Network Camera User's Manual

ManualsBrandsVivotek ManualsSecurity CameraFD7141(V)

Summary of content (132 pages)

PAGE 1
PAGE 2
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Table of Contents Overview ��3 Read before use ��3 Package contents ��
PAGE 3
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Overview VIVOTEK FD7141(V) is a professional vandal- and weather-proof fixed dome network camera, integrating all elements needed for outdoor security into a discreet, compact package. FD7141(V) is not only able to be shielded from dust and water with the IP-66 rated housing, but also fitted in high-risk environment by the structure of vandal resistant.
PAGE 4
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Physical description Inner View f= 3.3~12 mm (FD7141 Lens) f= 9~22 mm (FD7141V Lens) Tilt screw Lens Light sensor IR LEDs SD card slot Pan screw Status LED Image adjustment screw Indented reset button Focus controller Zoom controller N.C. N.C. N.C.
PAGE 5
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Outer View Dome cover N.C. N.C. N.C. V AC24 V AC24 Camera base c b a Bottom base c Keep a note of the MAC address under the camera base before installing the camera. Network Camera Model No: FD7141 RoHS V I MAC:0002D1083236 a Hole a~c: Holes for ceiling mount or for attaching the bottom base. This device complies with part 15 of the FCC rules.
PAGE 6
VIVOTEK - A Leading Provider of Multimedia Communication Solutions General I/O Terminal Block This Network Camera provides a general I/O terminal block which is used to connect external input / output devices. The pin definitions are described below. N.C. N.C. N.C. AC24V AC24V GND DI DO +12V Pin N.C. N.C. N.C. AC24V AC24V GND DI DO +12V Name No Connector No Connector No Connector Power in AC 24V Power in AC 24V Ground Digital Iutput Digital Output Power +12V N.C.: No Connector N.C.: No Connector N.C.
PAGE 7
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Hardware Reset Reset button Status LED The reset button is used to reset the system or restore the factory default settings. Sometimes resetting the system could set the system back to normal state. If the system problems remain after reset, restore the factory settings and install again. Reset: Press and release the indented reset button with a needle. Wait for the Network Camera to reboot.
PAGE 8
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Installation Hardware installation First, use a screwdriver to loose three screws and detach the dome cover from the camera base. Then, follow the steps below to install the camera; either to a ceiling or to a wall. N.C. N.C. N.C. V AC24 V AC24 Ceiling mount with the bottom base 1. Attach the supplied Alignment sticker to the ceiling. 2.
PAGE 9
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Wall mount with the bottom base 1. Attach the supplied Alignment sticker to the wall. 2. Through the 10 circles on the sticker, drill 2 pilot holes symmetrically on each side into the wall. Then Hammer the supplied four plastic anchors into the holes. 3. Through four holes on the bottom base, insert the supplied four screws to corresponding holes and secure the bottom base with a screwdriver. 4. Feed the cables through hole A or B.
PAGE 10
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Ceiling mount without the bottom base (Embedded) 1. Attach the supplied Ceiling Hole Template Sticker to the wall. 2. Dig a hole along the inner circle of the sticker. 3. Through the 3 circles on the sticker, drill 3 pilot holes into the ceiling. Then hammer the supplied three plastic anchors into the holes. 4. Mount the Network Camera to the ceiling and feed the cables. 5.
PAGE 11
VIVOTEK - A Leading Provider of Multimedia Communication Solutions There are several ways to setup the Network Camera over the Internet. The first way is to setup the Network Camera behind a router. The second way is to utilize a static IP. The third way is to use PPPoE. Internet connection via a router Before setting up the Network Camera over the Internet, make sure you have a router and follow the steps below. 1.
PAGE 12
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Internet connection via PPPoE (Point-to-Point over Ethernet) Choose this connection type if you are connected to the Internet via a DSL Line. Please refer to PPPoE on page 37 for details. Set up the Network Camera through Power over Ethernet (PoE) When using a PoE-enabled switch The Network Camera is PoE-compliant, which allows it to be powered via a single Ethernet cable.
PAGE 13
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Software installation Installation Wizard 2 (IW2), free-bundled software packaged in the product CD, helps to set up your Network Camera in LAN. 1. Install the IW2 under the Software Utility directory from the software CD. Double click the IW2 shortcut on your desktop to launch the program. 2. The program will conduct analyses on your network environment. After your network environment is analyzed, please click Next to continue the program.
PAGE 14
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Ready to use 1. Access to the Network Camera from the Internet. 2. Retrieve live video through web browsers or recording software. Please refer to page 16 for detailed information. http://192.168.5.109/index.html Adjusting the Lens Based on the live image retrieved from the camera, adjust the camera lens by doing the following: To adjust the viewing angle 1. Loosen the pan screw and then turn the lens module left and right.
PAGE 15
VIVOTEK - A Leading Provider of Multimedia Communication Solutions To adjust the zoom factor and focus range 1. Loosen the zoom controller and then adjust zoom factor by moving the controller left and right. Upon completion, tighten the zoom controller. 2. Loosen the focus controller and then adjust focus range by moving the controller left and right. Upon completion, tighten the focus controller. Loosen W N 8 Tighten T DO NOT over tighten the controllers.
PAGE 16
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Accessing the Network Camera This chapter explains how to access the Network Camera through web browsers, RTSP players, 3GPP-compatible mobile devices, and VIVOTEK recording software. Using web browsers Make use of Installation Wizard 2 (IW2) to access to the Network Cameras in LAN. If your network environment is not in LAN, follow the steps to access the Network Camera: 1. Launch your web browser (ex.
PAGE 17
VIVOTEK - A Leading Provider of Multimedia Communication Solutions ► By default, the Network Camera is not password-protected. To prevent unauthorized accesses, it is highly recommended to set a password for the Network Camera. For more information about how to enable password protection, please refer to Security on page 30. ► If you see a dialog box indicating that your security settings prohibit running ActiveX ® Controls, please enable your ActiveX® Controls for your browser. 1.
