CCTV CATALOGUE 2006 E D I T I O N www.x-vision.co.
Index 4-7 Bullet Camera Range Full details and specifications of our Bullet camera range, available with Omnivision CMOS, Panasonic CCD, or Sony Super HAD CCD images sensors for 350 to 500 TVL resolution, a choice of 3.6 to 12.0mm lenses and up to 25 metres Infra Red nightvision. 8 - 11 Dome Camera Range Full details and specifications of our Dome camera range, available with Sony CCD, Sony Super HAD CCD or Sony HQ1 Super HAD CCD image sensors for 420 to 550 TVL resolution, a choice of 3.3 to 22.
Foreward by Mike Norcross Business Development Manager X-vision in the News X-vision Group (UK) Welcome to the 2006 edition of the X-vision CCTV Catalogue which showcases the full X-vision CCTV product line up. As one of the UK’s leading CCTV brands we offer excellent performance, great value and uncompromised quality. All X-vision products are designed in the UK by our own R&D team and offer unrivalled performance and innovative features.
Introduction Bullet Cameras The X-vision bullet camera range is designed to fit every budget and application from low risk to high risk. Bullet cameras are very versatile and are ideal for use where a discreet low profile camera is required, they are weatherproof without the need for a separate housing and can be used internally as well.
Model: VIS225IR Features CMOS 1/3” Colour 350 TVL CMOS Bullet Camera with 5m IR Nightvision Integrated Long Life Infra Red LEDs turn on automatically when the camera switches to B/W mode and provide up to 5 metres night vision No 43° Omnivision 1/3" CMOS image sensor for 350 TVL resolution images and 2.
Model: XV300E Features Dual mode CCD sensor provides good quality Colour images in low light conditions of 0.5 lux or above and B/W images in low light conditions below 0.5 lux and in complete darkness.
Model: VIS349 Features CCD 1/3” 500 TVL 30 to 64° Lens 0.1 VIS349 Colour 500 TVL Sony 1/3" Super HAD CCD Varifocal Bullet Camera with 10m IR Nightvision Lux Weather Resistant The VIS349 colour bullet camera is designed for high risk applications.
Introduction Dome Cameras With over seven different types of dome cameras in the range, X-vision dome cameras are ideal for internal or external use in areas where the camera wil require regular cleaning, is in danger of being tampered with or at risk of being vandalised. Dome cameras are also ideal for use in areas where discreet unobtrusive surveillance is required. Most of our dome cameras feature integrated Infra Red LEDs for night vision capability.
Model: VIS200D Features CCD TVL 60° Lens 0.5 VIS200D Colour 420 TVL Sony 1/4" CCD Dome Camera Lux X Colour Discreet styling for unobtrusive low profile use DSP: X-vision IXC1 Tamper resistant and easy to clean as all moving parts are behind the dome cover Sony 1/4" CCD image sensor for 420 TVL resolution images and 0.5 lux low light sensitivity 420 TVL Lens Viewing Angle: 60° Infra Red Nightvision: No Minimum Illumination: 0.
Model: VIS338D Features Super High Resolution CCD sensor provides great quality Colour images in light levels of 0.2 lux and above Dome Cameras Specifications Picture Type: Colour Image Sensor: Sony 1/3” HQ1 Super HAD CCD DSP: X-vision IXC1HQ Discreet styling for unobtrusive low profile use CCD 1/3” 550 TVL 23 to 90° Lens 0.
Model: Features Dual mode Very High Resolution CCD sensor provides very good quality Colour images in low light conditions of 0.1 lux or above and B/W images in low light conditions below 0.1 lux and in complete darkness.
Introduction Long Range IR Since launching our first Infra Red camera in the UK six years ago we have made a massive investment in Infra Red technology and the result is the Long Range IR Nightvision Camera range. With a maximum night vision range of 30 to 60 metres and a choice of standard or varifocal lenses they are designed for use in demanding applications. All models feature X-vision long life low power consumption infra red LEDs for guaranteed year round operation.
Model: VIS430R/450R Features Dual mode Very High Resolution CCD sensor provides very good quality Colour images in low light conditions of 0.1 lux or above and B/W images in low light conditions below 0.1 lux and in complete darkness.
Introduction Traditional Cameras There are two types of traditional style cameras we are able to offer, All In One, which feature an integrated lens for ease of use and aethestically pleasing styling and Box type, which require separate lenses.
