Specifications

P
icture Type: B/W / Colour
Image Sensor: Sony 1/3” CCD / Sony
1
/4” CCD
D
SP: X-vision IXC1
Resolution: 480 TVL / 420 TVL
L
ens Viewing Angle: 78º / 60º
I
nfra Red Nightvision: No
Minimum Illumination: 0.3 lux / 0.5 lux
A
udio: Yes
O
perating Voltage: 12V DC 110 / 120mA
Suggested Power Supply: 12V DC 300mA
M
ounting: Wall/Ceiling
W
eatherproofing: No
Dimensions (WxHxD): 37x40x37mm
Specifications (B/W / Colour)
Specifications (B/W / Colour)
Connections
Picture Type: B/W / Colour
Image Sensor: Sony 1/3” CCD / Sony
1/4” CCD
DSP: X-vision IXC1
Resolution: 480 TVL / 420 TVL
Lens Viewing Angle: 78º / 60º
Infra Red Nightvision:
No
Minimum Illumination: 0.3 lux / 0.5 lux
Audio: Yes
Operating
V
oltage:
12V DC 110 / 120mA
Suggested Power Supply: 12V DC 300mA
Mounting: Wall/Ceiling
Weatherproofing: No
Dimensions (WxHxD): 70x120x40mm
Connections
Video Output: BNC Socket
A
udio Output:
P
hono Socket
Power Input: DC Socket
Video Output: BNC Socket
Audio Output: Phono Socket
P
ower Input:
DC Sock
et
20
The cameras measure just 36x36mm and are
f
itted with a pinhole lens which can see out
o
f an aperture as small as 2mm, allowing
them to be easily hidden for covert use
T
he KCB275P has a Sony 1/3" CCD image
sensor for B/W 480 TVL resolution images
a
nd 0.3 lux low light sensitivity and the
K
CB401P has a Sony 1/4" CCD image sensor
for Colour 420 TVL resolution images and 0.5
l
ux low light sensitivity
Both cameras feature an X-vision IXC1
D
igital Signal Processing (DSP) chip which
h
as been optomised for internal viewing and
features Automatic Gain Control, Automatic
E
lectronic Iris, Auto White Balance, Back Light
C
ompensation, Low Smear and Edge
Enhancement, the KCB401P also features
Z
ero Colour Rolling
3.7mm focus free pinhole lens for 78°
v
iewing angle on the KCB275P and 60°
v
iewing angle on the KCB401P
D
esigned for internal use and wa
ll or ceiling
m
ounting
2
Year Manufacturers Warranty
Covert CamerasModel: KCB275P/401P
Features
The KCB275P and KCB401P Mini cameras are designed for covert
use in medium to high risk applications. They feature a pinhole
lens which can see through an aperture as small as 2mm. The
KCB275P offers high resolution B/W 480 TVL images from its
Sony 1/3" CCD sensor and will provide images in light levels as
low as 0.3 lux and the KCB401P offers high resolution Colour 420
TVL images from its Sony 1/4" CCD sensor and will provide
images in light levels as low as 0.5 lux. Both are designed for
internal use and wall or ceiling mounting and can be used as a
covert camera.
B/W (Sony 1/3” CCD) & Colour (Sony
1/4” CCD) Mini Cameras
KCB275P/401P
480 TVL
(
B/W)
420 TVL
(Colour)
78º Lens
(B/W)
60º Lens
(Colour)
0.3 Lux
(
B/W)
0.5 Lux
(Colour)
X
1/3” CCD
(B/W)
1
/4” CCD
(Colour)
Designed to look just like a standard PIR
Alarm Sensor but fitted with a hidden
camera inside for covert viewing.
The PC810D has a Sony 1/3" CCD image
sensor for B/W 480 TVL resolution images
and 0.3 lux low light sensitivity and the
PC811D has a Sony 1/4" CCD image sensor
for Colour 420
TVL resolution images and 0.5
lux low light sensitivity
Both cameras feature an X-vision IXC1
Digital Signal Processing (DSP) chip which
has been optomised for internal viewing and
features
Automatic Gain Control, Automatic
Electronic Iris, Auto White Balance, Back Light
Compensation, Low Smear and Edge
Enhancement,
the PC811D also features Zero
Colour Rolling
3.7mm focus free pinhole lens for 78°
viewing angle on the PC810D and 60
°
viewing angle on the PC811D
Designed for internal use and wall or ceiling
mounting
2 Year Manufacturers Warranty
Covert CamerasModel: PC810D/811D
Features
The PC810D and PC811D 'PIR' cameras are designed for covert
use in medium to high risk applications
.
They look like a standard
PIR Alarm Sensor but have a hidden camera in side. The PC810D
offers high resolution B/W 480 TVL images from its Sony 1/3"
CCD sensor and will provide images in light levels as low as 0.3
lux and the PC811D offers high resolution Colour 420
TVL images
from its Sony 1/4" CCD sensor and will provide images in light
levels as low as 0.5 lux. Both are designed for internal use and
wall or ceiling mounting.
B/W (Sony 1/3” CCD) & Colour (Sony
1/4” CCD) 'PIR' Cameras
PC810D/811D
480 TVL
(B/W)
420 TVL
(Colour)
78º Lens
(B/W)
60º Lens
(Colour)
0.3 Lux
(B/W)
0.5 Lux
(Colour)
X
1/3” CCD
(B/W)
1/4” CCD
(Colour)