PAGE 18
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Using RTSP players To view the MPEG-4 streaming media using RTSP players, you can use one of the following players that support RTSP streaming. Quick Time Player Real Player VLC media player 1. Launch a RTSP player. mpegable Player 2. Choose File > Open URL. An URL dialog box will pop up. 3.
PAGE 19
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Using 3GPP-compatible mobile devices To view the streaming media through 3GPP-compatible mobile devices, make sure the Network Camera can be accessed from the Internet. For more information on how to set up the Network Camera over the Internet, please refer to Setup the Network Camera over the Internet on page 10. To utilize this feature, please check the following settings on your Network Camera: 1.
PAGE 20
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Using VIVOTEK recording software The product software CD also contains recording software, allowing simultaneous monitoring and video recording for multiple Network Cameras. Please install the recording software; then launch the program to add the Network Camera to the Channel list. For detailed information about how to use the recording software, please refer to the user’s manual of the software or download it at http://www.vivotek.com.
PAGE 21
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Main Page This chapter explains the layout of the main page. It is composed of the following sections: Logo of VIVOTEK INC., Host name, Camera control panel, Menu, and Live video window. Logo of VIVOTEK INC. Host name Camera control area Live view window Configuration area Logo of VIVOTEK INC. Click this logo to visit VIVOTEK website. Host name The host name can be customized to fit your needs.
PAGE 22
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Live Video Window ■ The following window is displayed when the video mode is set to MPEG-4: MPEG-4 protocol and media options Video title Title and time Time Video 10:11:50 2008/01/09 Video and audio control buttons Video title: The video title can be configured. For more information, please refer to Video settings on page 52. MPEG-4 protocol and media options: The transmission protocol and media options for MPEG-4 video streaming.
PAGE 23
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Volume: When the local computer. Mute function is not activated, move the slider bar to adjust the volume at Mute: Turn off the volume at local computer. The button becomes the Mute button. Audio on button after clicking Talk: Click this button to talk to people around the Network Camera. Audio will come out from the again to stop talk. external speaker connected to the Network Camera.
PAGE 24
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Start MP4 recording: Click this button to record video clips in MP4 file format to your computer. Press Stop MP4 recording button to end recording. When you quit the web browser, video recording the stops accordingly. To specify the storage destination and the file name, please refer to MP4 Saving Options on page 26 for details. Full Screen: Click this button to switch to full screen mode. Press “Esc” key to switch back to normal mode.
PAGE 25
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Client Settings This chapter explains how to select the stream transmission mode and saving options at local computer. When completed with the settings on this page, click Save on the page bottom to take effect. MPEG-4 Media Options Select to stream video or audio data. This works only when the video mode is set to MPEG-4.
PAGE 26
VIVOTEK - A Leading Provider of Multimedia Communication Solutions MP4 Saving Options Users can record the live video as they are watching it by clicking page. Here, you can specify the storage destination and file name. Start MP4 Recording on the main Folder: Specify a storage destination for the recorded video files. File Name Prefix: Enter the text that will be put in front of the video file name.
PAGE 27
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Configuration Click Configuration on the main page will enter the camera setting pages. Note that only Administrators can access the configuration page. VIVOTEK offers an easy-to-use user interface that helps you setup your network camera without much efforts. To simplify the setting procedure, VIVOTEK designs two kinds of user inferface-advanced mode for professional users and basic mode for entry-level users.
PAGE 28
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Advanced mode Configuration list Click to switch to Basic mode Firmware Version Each function on the configuration list will be explained in the following sections. Those functions that only show in Advanced mode are marked with Advanced mode . If you want to set up advanced functions, please click [Advanced mode] on the bottom of the configuration list to quickly switch to Advanced mode.
PAGE 29
VIVOTEK - A Leading Provider of Multimedia Communication Solutions System Time Keep current date and time: Select this option to reserve the current date and time of the Network Camera. The Network Camera’s internal real-time clock maintains the date and time even when the power of the system is turned off. Sync with computer time: Select this option to synchronize the date and time of the Network Camera with the local computer. The read-only date and time of the PC is displayed as updated.
PAGE 30
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Security This section explains how to enable password protection and create multiple accounts. Root Password The administrator account name is “root”, which is permanent and can not be deleted. If you want to add more accounts in Manage User column, please apply a password for the “root” account first. 1. Type the password identically in both text boxes, and click Save to enable password protection. 2.
PAGE 31
VIVOTEK - A Leading Provider of Multimedia Communication Solutions HTTPS Advanced mode This section explains how to enable authentication and encrypted communication over SSL. It helps protect streaming data transmission over the Internet. Enable HTTPS Check this item to enable HTTPS communication, and then select a connection option: "HTTP & HTTPS" or "HTTPS only". Note that you have to create and install certificate first in the second column before clicking the Save button.
PAGE 32
VIVOTEK - A Leading Provider of Multimedia Communication Solutions 4. The Certificate Information will automatically show up in the third column as below. You can click Property to see the detailed information of the certificate. 5. Click Home to return to the main page. Change the address from “http://” to “https://“ on the Address bar and press Enter on your keyboard. Some Security Alert dialogs will pop up. Click OK or Yes to enable HTTPS. https:// https://192.168.5.151/index.
PAGE 33
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Create self-signed certificate manually 1. Select this option. 2. Click Create to open a Create Certificate page, and then click Save to generate the certificate. 3. The Certificate Information will automatically show up in the third column as below. You can click Property to see the detailed information of the certificate. 4. Please refer to step 5. on last page.
PAGE 34
VIVOTEK - A Leading Provider of Multimedia Communication Solutions 3. If you see the following Information Bar, click OK and the menu bar on the top of the page to allow the Pop-ups. 4. The Pop-up window shows an example of a certificate request.
