User's Manual - 155
5: EV -0.3
6: EV 0
7: EV +0.3
8: EV +0.7
9: EV +1.0
10: EV +1.3
11: EV +1.7
12: EV +2.0
irismode fixed, indoor,
outdoor
<product
independent>
4/4 Control DC-Iris mode.
"outdoor": Auto-setting DC-Iris to get best
quality, but easy to meet rolling or flicker effect
in indoor environment.
"indoor": Avoid rolling and flicker effect first.
"fixed": Open the iris to maximum.
* Only available when
"capability_image_c<0~(n-1)>_iristype"=dci
ris
enableblc
<Not support anymore>
<boolean> 4/4 Enable backlight compensation.
* Not support this parameter anymore when
the version number (httpversion) is equal or
greater than 0301a.
* It's recommanded to use
"exposurewin_c<0~(n-1)>_mode" to switch
on/off BLC.
color 0, 1 4/4 0 =>monochrome
1 => color
flip <boolean> 4/4 Flip the image.
mirror <boolean> 4/4 Mirror the image.
rotate 0,90,180,270 1/4 The rotation angle of image.
Support only in Rotation mode
(capability_videoin_c<0~(n-1)>_rotation=1)
ptzstatus 0,<positive
integer>
1/7 A 32-bit integer, each bit can be set separately
as follows:
Bit 0 => Support camera control function;
0(not support), 1(support)
Bit 1 =>Built-in or external camera; 0
(external), 1(built-in)
Bit 2 => Support pan operation; 0(not
support), 1(support)