Model: PCC125 Features Traditional Cameras Specifications High Resolution CCD sensor provides great Picture Type: quality Colour images in light levels of 0.5 lux and above Image Sensor: CCD 1/4” 420 TVL 60° Lens 0.5 PCC125 Lux Optional DSP: X-vision IXC1 Resolution: 420 TVL Sony 1/4" CCD image sensor for 420 TVL resolution images and 0.
Model: PCC422 Features CCD 1/4” 520 TVL 2 to 60° Lens 0.5 PCC422 Lux Optional Specifications Dual mode Super High Resolution CCD sensor provides great quality Colour images in low light conditions of 0.5 lux or above and B/W images in low light conditions below 0.
Model: PCC225/225AC Features High Resolution CCD sensor provides excellent quality colour images in low light conditions of 0.1 lux or above CCD 1/3” 480 TVL CS Mount Lens 0.5 PCC225/225AC Lux Optional Colour 480 TVL Sony 1/3" Super HAD CCD Box Camera Traditional styling makes it ideal for use in situations where an instant deterrent is required Sony 1/3" Super HAD CCD image sensor for 480 TVL resolution images and 0.
Accessories Traditional Cameras Lenses: A selection of good quality varifocal lenses for use with X-vision traditional box cameras. All X-vision lenses have a 2 Year Manufacturers Warranty 3.5 to 8.0mm Varifocal Manual Iris Lens 2.8 to 12.0mm Varifocal Auto Iris Lens 6.0 to 60.0mm Varifocal Auto Iris Lens The X-vision XL3580M 3.5 to 8.0mm manual iris lens is recommended for use with the PCC125, PBC200, PCC225, PCC225AC, PCC425 and industry standard cameras.
Introduction Mini/Covert Cameras X-vision Mini & Covert cameras are available in B/W or Colour versions and are designed to be hidden in a room or office for undetected surveillance, they are fitted with a high resolution pinhole lens which allows the camera to view full images through an aperture as small as 2mm in diameter.
Model: KCB275P/401P Features 1/3” CCD (B/W) 1/4” CCD (Colour) 480 TVL (B/W) 420 TVL (Colour) 78º Lens (B/W) 60º Lens (Colour) KCB275P/401P B/W (Sony 1/3” CCD) & Colour (Sony 1/4” CCD) Mini Cameras 0.3 Lux (B/W) 0.5 Lux (Colour) X Picture Type: B/W / Colour Image Sensor: Sony 1/3” CCD / Sony 1/4” CCD The KCB275P has a Sony 1/3" CCD image sensor for B/W 480 TVL resolution images and 0.
Model: PC810/811 Features Designed to look just like a standard PIR Alarm Sensor but fitted with a hidden camera inside for covert viewing. 1/3” CCD (B/W) 1/4” CCD (Colour) 480 TVL (B/W) 420 TVL (Colour) 78º Lens (B/W) 60º Lens (Colour) PC810/811 B/W (Sony 1/3” CCD) & Colour (Sony 1/4” CCD) 'Working PIR' Cameras 0.3 Lux (B/W) 0.5 Lux (Colour) Can be used as a PIR Alarm Sensor with NO and NC outputs and pulse count The PC810 has a Sony 1/3" CCD image sensor for B/W 480 TVL resolution images and 0.
Model: PC600 Features Designed to look just like a standard Domestic Smoke Alarm but fitted with a hidden camera inside for covert viewing. Continues to operate as a working smoke alarm 1/3” CCD (B/W) 1/4” CCD (Colour) 480 TVL (B/W) 420 TVL (Colour) 78º Lens (B/W) 60º Lens (Colour) PC600 B/W (Sony 1/3” CCD) & Colour (Sony 1/4” CCD) 'Working Smoke Alarm' Cameras 0.3 Lux (B/W) 0.5 Lux (Colour) The PC600 has a Sony 1/3" CCD image sensor for B/W 480 TVL resolution images and 0.
Introduction Speed Dome Range The most powerful cameras in the X-vision range, these cameras can be manually or automatically panned, tilted and zoomed to the exact views required. We offer a low profile Vandal Resistant Mini Speed Dome camera which is designed for internal or external use, a powerful 270x zoom Day/Night Speed Dome for high risk applications and the worlds first IR Speed Dome with integrated Infra Red LEDs for nightvision.
Model: XVISZCAMX Speed Dome Range CCD 1/3” 500 TVL 30-64° Lens 0.1 Lux XVISZCAMX Weather Resistant Colour 500 TVL Sony 1/3" Super HAD CCD Vandal Resistant Mini Speed Dome The XVISZCAMX Colour Vandal Resistant Mini Speed Dome Camera is designed for use in high risk applications in and situations where there is risk of vadalism to the camera. The camera is designed to withstand a blow from a 10 pound sledgehammer.