PAGE 35
VIVOTEK - A Leading Provider of Multimedia Communication Solutions 5. Look for a trusted certificate authority that issues digital certificates. Enroll the Network Camera. Wait for the certificate authority to issue a SSL certificate; click Browse... to search for the issued certificate, then click Upload in the second column. 6. Please refer to step 4. and 5. on page 32. NOTE ► How to cancel HTTPS settings? 1.
PAGE 36
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Network This section explains how to configure wired network connection for the Network Camera. Network Type LAN Select this option when the Network Camera is deployed in a local area network (LAN) and is intended to be accessed by local computers. The default setting of Network Type is LAN. Remember to click Save when you complete the Network setting.
PAGE 37
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Network Camera (192.168.5.151) Enable UPnP port forwarding: To access the Network Camera from the Internet, select this option to allow the Network Camera to open ports on the router automatically so that video streams can be sent out from a LAN. To utilize of this feature, make sure that your router supports UPnPTM and it is activated.
PAGE 38
VIVOTEK - A Leading Provider of Multimedia Communication Solutions 1. Go to Start, click Control Panel, and then click Add or Remove Programs. 2. In the Add or Remove Programs dialog box, click Add/Remove Windows Components. 3. In the Windows Components Wizard dialog box, select Networking Services and then click Details.
PAGE 39
VIVOTEK - A Leading Provider of Multimedia Communication Solutions 4. In the Networking Services dialog box, select Universal Plug and Play and then click OK. 5. Click Next in the following window. 6. Click Finish. UPnP TM is enabled. ► How does UPnP TM work? UPnP TM networking technology provides automatic IP configuration and dynamic discovery of devices added to a network.
PAGE 40
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Enable IPv6 Select this option and then click Save to enable IPv6 settings. Please note that it only works if your network environment and hardware equipment support IPv6. As for the web browse, you have to update to Microsoft® Internet Explorer 6.5, Mozilla Firefox 3.0 or above. When IPv6 is enabled, by default, the network camera will listen to router advertisements and be assigned with a link-local IPv6 address accordingly.
PAGE 41
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Please follow the steps below to link to IPv6 address: 1. Open your web browser. 2. Enter the link-global or link-local IPv6 address to the address bar of your web browser. 3. The format should be: http://[2001:0c08:2500:0002:0202:d1ff:fe04:65f4]/ IPv6 address 4. Press Enter on the keyboard or click Refresh button to refresh the webpage.
PAGE 42
VIVOTEK - A Leading Provider of Multimedia Communication Solutions HTTP Advanced mode To utilize the HTTP authentication, make sure that your have set a password for the Network Camera first; please refer to Security on page 30 for details. Authentication: Depending on your network security requirements, the Network Camera provides two types of security settings for a HTTP transaction: basic and digest.
PAGE 43
VIVOTEK - A Leading Provider of Multimedia Communication Solutions URL command -- http://:/ For example, when the Access name for stream 2 is set to video2.mjpg: 1. Launch Mozilla Firefox or Netscape. 2. Type the URL command in the address bar. Press Enter. 3. The JPEG images will be displayed in your web browser. http://192.168.5.151/video2.
PAGE 44
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Note that as JPEG only transmits a series of JPEG images to the client, to enable two-way audio function, make sure the video mode is set to “MPEG-4” on Audio and Video settings page and the media option is set to “Video and Audio” on the Client Settings page. Please refer to Client Settings on page 25 and Audio and Video Settings on page 52.
PAGE 45
VIVOTEK - A Leading Provider of Multimedia Communication Solutions RTSP Streaming To utilize the RTSP streaming authentication, make sure that your have set a password for the Network Camera first; please refer to Security on page 30 for details. Authentication: Depending on your network security requirements, the Network Camera provides three types of security settings for streaming via RTSP protocol: disable, basic and digest.
PAGE 46
VIVOTEK - A Leading Provider of Multimedia Communication Solutions RTSP port /RTP port for video, audio/ RTCP port for video, audio The RTSP (Real-Time Streaming Protocol) controls the delivery of streaming media. By default, the port number is set to 554. ■ The RTP (Real-time Transport Protocol) is used to deliver video and audio data to the clients. By default, the RTP port for video is set to 5556 and the RTP port for audio is set to 5558.
PAGE 47
VIVOTEK - A Leading Provider of Multimedia Communication Solutions DDNS This section explains how to configure dynamic domain name service for the Network Camera. DDNS is a service that allows your Network Camera, especially when assigned with a dynamic IP address, to have a fixed host and domain name. DDNS: Dynamic domain name service Enable DDNS: Select this option to enable the DDNS setting. Provider: Select a DDNS provider from the Provider drop-down list. VIVOTEK offers Safe100.
PAGE 48
VIVOTEK - A Leading Provider of Multimedia Communication Solutions [Register] Successfully Your account information has been mailed to registered e-mail address 4. Select Enable DDNS and then click Save to take effect. ■ CustomSafe100 VIVOTEK offers documents to establish CustomSafe100 DDNS server for distributors and system integrators. You can use CustomSafe100 to register a dynamic domain name if your distributor or system integrators offer such services. 1.
PAGE 49
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Access list Advanced mode This section explains how to control the access permission by checking the client PC’s IP addresses. General Settings Maximum number of concurrent streaming connection(s) limited to: Simultaneous live viewing for 1~10 clients (including stream 1 and stream 2). The default value is 10.
PAGE 50
VIVOTEK - A Leading Provider of Multimedia Communication Solutions ■ Refresh: Click this button will refresh all current connections. ■ Add to deny list: You can check some items on the connection status list, and then click this button to add them to the denied list. Please note that those checked connections will only be disconnected temporarily, but will automatically try to re-link again (IE Explore or Quick Time Player).
PAGE 51
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Network: This rule is for user to assign a Network address and corresponding subnet mask to Allow/Deny list. For example: IP address 192.168.2.x will be bolcked. Range: This rule is for user to assign a range of IP address to Allow/Deny list. This rule is only applied to IPv4. For example: ■ Delete Allowed/Denied list: In the Delete allowed list or Delete denied list column, select a list from the list and then click Delete to delete it.
