Specifications

37
Real Time Live Display of up to 16 cameras
Real Time recording of up to 4 cameras on the TDVR4 (4 camera
version) and up to 100 fps recording on the TDVR8 (8 camera
version) and TDVR16 (16 camera version)
DVD quality recording
Supports up to 400GB recording on the TDVR4 and 800GB on the
TDVR8 and TD
VR16 and uses MJPEG compr
ession for 3 times the
recording time of an equivalent sized Wavelet compression DVR
Triplex operation for multi screen recording and playback
independently of live viewing selection, and playback of recordings
whilst continuing to record
Easy back up to USB Memory Stick on all models and to CD on the
TDVR8 and TDVR16
Password Protection for preventing unauthorised access
Networking/Internet Access for remote live viewing and playback
of camer
a recordings
DVR RangeModel: TDVR4/9/16
Main Features
Main Features in detail:
The TDVR professional DVR range is designed for medium to high risk applications and offers the perfect balance of cost versus performance. Standard features include DVD
quality recording for identification quality images, 100 fps recording for medium to high risk applications, triplex recording for uninterrupted recording even when playing
back recordings, networking/internet access for remote viewing of cameras and playback of recordings, IR Remote Control for ease of use and independent backing up of
recordings to USB memory stick or CD (depending on model). Powerful, simple to install and use, the TDVR range is our most popular DVR.
Live Viewing Features
Full and Multi Screen Display: During live viewing on the TDVR4 (4 camera version) it is possible to view each camera full screen as a picture in picture or all 4 as a quad
image, in addition to this on the TDVR8 (8 camera version) the cameras can also be viewed as an 8 camera cameo, and on the TDVR16 (16 camera version) as a 16 camera
cameo also.
Real
Time Live Display:
On all models the cameras are displayed in real time for smooth movement in all displays views and at 720x 576 resolution for excellent quality
when in full screen.
Audio: All models have 1 audio input which can be monitored live during live viewing.
Pan Tilt Zoom & Speed Dome Control: The TDVR range features Pan Tilt Zoom control of Pelco D & P protocol cameras and speed domes.
Standar
d & VGA Monitor Support:
All models have 2 standard BNC sock
ets for video outputs to 2 CCTV monitors, & optional VGA output for connection to a PC monitor
by adding the BNCV
GA adaptor. In addition to this the TDVR8 and TDVR16 have an SVHS input for enhanced picture quality when used with SVHS compatible CCTV monitors.
Network/Internet Live Viewing: Live viewing is also possible from a compatible Windows PC which is connected to the TDVR range via a local network or the internet.
During live viewing by PC on the TDVR4 (4 camera version) it is possible to view each camera full screen as a picture in picture or all 4 as a quad image, in addition to this on
the TDVR8 (8 camera version) the cameras can also be viewed as an 8 camera cameo, and on the TDVR16 (16 camera version) as a 16 camera cameo also.
Recording
Real Time Recording The TDVR4 features real time recording at 360x288 resolution allowing it record in real time. The TDVR8 and TDVR16 record at near real time with 100
fps shared between all cameras
.
Removable Har
d Drive:
T
he
TDVR4 features a removable hard drive which can be swapped for a second drive when full for longer recording times if the recycle recordings
function is not used and can also be played back on a PC using the TDVRUSBR PC Playback Adaptor. The TDVR8 and TDVR16 do not have a removable hard drive they have two
internal hard drive bays.
Near DVD Quality Recor
ding:
All models have a near DVD quality recording option which is 720x288 resolution recording.
In this mode they will record at 50fps shared
between all cameras.
MJPEG Compression: The TDVR range uses MJPEG compression for the highest quality picture recording and lower file size when compared with wavelet compression.
Recording times are up to 3 times longer than equivalent wavelet times. Up to 4 different recording qualities and 6 different fps recording speeds can be set allowing the user to
adjust the quality and speed to achieve the best balance of recording time and picture quality
Audio Recording: As well as camera images the
TDVR range will also record 1 audio input.
Triplex Recording: The triplex recording feature of the
TDVR range allows the user to select any camera full screen or as a multiscreen layout during live viewing without
disturbing the recording of all cameras as full screen images. It also allows the user to playback recordings without having to stop current recordings, so that recordings are not
interrupted.
Triplex 4/8/16 Camera DVRs with
Network/Internet Access & Optional CD
TDVR4/8/16
