the front and rear legs of cart (Step 2). • Put the gas tank on the Gas Tank Caddy and tighten into place using Gas Tank Caddy knob (Step 3a). Note: Do NOT allow the hose to touch the ceramic. Step 2: Install Battery • Remove Ignition Button Cap by turning counter clockwise. Insert AA battery (not included) negative end first.
PAGE 3
STARTING Step 5: Place Heat Diffuser Lava Stone ATTENTION: The grill needs to be cooled before switching from the Ash Drawer to the Quickchange Gas Insert. Step 1: Fully Open Top Vent Spread bracket so it makes an “X” shape and lower onto fire bowl, allowing the bracket to rest on edge of bowl. Lower Lava Stone onto the bracket. Replace cooking grates with hinged sections facing towards the front of grill. Step 6: Connect to Gas Supply Turn Top Vent to position 3 (or SEAR).
PAGE 4
GENERAL INSTRUCTIONS This instruction manual contains important information necessary for the proper assembly and safe use of the appliance. Read and follow all warnings and instructions before assembling and using the appliance. Keep this manual for future reference. Always wait for grill to be completely cooled before opening built-in ash drawer.