PAGE 52
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Audio and video This section explains how to configure audio and video performances of the Network Camera. It is composed of the following two columns: Video settings and Audio settings. Video Settings Video title: Enter a name that will be displayed on the title bar of the live video. Video title Color: Select to display colorful or black/white video streams.
PAGE 53
VIVOTEK - A Leading Provider of Multimedia Communication Solutions 17:08:56 2008/06/25 Image Settings Advanced mode Click Image settings to open the Image Settings page. In this page, you can tune White balance, Brightness, Saturation, Contrast, and Sharpness for video compensation. White balance: Adjust the value for best color temperature. ■ Auto The Network Camera automatically adjusts the color temperature of light in response to different light sources.
PAGE 54
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Image Adjustment ■ Brightness: Adjust the image brightness level, which ranges from -5 to +5. The default value is set to 0. ■ Saturation: Adjust the image saturation level, which ranges from -5 to +5. The default value is set to 0. ■ Contrast: Adjust the image contrast level, which ranges from -5 to +5. The default value is set to 0. ■ Sharpness: Adjust the image sharpness level, which ranges from -3 to +3. The default value is set to +3.
PAGE 55
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Sensor Settings Advanced mode Click Sensor Settings to open the Sensor Settings page. In this page, you can set the maximum exposure time, exposure level, AGC, and WDR (Wide Dynamic Range) settings. You can configure two sets of sensor settings: one for normal situation; the other for special situation, such as day/night/schedule mode.
PAGE 56
VIVOTEK - A Leading Provider of Multimedia Communication Solutions If you want to configure another sensor setting for day/night/schedule mode, please click Profile to open Sensor Settings Profile Settings page as below. Please follow the steps beolw to setup a profile: 1. Check Enable this profile. 2. Select the applied mode: Day mode, Night mode, or schedule mode. Please manually enter a range of time if you choose Schedule mode. 3. Configure Exposure settings in the second column.
PAGE 57
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Video quality settings for stream 1 / stream 2 Advanced mode The Network Camera offers two choices of video compression standards for real-time viewing, so you can choose MPEG-4 or MJPEG for dual streams. Click the items to display the detailed configurations. You can set up two seperate streams for the Network Camera for different viewing devices.
PAGE 58
VIVOTEK - A Leading Provider of Multimedia Communication Solutions ■ Intra frame period Determine how often to plant an I frame. The shorter the duration, the more likely you will get a better video quality, but at the cost of higher network bandwidth consumption. Select the intra frame period from the following duration: 1/4 second, 1/2 second, 1 second, 2 seconds, 3 seconds and 4 seconds.
PAGE 59
VIVOTEK - A Leading Provider of Multimedia Communication Solutions IR cut filter With a removable IR-cut filter and built-in IR illuminators, up to 15m, this Network Camera can automatically remove the filter and turn on the IR illuminators to let IR light into the sensor for low light sensitivity. ■ Auto The Network Camera automatically removes the filter by judging the level of ambient light.
PAGE 60
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Motion detection This section explains how to configure the Network Camera to enable motion detection. A total of three motion detection windows can be configured. Video(TCP-AV) Motion Detection Setting 1: for normal situation Motion Detection Setting 2: for special situation Follow the steps below to enable motion detection: 1. Click New to add a new motion detection window. 2.
PAGE 61
VIVOTEK - A Leading Provider of Multimedia Communication Solutions A green bar indicates that even though motions are detected, the event will not be triggered because the image variations are still falling under the defined threshold. Percentage = 30% If you want to configure another motion detection setting for day/night/schedule mode, please click Profile to open Motion Detection Profile Settings page as below. A total of three motion detection windows can be configured on this page, too.
PAGE 62
VIVOTEK - A Leading Provider of Multimedia Communication Solutions NOTE ► How does motion detection work? A C B D There are two parameters for setting the motion detection: Sensitivity and Percentage. In the illustration above, frame A and frame B are two sequential images. Pixel differences between the two frames are detected and highlighted in gray (frame C), and will be compared with the sensitivity setting. Sensitivity is a value that expresses the sensitivity to moving objects.
PAGE 63
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Camera tampering detection This section explains how to set up camera tempering detection. With the tampering detection, it is capable of detecting incidents such as shooting redirection, blocking or defocusing of cameras, or even spray-painted. Please follow the steps below to set up camera tampering detection function: 1. Check Enable camera tampering detection. 2. Enter the tampering trigger duration. (10 sec. ~ 10 min.
PAGE 64
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Homepage layout Advanced mode This section explains how to set up your own customized homepage layout. Preview This column shows the settings of your homepage layout. You can manually setup the background and font colors in Theme Options, the third column on this page. The settings will automatically show up in this Preview column. Following shows the default setting. Logo graph Here you can change the logo on the top of your homepage.
PAGE 65
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Theme options Here you can change the color of your homepage layout. There are three kinds of preset patterns for you to choose. The new layout will simultaneously present in the Preview column. Click Save to enable the settings.
PAGE 66
VIVOTEK - A Leading Provider of Multimedia Communication Solutions ■ Follow the steps below to set up customized homepage: 1. Click Custom on the left column. 2. Click a blank you want to change color on the right column. color picker customed pattern 3. The palette window will pop up as below. 2 3 1 4 4. Drag the slider bar and click on the left square to select a desired color. 5. The selected color will show up in the corresponding blank and in the Preview column. 6.
PAGE 67
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Application Advanced mode This section explains how to configure the Network Camera to react in response to particular situations (event). A typical application is that when a motion is detected, the Network Camera sends buffered images to a FTP server or e-mail address as notifications. In the illustration, an event can be triggered by many sources, such as motion detection or external digital input devices.
PAGE 68
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Event Settings In the Event Settings column, click Add to open the Event Settings page. In this page, you can arrange three elements -- Trigger, Schedule and Action to plot an event. A total of 3 event settings can be configured. Event name: Enter a descriptive name for the event setting. Enable this event: Select this option to enable this event setting. Priority: Select the relative importance of this event (High, Normal, or Low).
