User's Manual - 267
action_cf_media NULL, 0~4,101 6/6 Index of the attached media.
101 means “Recording Notify”
action_cf_datefolder <boolean> 6/6 Enable this to create folders by date, time, and
hour automatically.
action_cf_backup <Boolean> 6/6 Enable or disable the function that send media to
SD card for backup if network is disconnected.
action_server_i<0~4>_ena
ble
<boolean> 6/6 Enable or disable this server action.
action_server_i<0~4>_me
dia
NULL, 0~4,101 6/6 Index of the attached media.
101 means “Recording Notify”
action_server_i<0~4>_dat
efolder
<boolean> 6/6 Enable this to create folders by date, time, and
hour automatically.
action_goto_enable
<product dependent>
<boolean> 6/6 Enable/disable ptz goto preset position on event
triggered.
* Only available when capability_ptzenabled >
0.
action_goto_name
<product dependent>
string[40] 6/6 Specify the preset name that ptz goto on event
triggered.
* Only available when capability_ptzenabled >
0.
action_goto_sync
<product dependent>
<boolean> 6/6 Capture media after moving to the location.
* Only avaliable when the bit4 of
capability_ptzenabled is 1 and the bit7 of
capability_ptzenabled is 0
action_autotrack_enable
<product dependent>
<boolean> 6/6 Enable/disable auto tracking on event triggerd.
* Only avaliable when the bit4 of
capability_ptzenabled is 1 and the bit7 of
capability_ptzenabled is 0
