190 - User's Manual
* Only available when bit 0 of
"capability_image_c<0~(n-1)>_basicsetting"
is 1.
profile_i<0~(m-1)>_contrastpe
rcent
0~100 4/4 Set contrast in the normalized range.
0: Less contrast <-> 100: More contrast
* Only available when bit 1 of
"capability_image_c<0~(n-1)>_basicsetting"
is 1
profile_i<0~(m-1)>_saturation
percent
0~100 4/4 Set saturation in the normalized range.
0: Less saturation <-> 100: More saturation
* Only available when bit 2 of
"capability_image_c<0~(n-1)>_basicsetting"
is 1.
profile_i<0~(m-1)>_sharpness
percent
0~100 4/4 Set sharpness in the normalized range.
0: Softer <-> 100: Sharper
* Only available when bit 3 of
"capability_image_c<0~(n-1)>_basicsetting"
is 1
profile_i<0~(m-1)>_gammacur
ve
0~100 4/4 0: Fine-turned gamma curve by Vivotek.
1: Gamma value = 0.01
2: Gamma value = 0.02
3: Gamma value = 0.03
...
100: Gamma value = 1
* Note: Although we set gamma value to 100
level, but not all gamma values are valid.
Internal module will take the closest valid one.
For example, 1~45 may all be mapped to
gamma value = 0.45, etc.
* Only available when
"capability_image_c<0~(n-1)>_gammacurve
" is 1
profile_i<0~(m-1)>_lowlightm
ode
<product dependent>
<boolean> 4/4 Enable/disable low light mode.
* Only available when
"capability_image_c<0~(n-1)>_lowlightmode
" is 1