Model: XSD27ZDN2 Speed Dome Range CCD 1/4” 550 TVL 1-78° Lens 0.01 Lux XSD27ZDN2 Weather Resistant Colour 550 TVL Sony 1/4" Super HAD CCD Speed Dome with 270x Zoom The XSD27ZDN2 Colour Speed Dome with 270x Zoom is designed for use in high risk applications and can be panned, tilted and zoomed in seconds to the view you require.
Model: XSD22ZIR Speed Dome Range CCD 1/4” 520 TVL 2-60° Lens 0 Lux XSD22ZIR Weather Resistant Colour 520 TVL Sony 1/4" Ex View CCD Speed Dome with 220x Zoom with 50m IR Nightvision The XSD22ZIR Colour Speed Dome with 220x Zoom is designed for use in high risk applications and can be panned, tilted and zoomed in seconds to the view you require.
Introduction Monitors Range The X-vision range of monitors are all designed to offer the best possible picture resolution and the sharpest images.
Model: XCM14 Features CRT 450 TVL Yes Monitors Range Specifications Professional grade CCTV monitor Size: 14” High resolution low radiation 14" CRT for excellent 450 TVL image quality Screen Type CRT Resolution: 450TVL Integrated high fidelity speaker for good quality audio Remote Control: No Loopthrough connections and automatic impedance matching ensures perfect picture quality even when connecting up to 3 additional slave monitors Dimensions (WxHxD): 365x343x318mm Weight: 16Kg Choi
Model: Features 4:3 screen ratio 5" LCD recommended for CCTV applications High resolution 670 TVL image quality LCD 670 TVL Monitors Range XVIS5LCD Specifications Size: 5” Screen Type LCD Resolution: 670TVL Vertical and Horizontal Mirror function for mounting the LCD on a ceiling or using as a reversing monitor Remote Control: YES Dimensions (WxHxD): 148x125x30mm Integrated high fidelity speaker for good quality audio Weight: 1Kg Lightweight compact design Can be wall or ceiling mounted
Model: XLCD17 Features LCD XLCD17 Professional 17" CCTV LCD Monitor Size: 17” High Brightness 17" LCD with special filter for excellent 800 TVL resolution images Screen Type LCD Resolution: 800TVL Integrated high fidelity speakers for good quality audio Remote Control: No 2 switchable BNC inputs and an SVHS input for best picture quality and flexibility 2 BNC and 1 SVHS loopthrough connections connecting an additional slave monitor VGA input for resolutions of up to 1280x1024 pixels Yes Bui
Model: Monitors Range PMP42SX Features PLASMA Size: 42” Screen Type PLASMA High resolution plasma panel for up to 600 TVL images and VGA input resolutions of 1024x768 with a native resolution of 840x480 pixels Resolution: 600TVL Remote Control: YES Dimensions (WxHxD): 1031x634x79mm Weight: 30Kg Features Scart, Video, Audio, SVHS and VGA inputs for versatile connectivity TVL Compatible with NTSC, PAL and SECAM signal types for worldwide use Yes Professional 42" Plasma Display Incorpora
Introduction Analogue Control Equipment Even with the advent of Digital Recording we continue to manufacture a full range of high quality analogue control equipment, including 4 and 8 Camera Switcher units, a powerful 4 Camera Quad unit and a range of 4, 8 and 16 Camera multiplexers. New for 2006 is the sub compact XVCR960P, CCTV Recorder which features both Real Time and Time Lapse recording and dual voltage AC & DC voltage operation.
Model: PCM104A/109A/116A Features Allows you to view up to 16 cameras on one screen.
Introduction DVR Range DVRs are now the most popular way to manage and record CCTV cameras. They record directly on to Hard Drive and offer high resolution recording up to DVD quality (500+ TVL) and high frame rates up to 400 fps (no of images being recorded a second). DVRs outperform equivalent time lapse video based systems which can only record 200 to 300 TVL (when connected to a quad/multiplexer) and a maximum of 6 fps.
Model: EDVR4/9/16 DVR Range EDVR4/8/16 Entry Level 4/8/16 Camera DVRs with PC Backup The EDVR entry level DVR range is ideal for use as a direct replacement for an existing video recorder and switcher, quad or multiplexer or as the heart of a new CCTV system. They are competitively priced with features you would normally expect to see only on more expensive DVRs. Including superior picture quality, fast frame rates and a USB port for quick and easy backing up to a compatible Windows PC.
