User's Manual - 209
"capability_image_c<0~(n-1)>_privacymask
_wintype" = rectangle.
win_i<0~(m-1)>_height 0 ~ 240 4/4 Height of privacy mask window.
* Only available when
"capability_image_c<0~(n-1)>_privacymask
_wintype" = rectangle.
win_i<0~(m-1)>_polygo
n
0 ~ 320,0 ~ 240,
0 ~ 320,0 ~ 240,
0 ~ 320,0 ~ 240,
0 ~ 320,0 ~ 240
4/4 Coordinate of polygon window position.
(4 points: x0,y0,x1,y1,x2,y2,x3,y3)
* Only available when
"capability_image_c<n>_privacymask_winty
pe" = polygon.
* Only available when qvga is listed in
"capability_image_c<0~(n-1)>_privacymask
_windomain".
win_i<0~(m-1)>_polygo
npx
0 ~ W,0 ~ H,
0 ~ W,0 ~ H,
0 ~ W,0 ~ H,
0 ~ W,0 ~ H
W: 0~ The current
image width -1
H: 0~ The current
image height -1
4/4 Coordinate of polygon window position.
(4 points: x0,y0,x1,y1,x2,y2,x3,y3)
* Only available when
"capability_image_c<0~(n-1)>_privacymask
_wintype" = polygon.
* Only available when px is listed in
"capability_image_c<0~(n-1)>_privacymask
_windomain".
win_i<0~(m-1)>_polygo
nstd
0 ~ 9999,0 ~ 9999,
0 ~ 9999,0 ~ 9999,
0 ~ 9999,0 ~ 9999,
0 ~ 9999,0 ~ 9999
4/4 Coordinate of polygon window position.
(4 points: x0,y0,x1,y1,x2,y2,x3,y3)
* Only available when
"capability_image_c<0~(n-1)>_privacymask
_wintype" = polygon.
* Only available when std is listed in
"capability_image_c<0~(n-1)>_privacymask
_windomain".
