184 - User's Manual
n"-1>_externalir > 0)
extledmode do, irring
* Available values
are listed in
"capability_daynight
_c<0~(n-1)>_extle
d_interface"
6/6 Turn on an external IR led which is mounted do
(digital output) device or is a IR ring device.
* Only available when
"capability_daynight_c<0~"capability_nvideoi
n"-1>_externalir" is 1.
* Only valid when "ircutcontrol_enableextled"
is 1.
bwmode <boolean> 6/6 Switch to B/W in night mode if enabled
sensitivity low, normal, high
(if
capability_daynight
_c<0~(n-1)>_ircut
sensitivity_type=op
tions)
1~100 (if
capability_daynight
_c<0~(n-1)>_ircut
sensitivity_type=no
rmalize)
6/6 Sensitivity of day/night control.
There are two value format:
"low,normal,high": if
capability_daynight_c<0~(n-1)>_ircutsensiti
vity_type=options
"1~100": if
capability_daynight_c<0~(n-1)>_ircutsensiti
vity_type=normalize
* Only available when
"capability_daynight_c<0~(n-1)>
_ircutsensitivity_type" is not "-".
7.11 Image setting per channel
Group: image_c<0~(n-1)> for n channel profucts and m profile
n denotes the value of "capability_nvideoin" and m denotes the value of "capability_nvideoinprofile"
NAME VALUE SECURITY
(get/set)
DESCRIPTION
brightness
<Not recommended to use this>
-5~5,100 4/4 -5: Darker <-> 5: Bright
100: Use " image_c<n>_brightnesspercent"
* Only available when bit 0 of
"capability_image_c<0~(n-1)>_basicsetting"
is 1
* We replace "brightness" with
"brightnesspercent".
* This parameter will not be used after the
