Specifications

Connections
Signal Type: B/W and Colour
Display/Recording Type: Quad
Camera Inputs: 4
Audio Inputs: 0
Monitor Outputs:
2
Operating
V
oltage: 12V DC 1250mA
Suggested Power Supply: Supplied
Specifications
Connections
32
Designed for use with 2 to 4 (2 to 8 on
P
S108) B/W or Colour cameras
Switches video and audio signals
M
anual selection of each camera and
bypassing of each camera is possible
F
eatures automatic switching with adjustable
dwell time
I
ndustry standard BNC sockets for video and
monitor out signals and Phono sockets for
a
udio signals
Built in power supply and can be directly
p
owered from an AC outlet
Recommended for use with our XVCR960P
C
CTV Video Recorder
1 Year Manufacturers Warranty
Analogue Control
M
odel:
PS104/PS108
Analogue Control
Model: PCQ101E
Features
The PS104 & PS108 switchers are designed for use with 2 to 8 cameras and
allows you to view and record audio and video signals from up to 8
cameras on to a single monitor or recorder. They allow manual selection of
each camera or automatic switching of the connected cameras with an
adjustable dwell time. They feature a built in power supply & can be directly
powered from an AC outlet. Their casing is constructed from metal for extra
durability & they are recommended for use in low risk applications.
4 /8 Camera Switcher Units
PS104/108
Designed for use with up to 4 B/W or Colour
cameras
Compresses the images from the cameras in to
a high resolution picture in picture, 1 main and
3 small, and real time quad image, allowing all
the cameras to be viewed and recorded
together on one monitor or recorder
F
eatures dual outputs
, monitor out which
allows you to view a quad image
,
automatic
switching of cameras or each camera full
screen,
and a
VCR out which shows a
permanent quad image
.
Digital zoom on playback for w
atching
cameras full screen from recorded quad images
On screen time, date and camera title display
4 alarm inputs and alarm output for
connection to sensors and external devices
Supplied with a high quality power supply for
powering from an AC socket
Industry standard BNC sockets
Recommended for use with our XVCR960P
CCTV Video Recorder
1 Year Manufacturers Warranty
Features
The PCQ101E high resolution colour quad unit is designed for low to medium
risk applications and features real time picture in picture
,
1 main & 3 small,
and quad displays of up to 4 B/W or Colour cameras
.
It features dual outputs
,
monitor out which allows you to view a picture in picture, 1 main and 3
small, and quad image, automatic switching of cameras or each camera full
screen, and a VCR out which shows a permanent quad image. In addition to
this it features digital zoom on playback for watching cameras full screen
from recorded quad images
,
time
,
date camera title display
, alarm inputs and
alarm output and is supplied with a 12V DC power supply for powering from
an AC socket. The casing is constructed from metal for extra durability.
Colour Picture In Picture &
Quad Unit
PCQ101E
Analogue Control
Equipment
Introduction
Even with the advent of Digital Recording we continue to manufacture a full range of high quality analogue control equipment, including 4
and 8 Camera Switcher units, a powerful 4 Camera Quad unit and a range of 4, 8 and 16 Camera multiplexers.
New for 2006 is the sub compact XVCR960P, CCTV Recorder which features both Real Time and Time Lapse recording and dual voltage AC &
D
C voltage operation.All models will operate with both B/W & Colour CCTV Systems and are simple to use whilst offering a host of features.
S
ignal Type: B/W and Colour
Display/Recording Type: Switching
C
amera Inputs: 4 (PS104)
8
(PS108)
Audio Inputs: 4/8
M
onitor Outputs: 1
O
perating Voltage: 220-240V AC
Suggested Power Supply: Supplied
Specifications
A
ll connections are industry standard BNC type