PAGE 69
VIVOTEK - A Leading Provider of Multimedia Communication Solutions An event is an action initiated by user-defined trigger source; it is the causal arrangement of the following three elements: Trigger, Event Schedule, and Action. Trigger Also referred as the cause or stimulus, defines when to trigger the Network Camera. The trigger source can be configured to use the Network Camera’s built-in motion detection mechanism or external digital input devices.
PAGE 70
VIVOTEK - A Leading Provider of Multimedia Communication Solutions ■ Camera tampering detection This option allows the Network Camera to trigger during camera tampering detection. To enable this function, you need to configure Camera tampering detection first. Please refer to page 63 for detailed information. Event Schedule Specify the effective period for the event. ■ Select the days on weekly basis. ■ Select the time for recording in 24-hr time format.
PAGE 71
VIVOTEK - A Leading Provider of Multimedia Communication Solutions To plot an event with recorded video or snapshots, it is necessary to configure the server and media settings, so that the Network Camera will know what action shall be performed (send media files to which server) when a trigger is activated. ■ Add Server / Add Media Click Add Server to configure Server Settings. For more information, please refer to Server Settings on page 73. Click Add Media to configure Media Settings.
PAGE 72
VIVOTEK - A Leading Provider of Multimedia Communication Solutions When completed, click Save to take effect and then click Close to quit Event Settings page. The new event settings / server settings / media settings will appear in the event drop-down list on the Application page. Here is an example of Application page with an event setting: When the Event Status is ON, once an event is triggered by motion detection, the Network Camera will automatically send snapshots via e-mail.
PAGE 73
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Server Settings Click Add Server on Event Settings page to open the server setting page. In this page, you can specify where the notification messages will be send when a trigger is activated. A total of 5 server settings can be configured. Server name: Enter a descriptive name for the server setting. Server Type There are four choices of server types available: Email, FTP, HTTP, and Network storage.
PAGE 74
VIVOTEK - A Leading Provider of Multimedia Communication Solutions FTP: Select to send the media files to a FTP server when a trigger is activated. ■ Server address: Enter the domain name or IP address of the FTP server. ■ Server port By default, the FTP port server is set to 21. Also, it can be assigned with another port number between 1025 and 65535. ■ User name: Enter the login name of the FTP account. ■ Password: Enter the password of the FTP account.
PAGE 75
VIVOTEK - A Leading Provider of Multimedia Communication Solutions HTTP: Select to send the media files to a HTTP server when a trigger is activated. ■ URL: Enter the URL of the HTTP server. ■ User name: Enter the user name if necessary. ■ Password: Enter the password if necessary. To verify if the HTTP settings are correctly configured, click Test. The result will be shown in a pop-up window as below. If it works, you will also receive a test.txt file on the HTTP server.
PAGE 76
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Media Settings Click Add Media on Event Settings page to open the media settings page. In this page, you can specify what kind of media to send when a trigger is activated. A total of 5 media settings can be configured. Media name: Enter a descriptive name for the media setting. Media Type There are three choices of media types available: Snapshot, Video clip, and System log. Select the item to display the detailed configurations.
PAGE 77
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Video clip: Select to send video clips when a trigger is activated. ■ Source: Select to record video clips from stream 1 or stream 2. ■ Pre-event recording The Network Camera has a buffer area; it temporarily holds data up to a certain limit. Enter a number to decide how many seconds for video clips recording before a trigger is activated. Up to 9 seconds can be set. ■ Maximum duration Specify the maximal recording duration in seconds.
PAGE 78
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Recording notify message: Select to send a recording notify message when a trigger is activated. Following is an example of recording notify message (.txt file), which shows a list of deleted recorded data due to cycle recording. When completed, click Save to take effect and then click Close to quit this page. The new media settings will show up on the Event Settings page.
PAGE 79
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Click 20081120 to open the directory: The format is: HH (24r) Click to open the file list of that hour Click to do back to upper layer of the directory Click to delete some items Click to delete all recorded data The format is: File name prefix + Minute (mm) You can set up the File name prefix on Media Settings page. Please refer to page 76 for detailed information.
PAGE 80
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Recording Advanced mode This section explains how to configure the recording settings for the Network Camera. Recording Settings Insert your SD card and click to test if it works. NOTE ► Before setting up this page, please set up the Network Storage on the Server Settings page first. ► Please remember to format your SD card for the first time use. Please refer to page 88 for detailed information.
PAGE 81
VIVOTEK - A Leading Provider of Multimedia Communication Solutions If it works, you will also receive a test.txt file on the network storage server. 3. Enter a descriptive server name. 4. Click Save to finish the setting and click Close to quit the page. Recording Settings Click Add to open the recording setting page. In this page, you can define the recording source, recording schedule and recording capacity. A total of 2 recording settings can be configured.
PAGE 82
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Source: Select the recording source (stream 1 or stream 2). Recording Schedule: Specify the recording duration. ■ Select the days on weekly basis. ■ Select the time for recording in 24-hr time format. Destination: You can select the SD card or network storage you’ve setup for the recorded video files. Folder: This blank will only show up if you select a local storage SD card for local storage. Enter the folder name to store the media files.
PAGE 83
VIVOTEK - A Leading Provider of Multimedia Communication Solutions System log Advanced mode This section explains how to configure the Network Camera to send system log to the remote server as a backup. Remote Log You can configure the Network Camera to send the system log file to a remote server as a log backup. Before utilizing this feature, it is suggested to install a log-recording tool to receive system log messages from the Network Camera. For example, a tool -- Kiwi Syslog Daemon.
PAGE 84
VIVOTEK - A Leading Provider of Multimedia Communication Solutions View parameters Advanced mode The View parameters page lists the entire system’s parameters in alphabetical order. If you need technical assistance, please provide the information listed in this page.
