Installation Sheet

1. Carefully remove all parts from the box.

2. Remove the mounting plate (B) from the fixture body (E) by loosening side screws (C).

3. Affix mounting plate (B) onto the outlet box and secure with mounting screws (D).

4. Connect the hot wire (BLACK) from the fixture to the hot wire from the outlet box

(usually BLACK). Fasten them together with a plastic wire connector (A) provided

and wrap the connection with electrical tape.

5. Connect the neutral wire (WHITE) from the fixture to the wire from the outlet box

(usually WHITE).

DO NOT REVERSE THE HOT AND NEUTRAL CONNECTIONS OR SAFETY WILL

BE COMPROMISED.

6. Connect ground wire from the fixture (bare copper) to ground wire from the outlet box

(usually green or copper in color).

IT IS IMPERATIVE THAT THIS FIXTURE BE GROUNDED.

7. Attach the fixture body (E) onto the mounting plate (B) and secure with side screws (C).

8. Insert bulbs (not included) into the socket (J & F).

9. Attach the glass frame (H) to the top of the fixture (H1).

10. Attach the glass frame (G) to the bottom of the fixture (G1).

Do not touch glass frame (H & G) and top cap (N & M),only hold bottom ring (K & L)

during assembly.

11. Installation is complete, turn on power at fuse or circuit breaker.

***Clean with a dry, soft cloth only. Use no harsh abrasives or chemical agents.

Allen Double Light Sconce

Item # RL 2082

WE RECOMMEND INSTALLATION OF THIS LIGHTING FIXTURE BE DONE BY A

LICENSED ELECTRICIAN.

WARNING***SWITCH OFF THE MAIN ELECTRICAL SUPPLY FROM THE MAIN

FUSE BOX/CIRCUIT BREAKER BEFORE INSTALLATION.

INSPECT ITEM CAREFULLY BEFORE ATTEMPTING TO INSTALL. IF THERE IS ANY

DAMAGE OR OBVIOUS DEFECT. DO NOT INSTALL.

ITEM MAY NOT BE RETURNED ONCE IT HAS BEEN INSTALLED.

NOTE: CAREFULLY UNPACK EACH PIECE IN TOP LAYER OF PACKING PRIOR TO

REMOVING. RETAIN ALL PACKING MATERIAL UNTIL INSPECTION AND

INSTALLATION ARE FINAL.

DAMP

Outlet Box

D E

A B

Bulb

(Not included)
