WiringCat5 Wiring

Cat 5 wiring (also known as structured cabling) is increasingly being used as an alternative to standard wiring, the main reason is that many commercial buildings have spare

Cat 5 cables running through the building and the majority of new buildings have Cat 5 run throughout the building. Cat 5 wiring uses convertors in place of connectors at the

ends of the Cat 5 Cable, these convertors convert picture, power, audio and RS485 data to a format which can be carried by Cat 5 cable and then convert them back again. Cat

5 wiring can be run up to a maximum of 1500 metres.We recommend this type of wiring in situations where Cat 5 cable is already run or where there is a need for very long

or versatile cable runs and for future proofing.

Microphones

ideo Signal Distributor

s &

Amplifier

Power Cables

Model: C5V

ingle Input Video Signal/Data to CAT5

onverter dongle

This converts the video output of a camera and data line to

a CAT 5 compatible signal, allowing it to be run down a

single twisted pair of a CAT 5 cable, it can then be

converted back at the viewing end by using another C5V

or a C5V4.

Model: C5V4

Input Video Signal/Data to CAT5

onverter

This converts the video outputs of up to four cameras or 3

cameras and a data line to a CAT 5 compatible signal,

allowing four cameras to be run down a single CAT 5

cable, it can then be converted back at the viewing end by

using up to four C5V baluns or a single C5V4 balun.

Model: AUDIO

Internal Camera Microphone

A microphone hidden in a cable.Adds audio to any internal camera

with the high quality microphone. Connects to the BNC and DC

socket on the camera and adds audio.

Model: AUDIOEXT

External Camera Microphone

Weatherproof Connection Box with microphone inside.Adds audio

to any external camera, the microphone is located inside the box

making it suitable for external use.

Model: C5VP

Single Input Video

Signal/Power/Data to

CAT5 converter (includes

transmitter & receiver)

Converts the video output of a

amera to a CAT 5 compatible

signal and allows power to be

sent down the CAT 5 to power

the camera, two baluns are

supplied one for the camera end

and one for the viewing end

which is where the camera power

supply needs to be plugged in.

Model: C5VADLR

Single Input Long

Range Video/Audio/Data

to CAT5 converter.

Includes transmitter

and receiver units and

power supplies

This converts the video and audio

output of a camera and data line

to a CAT 5 compatible signal,

allowing the camera to be run

down one CAT 5 cable, two baluns

are supplied one for the camera

end and one for the viewing end.

Model: C5SC

Video Signal Corrector

for C5V, C5V4 and C5VP

Video Signal Corrector for C5V,

C5V4 and C5VP dongles. Helps

remove interference from the

camera picture that may be

picked up by the CAT5 pair from

other cables and signals

Model: VIDAMP

Single camera 12V DC

300ma power supply

1 Video Input to 4 Video Output

Distributor. 1 Year Guarantee

Model: VIDAMPPRO

4 Video Input to 8 Video

Output Amplifier &

Distributor

4 Video Input to 8 Video Output

Amplifier & Distributor

All 4

video inputs has 2 video outputs.

Model: VIDAMP16

8 Video Input to 16

Video Output

Distributor

8 Video Input to 16 Video Output

Distributor. Each of the 8 video

inputs has 16 video outputs.

Data Protection Act Compliance Products

Model: WS

CCTV In Use A4 Warning Sign

Laminated, Heavy Duty and Weatherproof CCTV In Use A4

arning Sign.

Model: LVCD

Locking Video Cassette Dispenser

Model: LCC1

Locking Case

The LCC1 locking case has been specially designed for

use with X-vision DVRs and allows the DVR to be locked

in a strong metal locable case, whilst allowing good

airflow so the unit is not at risk of overheating. Ideal for

preventing unauthorised access to the DVR.

Model: DPACP

Data Protection Act Compliance Pack