PAGE 85
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Maintenance This chapter explains how to restore the Network Camera to factory default, upgrade firmware version, etc. Reboot This feature allows you to reboot the Network Camera, which takes about one minute to complete. When completed, the live video page will be displayed in your browser. The following message will show during the rebooting process.
PAGE 86
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Export / Upload Files Advanced mode This feature allows you to Export / Upload daylight saving time rules, custom language files, and setting backup files. Export daylight saving time configuration file: Click to set the starting time and ending time of DST. Follow the steps below to export: 1. In the Export files column, click Export to export a daylight saving time configuration file from the Network Camera. 2.
PAGE 87
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Upload daylight saving time rule: Click Browse… and specify the XML file to upload. If the incorrect date and time is assigned, you will see the following warning message when uploading the file to the Network Camera. The following message is displayed when attempting to upload an incorrect file format. Export language file: Click to export language strings.
PAGE 88
VIVOTEK - A Leading Provider of Multimedia Communication Solutions The following message is displayed when the upgrade is succeeded. The following message is displayed when you have selected an incorrect firmware file. Starting firmware upgrade... Do not power down the server during the upgrade. The server will restart automatically after the upgrade is completed. It will takes about 1 - 5 minutes. Wrong PKG file format Unpack fail SD settings Format SD card: Click the button to format SD card.
PAGE 89
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Appendix URL Commands of the Network Camera Overview For some customers who already have their own web site or web control application, Network Camera/ Video server can be easily integrated through convenient URLs. This section specifies the external HTTP based application programming interface. The HTTP based camera interface provides the functionality to request a single image, to control camera functions (PTZ, output relay etc.
PAGE 90
VIVOTEK - A Leading Provider of Multimedia Communication Solutions General CGI URL syntax and parameters CGI parameters are written in lower-case and as one word without any underscores or other separators. When the CGI request includes internal camera parameters, the internal parameters must be written exactly as they are named in the camera or video server. The CGIs are organized in function related directories under the cgi-bin directory. The file extension of the CGI is required.
PAGE 91
VIVOTEK - A Leading Provider of Multimedia Communication Solutions http:///cgi-bin/viewer/getparam.cgi?[] [&…] http:///cgi-bin/operator/getparam.cgi?[] [&…] http:///cgi-bin/admin/getparam.cgi?[] [&…] where the should be [_] or [.] If you do not specify the any parameters, all the parameters on the server will be returned.
PAGE 92
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Set server parameter values Note: The access right depends on the URL directory. Method: GET/POST Syntax: http:///cgi-bin/anonymous/setparam.cgi? = [&=…][&update=][&return=] http:///cgi-bin/viewer/setparam.cgi? = [&=…][&update=] [&return=] http:///cgi-bin/operator/setparam.
PAGE 93
VIVOTEK - A Leading Provider of Multimedia Communication Solutions \r\n where is =\r\n [] Only the parameters that you set and readable will be returned. Example: Set the IP address of server to 192.168.0.123 Request: http://myserver/cgi-bin/admin/setparam.cgi?network_ipaddress=192.168.0.123 Response: HTTP/1.0 200 OK\r\n Content-Type: text/html\r\n Context-Length: 33\r\n \r\n network.ipaddress=192.168.0.
PAGE 94
VIVOTEK - A Leading Provider of Multimedia Communication Solutions , … blank A blank string everything inside <> As description NOTE: The camera should prevent to restart when parameter changed.
PAGE 95
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Central Time, Mexico City, Saskatchewan -200: GMT-05:00 Eastern Time, New York, Toronto -201: GMT-05:00 Bogota, Lima, Quito, Indiana -160: GMT-04:00 Atlantic Time, Canada, Caracas, La Paz, Santiago -140: GMT-03:30 Newfoundland -120: GMT-03:00 Brasilia, Buenos Aires, Georgetown, Greenland -80: GMT-02:00 Mid-Atlantic -40: GMT-01:00 Azores, Cape_Verde_IS.
PAGE 96
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Krasnoyarsk 320: GMT 08:00 Beijing, Chongging, Hong Kong, Kuala Lumpur, Singapore, Taipei 360: GMT 09:00 Osaka, Sapporo, Tokyo, Seoul, Yakutsk 380: GMT 09:30 Adelaide, Darwin 400: GMT 10:00 Brisbane, Canberra, Melbourne, Sydney, Guam, Vladivostok 440: GMT 11:00 Magadan, Solomon Is., New Caledonia 480: GMT 12:00 Aucklan, Wellington, Fiji, Kamchatka, Marshall Is.
PAGE 97
VIVOTEK - A Leading Provider of Multimedia Communication Solutions cooperating with others, the system parameters will be restored to default value except a union of combined results. restoreexceptdst 7/6 Restore the system parameters to default value except all daylight saving time settings. This command can cooperate with other “restoreexceptXYZ” commands. When cooperating with others, the system parameters will be restored to default value except a union of combined results.
PAGE 98
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Group: status NAME VALUE SECURITY DESCRIPTION (get/set) videoactualmodulation ntsc, 4/7 pal di_i<0~(ndi-1)> The actual modulation type (videoin.
PAGE 99
VIVOTEK - A Leading Provider of Multimedia Communication Solutions operator, admin user_i<1~20>_ viewer, privilege operator, 6/6 User’s privilege.
PAGE 100
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Subgroup of network: http NAME VALUE SECURITY DESCRIPTION (get/set) port 80, 6/6 HTTP port 1025 ~ 65535 alternateport 1025~65535 6/6 Alternative HTTP port authmode basic, 1/6 HTTP authentication mode 1/6 Http server push access name for stream 1 digest s0_accessname string[32] (capability.protocol.spush_mjpeg =1 and video.stream.
PAGE 101
VIVOTEK - A Leading Provider of Multimedia Communication Solutions -1 => audio mute s1_audiotrack 6/6 The current audio track for stream2. -1 => audio mute Subgroup of rtsp_s<0~(n-1)>: multicast, n is stream count (capability.protocol.rtp.