Model: EDVR4/9/16 DVR Range Main Features in detail: (continued) Timer Recording: The DVR’s will allow the user to set up a comprehensive timer schedule so that it only records during the times and days recording is required. Recording Recycling: Once the hard drive is full the DVR’s can be set to rerecord over the hard drive or display a message alerting the user that the hard drive is full.
Model: TDVR4/9/16 DVR Range TDVR4/8/16 Triplex 4/8/16 Camera DVRs with Network/Internet Access & Optional CD The TDVR professional DVR range is designed for medium to high risk applications and offers the perfect balance of cost versus performance.
Model: TDVR4/9/16 DVR Range Main Features in detail: (continued) Continuous Recording: The standard recording mode of the range is continuous recording, in this mode the DVR will record all the time. Motion Detection Recording: The range also includes a motion detection recording feature, this allows areas of each cameras view to be highlighted and then the DVR will only record when motion is detected in those areas. Allowing the DVR to record for much longer than continuous recording would achieve.
Model: XDVR2 DVR Range XDVR2 Advanced Professional High Speed Pentaplex DVR with Networking/Internet Access & CD/DVD The XDVR2 advanced professional DVR range sets a new standard in excellence in the world of CCTV. Designed for use in high risk application and where only the best will do. It is based on the best selling XDVR range which was recognised all over the world as being one of the best DVRs on the market and was the DVR of choice for the UKs leading retail chains.
Model: XDVR2 DVR Range Main Features in detail: (continued) Triplex Recording: The triplex recording feature of the XDVR2 range allows the user to select any camera full screen or as a multiscreen layout during live viewing without disturbing the recording of all cameras as full screen images. It also allows the user to playback recordings without having to stop current recordings, so that recordings are not interrupted.
Model: XDVR2 DVR Range Additional Features: True Pentaplex Operation: The XDVR2 range features true Pentaplex operation, which allows the following independent functions to take place simultaneously 1. Local Recording of cameras 2. Local Playback of Cameras 3. Remote Viewing of Cameras 4. Remote Playback of Cameras 5.
Introduction PC DVR Range The x-vision PCDVR range of PC based CCTV systems comprise of a Video Capture Card and Software. The Video Capture Card is installed in to a spare PCI slot on any compatible PC, and the software loaded on to the PC, which must be running Windows 2000 or XP. The PC then becomes a powerful Digital Hard Drive Recorder, that can record up to 32 CCTV cameras at up to 200 fps, and at high resolution directly on to the PC's hard drive.
PC DVR Range Main Features (continued) To minimize false detections, the motion detection feature lets you adjust its sensitivity, so it ignores small movements such as rain, and areas of each cameras view can be masked, so for example it ignores movement on the road in front of your premises, but does not ignore movement on the pavement Once movement has been detected as well as recording it the software can call up to 3 telephone numbers and play a prerecorded message, or alternatively send an email with
PC DVR Range Recording Speed & Times: Recording Speeds The x-vision card has 3 different modes of operation for allocating frames to cameras: There are 10 different models of x-vision cards, as well as a choice of camera capacity, they are available with a choice of frame rates, these rates relate to the number of images that are captured per second. To record a camera in real time a frame rate of at least 25 fps is required.
Plug & Play Wiring Accessories Our Plug & Play cable makes fitting your camera quick and easy, as it carries the picture, sound and power down the same cable. Simply connect one side of the cable to the camera and the other to the Tv, Video or CCTV equipment (Switcher, Quad, Multiplexer, DVR, DVR Card).
Standard Wiring Accessories Standard wiring is favoured by installers the world over. It takes longer to set up and run than DIY Plug & Play wiring and requires the installer to put the connectors on the cable However it is more flexible, allowing the cameras to be powered either locally or from another location up to 250m away per camera. We do not recommend the use of this type of cabling by those who are not familiar with CCTV installation, please use DIY Plug & Play wiring if this applies to you.
Cat5 Wiring Wiring Cat 5 wiring (also known as structured cabling) is increasingly being used as an alternative to standard wiring, the main reason is that many commercial buildings have spare Cat 5 cables running through the building and the majority of new buildings have Cat 5 run throughout the building.
Available from: Y3K (Europe) Limited, Unit2,Valley Point, Beddington Farm Road, Croydon, Surrey, CR0 4WF. United Kingdom Tel: +44 (0)870 442 2020 Fax: +44 (0)870 443 0590 Email: sales@y3k.com All prices and specifications are subject to change without notice. All errors and omissions excepted. All network specifications are based upon theoretical scenarios. Actual performance will vary depending on external factors which effect network performance. All relevent trademarks acknowledged.