PAGE 102
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Group: ipfilter NAME VALUE SECURITY DESCRIPTION (get/set) enable 6/6 Enable or disable ipfilter settings admin_enable 6/6 Enable or disable the function always allow the admin IP address to access this device admin_ip 1.0.0.0 ~ 6/6 255.255.255.
PAGE 103
VIVOTEK - A Leading Provider of Multimedia Communication Solutions atwbvalue1 0~ 4/4 The auto white balance value. 4/4 The auto white balance value.
PAGE 104
VIVOTEK - A Leading Provider of Multimedia Communication Solutions maxexposure 1~120 4/4 Maximum exposure time options quality, 4/4 To customize video quality first or video framerate frame rate first.
PAGE 105
VIVOTEK - A Leading Provider of Multimedia Communication Solutions 720x480 s<0~(m-1)>_field2frame 4/4 Do field to frame in server side (product dependent) s<0~(m-1)>_mpeg4_intraper 250, 500, iod 1000, 4/4 The period of intra frame in milliseconds 4/4 cbr, constant bitrate 2000, 3000, 4000 s<0~(m-1)>_mpeg4_ratecon cbr, vbr trolmode s<0~(m-1)>_mpeg4_quant vbr, fix quality 1~5, 99 4/4 quality of video when choosing vbr in “ratecontrolmode”. 99 is customized manual input setting.
PAGE 106
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Group: videoinpreview NAME VALUE SECURITY DESCRIPTION (get/set) maxexposure 1~120 4/4 Maximum exposure time exposurelevel 1~8 4/4 The target brightness adjust by exposure options 1: darkest 8: brightness enableblc 4/4 Enable backlight compensation (product dependent) enablewdr 4/4 Enable wide dynamic range (product dependent) agc 0~2 4/4 Set auto gain control to: 0: 2X level 1: 4X level 2: 8X level
PAGE 107
VIVOTEK - A Leading Provider of Multimedia Communication Solutions 6700, 7400, 7950, 10200, 12200 Group: image_c<0~(n-1)> for n channel products NAME VALUE SECURITY DESCRIPTION (get/set) brightness -5 ~ 5 4/4 Adjust brightness of image according to mode settings. saturation -5 ~ 5 4/4 Adjust saturation of image according to mode settings. contrast -5 ~ 5 4/4 Adjust contrast of image according to mode settings. sharpness -3 ~ 3 4/4 Adjust sharpness of image according to mode settings.
PAGE 108
VIVOTEK - A Leading Provider of Multimedia Communication Solutions win_i <0~2>_top 0 ~ 240 4/4 Top coordinate of window position. win_i <0~2>_width 0 ~ 320 4/4 Width of motion detection window. win_i<0~2>_height 0 ~ 240 4/4 Height of motion detection window. win_i<0~2>_objsize 0 ~ 100 4/4 Percent of motion detection window. win_i<0~2>_sensitivity 0 ~ 100 4/4 Sensitivity of motion detection window.
PAGE 109
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Group: ddns NAME VALUE SECURITY DESCRIPTION (get/set) enable 6/6 Enable or disable the dynamic dns. provider Safe100, 6/6 Safe100 => safe100.net DyndnsDynamic, DyndnsDynamic => dyndns.org (dynamic) DyndnsCustom, DyndnsCustom => dyndns.org (custom) TZO, TZO => tzo.com DHS, DHS => dhs.org DynInterfree, DynInterfree =>dyn-interfree.
PAGE 110
VIVOTEK - A Leading Provider of Multimedia Communication Solutions serverip 6/6 Log server IP address serverport 514, 6/6 Server port used for log 6/6 The levels to distinguish the importance of 1025~65535 level 0~7 information.
PAGE 111
VIVOTEK - A Leading Provider of Multimedia Communication Solutions win_i<0~4>_name string[14] 4/4 The name of privacy mask window win_i<0~4>_left 0 ~ 320/352 4/4 Left coordinate of window position. win_i<0~4>_top 0 ~ 240/288 4/4 Top coordinate of window position.
PAGE 112
VIVOTEK - A Leading Provider of Multimedia Communication Solutions ptzenabled 0/7 An 32-bits integer, each bit can be set separately as follows: Bit 0 => Support camera control function 0(not support), 1(support) Bit 1 => Build-in or external camera. 0(external), 1(build-in) Bit 2 => Support pan operation. 0(not support), 1(support) Bit 3 => Support tilt operation. 0(not support), 1(support) Bit 4 => Support zoom operation. 0(not support), 1(support) Bit 5 => Support focus operation.
PAGE 113
VIVOTEK - A Leading Provider of Multimedia Communication Solutions http protocol_spush_mjpeg 0/7 indicate whether to support server push motion jpeg protocol_snmp 0/7 indicate whether to support snmp protocol_ipv6 0/7 indicate whether to support ipv6 videoin_type 0, 1, 2 0/7 0 => Interlaced CCD 1 => Progressive CCD 2 => CMOS videoin_resolution
PAGE 114
VIVOTEK - A Leading Provider of Multimedia Communication Solutions audioout_codec tunnel for camera control uart_httptunnel 0/7 Indicate whether to support the http tunnel for uart transfer transmission_mode joystick Tx, 0/7 Indicate what kind of transmission Rx, mode the machine used.
PAGE 115
VIVOTEK - A Leading Provider of Multimedia Communication Solutions enable 0, 1 6/6 To enable or disable this event. priority 0, 1, 2 6/6 Indicate the priority of this event. “0” indicates low priority. “1” indicates normal priority. “2” indicates high priority. delay 1~999 6/6 Delay seconds before detect next event. trigger boot, 6/6 Indicate the trigger condition. di, “boot” indicates system boot. motion, “di” indicates digital input. seq, “motion” indicates video motion detection.
PAGE 116
VIVOTEK - A Leading Provider of Multimedia Communication Solutions weekday 6/6 Indicate which weekday is scheduled. One bit represents one weekday. The bit0 (LSB) indicates Saturday. The bit1 indicates Friday. The bit2 indicates Thursday. The bit3 indicates Wednesday. The bit4 indicates Tuesday. The bit5 indicates Monday. The bit6 indicates Sunday. For example, to detect events on Friday and Sunday, set weekday as 66. begintime hh:mm 6/6 Begin time of weekly schedule.
PAGE 117
VIVOTEK - A Leading Provider of Multimedia Communication Solutions type email, 6/6 Indicate the server type. ftp, “email” is email server. http, “ftp” is ftp server. ns “http” is http server. “ns” is network storage. http_url string[128] 6/6 The url of http server to upload. http_username string[64] 6/6 The username to login in the server. http_passwd string[64] 6/6 The password of the user.
PAGE 118
VIVOTEK - A Leading Provider of Multimedia Communication Solutions type snapshot, 6/6 systemlog The media type to send to the server or store by the server. videoclip snapshot_source 6/6 Indicate the source of media stream. 0 means the first stream. 1 means the second stream and etc. snapshot_prefix string[16] 6/6 Indicate the prefix of the filename. snapshot_datesuffix 0, 1 6/6 To add date and time suffix to filename or not. 1 means to add date and time suffix.
PAGE 119
VIVOTEK - A Leading Provider of Multimedia Communication Solutions weekday 6/6 Indicate which weekday is scheduled. One bit represents one weekday. The bit0 (LSB) indicates Saturday. The bit1 indicates Friday. The bit2 indicates Thursday. The bit3 indicates Wednesday. The bit4 indicates Tuesday. The bit5 indicates Monday. The bit6 indicates Sunday. For example, to detect events on Friday and Sunday, set weekday as 66. begintime hh:mm 6/6 Begin time of weekly schedule.
PAGE 120
VIVOTEK - A Leading Provider of Multimedia Communication Solutions dest cf, 6/6 0~4 The destination to store the recording data. “cf” means CF card. “0~4” means the index of network storage. cffolder string[128] 6/6 folder name. VALUE SECURITY DESCRIPTION Group: custom_i<0~2> PARAMETER (get/set) name string[40] 6/6 The identification of customize event script file.
PAGE 121
VIVOTEK - A Leading Provider of Multimedia Communication Solutions localityname string[128] 6/6 the locality name in certificate information organizationname string[64] 6/6 organization naem in certificate information unit string[32] 6/6 organizational unit name in certificate information commonname string[64] 6/6 common name in certificate information validdays 0 ~ 9999 6/6 certificatation valid period Drive the digital output Note: This request requires the privilege of viewer.
PAGE 122
VIVOTEK - A Leading Provider of Multimedia Communication Solutions http:///cgi-bin/dido/getdi.cgi?[di0][&di1][&di2][&di3] If no parameter is specified, all the status of digital input will be returned. Return: HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n Content-Length: \r\n \r\n [di0=]\r\n [di1=]\r\n [di2=]\r\n [di3=]\r\n where can be 0 or 1. Example: Query the status of digital input 1 Request: http://myserver/cgi-bin/dido/getdi.
PAGE 123
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Content-Type: text/plain\r\n Content-Length: \r\n \r\n [do0=]\r\n [do1=]\r\n [do2=]\r\n [do3=]\r\n where can be 0 or 1. Example: Query the status of digital output 1 Request: http://myserver/cgi-bin/dido/getdo.cgi?do0 Response: HTTP/1.
PAGE 124
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Return: HTTP/1.0 200 OK\r\n Content-Type: image/jpeg\r\n [Content-Length: \r\n] Account management Note: This request requires administrator privilege Method: GET/POST Syntax: http:///cgi-bin/admin/editaccount.
PAGE 125
VIVOTEK - A Leading Provider of Multimedia Communication Solutions return Redirect to the page after the parameter is assigned. The can be a full URL path or relative path according the the current path. If you omit this parameter, it will redirect to an empty page. System logs Note: This request require administrator privilege Method: GET/POST Syntax: http:///cgi-bin/admin/syslog.cgi Server will return the up-to-date system log. Return: HTTP/1.
PAGE 126
VIVOTEK - A Leading Provider of Multimedia Communication Solutions HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n Content-Length: \r\n \r\n \r\n Upgrade firmware Note: This request requires administrator privilege Method: POST Syntax: http:///cgi-bin/admin/upgrade.
PAGE 127
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Content-Length: \r\n \r\n Model=\r\n CapVersion=0200\r\n PARAMETER(supported VALUE DESCRIPTION system.firmwareversion Model name of server.
PAGE 128
VIVOTEK - A Leading Provider of Multimedia Communication Solutions deletedeny Remove a set of deny IP address range from server. If start and end parameters are specified, it will try to remove the matched IP address. If index is specified, it will try to remove the address from given index position. [start, end] parameters have higher priority then the [index] parameter. start The start IP address to add or to delete. end The end IP address to add or to delete.
PAGE 129
VIVOTEK - A Leading Provider of Multimedia Communication Solutions User must use GET and POST to establish two channels for downstream and upstream. The x-sessioncookie in the GET and POST should be the same to be recognized as a pair for one session. The contents of upstream should be base64 encoded to be able to pass through some proxy server. This channel will help to do real-time event notification and control. The event and control format are described in another document.
PAGE 130
Focus Controller Lens Light Sensor IR LEDs Zoom Controller Image Adjustment Screw VIVOTEK - Card A Leading Provider of Multimedia Communication Solutions Tilt Screw SD Slot Status LED General I/O Terminal Block Ethernet10/100 RJ45 Socket Audio Out (Green) Microphone In (Pink) Power Cord Socket (Black) Earth Pan Screw Indented Reset Button Technical Specifications Specifications Models ．FD7141 ．FD7141V System ．CPU: Bach SoC ．Flash: 8 MB ．RAM: 96 MB ．Embedded OS: Linux 2.
