VIVOTEK - A Leading Provider of Multimedia Communication Solutions Package Contents IP7135 Software CD Power adapter Quick installation guide Camera stand Warranty card 6 - User's Manual
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Installation In this manual, "User" refers to whoever has access to the Network Camera, and "Administrator" refers to the person who can configure the Network Camera and grant user access to the camera. Hardware installation Please verify that your product package contains all the accessories listed in the foregoing Package Contents. Depending on the user’s application, an Ethernet cable may be needed.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Software installation At the end of the hardware installation, users can use Installation Wizard program included in the product CDROM to find the location of the Network Camera. There may be many Network Cameras in the local network. Users can differentiate the Network Cameras with the serial number. The serial number is printed on the labels on the carton and the back of the Network Camera body.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Once installation is complete, the Administrator should proceed to the next section "Initial access to the Network Camera" for necessary checks and configurations. Initial Access to the Network Camera Check Network Settings The Network Camera can be connected either before or immediately after software installation onto the Local Area Network.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions How to Use Authentication After opening the Web browser and typing in the URL of the Network Camera, a dialogue window pops up to request a username and password. Upon successful authentication, the following figure is displayed. The foreground is the login window and the background shows the message if authentication fails. The user may check the option box to save the password for future convenience.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Installing plug-in For the initial access to the Network Camera in Windows, the web browser may prompt for permission to install a new plug-in for the Network Camera. Permission request depends on the Internet security settings of the user’s PC or notebook. If the highest security level is set, the computer may prohibit any installation and execution attempt.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Primary user’s capability Main Screen with Camera View The main page layout has two parts: Configuration functions: The camera can be configured using these user interfaces. Camera View: What the camera sees. Click on the configuration link to the left of the image window to enter the configuration page.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Digital Zoom Click on the magnifier icon under the camera view then the digital zoom control panel will be shown. Uncheck “Disable digital zoom” and use the slider control to change the zoom factors.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Snapshot Click on “Snapshot”, web browser will pop up a new window to show the snapshot. Users can point at the snapshot and click the right button of mouse to save it.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Client settings At the initial access to the “Connection type” page in Windows, the web browser will ask for a new plug-in installation, the plug-in being the Network Camera. This plug-in has been registered for certification and can be used to change the parameters at the client’s site. The user may click on to install the plug-in.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions If no special need is required, UDP protocol is recommended. Generally speaking, the client’s choice will be in the order of UDP Ш TCP. After the Network Camera is connected successfully, “Protocol Option” will indicate the selected protocol. The selected protocol will be recorded in the user's PC and will be used for the next connection.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Administrator’s capability Fine-tuning for Best Performance Best performance generally equates to the fastest image refresh rate with the best video quality, and at the lowest network bandwidth as possible. The three factors, “Maximum frame rate”, “Constant bit rate”, and “Fix quality” on the Audio and Video Configuration page, are correlative to allow for achieving the best performance possible.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions For Best Real-time Video Images To achieve good real-time visual effect, the network bandwidth should be large enough to allow a transmission rate of greater than 20 image frames per second. If the broadband network is over 1 Mbps, set the “Fix bit rate” to 1000Kbps or 1200Kbps, and set “Fix quality” at the highest quality. The maximum frame rate is 30.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Opening accounts for new users 1 2 3 Protect Network Camera by passwords The Network Camera is shipped without any password by default. That means everyone can access the Network Camera including the configuration as long as the IP address is known. It is necessary to assign a password if the Network Camera is 1 to enable protection. intended to be accessed by others.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Build a security application The Administrator can use the built-in motion detection to monitor any movement to perform many useful security applications. To upload the snapshots, users can choose either email or FTP according to user’s needs. Both e-mail and FTP use the network settings on the Email and FTP page. Refer to the definition section for detail configuration. 1. Click on “Configuration” on homepage, 2.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Software revision upgrade Customers can obtain the up-to-date software from the web site of VIVOTEK. An easy-to-use Upgrade Wizard is provided to upgrade the Network Camera with just a few clicks. The upgrade function is opened to the Administrator only. To upgrade the system, follow the procedures below. 1. Download the firmware file named “xxx.pkg” from the appropriate product folder. 2.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Definitions in Configuration Only the Administrator can access system configuration. Each category in the left column will be explained in the following pages. The bold texts are the specific phrases on the Option pages. The Administrator may type the URL below the figure to directly enter the frame page of configuration. If the Administrator also wants to set certain options through the URL, read the reference appendix for details.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions System parameters "Host name" The text displays the title at the top of the main page. “Turn off the LED indicator” Check this option to shut off the LED on the rear. It can prevent the camera’s operation being noticed. "Keep current date and time" Click on this to reserve the current date and time of the Network Camera. An internal real-time clock maintains the date and time even when the power of the system is turned off.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Security settings “Root password” Change the Administrator’s password by typing in the new password identically in both text boxes. The typed entries will be displayed as asterisks for security purposes. After pressing , the web browser will ask the Administrator for the new password for access. “Add user” Type the new user's name and password and press to insert the new entry. The new user will be displayed in the user name list.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Network settings Any changes made on this page will restart the system in order to validate the changes. Make sure every field is entered correctly before clicking on . Network type “LAN” & “PPPoE” The default type is LAN. Select PPPoE if using ADSL "Get IP address automatically" & “Use fixed IP address” The default status is “Get IP address automatically”.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions HTTP “Http port” This can be other than the default Port 80. Once the port is changed, the users must be notified the change for the connection to be successful. For instance, when the Administrator changes the HTTP port of the Network Camera whose IP address is 192.168.0.100 from 80 to 8080, the users must type in the web browser “http://192.168.0.100:8080” instead of “http://192.168.0.100”.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions DDNS “Enable DDNS” This option turns on the DDNS function. “Provider” The provider list contains four hosts that provide DDNS services. Please connect to the service provider’s website to make sure the service charges. “Host Name” If the User wants to use DDNS service, this field must be filled. Please input the hostname that is registered in the DDNS server.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Access List The access list is to control the access permission of clients by checking the client IP address. There are two lists for permission control: Allow List and Deny List. Only those clients whose IP address is in the Allow List and not in the Deny List can connect to the Video Server or Network Camera for receiving the audio/video streaming. Both Allow List and Deny List consist of a list of IP ranges.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Audio and Video General “Configure for computer viewing” To make quick setting for computer viewing “Configure for mobile viewing” To make quick setting for cell phone viewing Video Settings “Video title” The text string can be displayed on video “Color” Select either for color or monochrome video display. “Frame Size” There are four options for video sizes. “160x120”. “176x144”, “320x240”, “640x480”.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Video orientation “Flip” Vertically rotate the video. “Mirror” Horizontally rotate the video. Check options both if the Network Camera is installed upside down. “White balance” Adjust the value for best color temperature.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Image Settings Click on this button to pop up another window to tune “Brightness”, “Contrast”, “Saturation” “Hue” for and video compensation. Each field has eleven levels ranged from -5 to +5. In “Brightness” and “Contrast” fields the value 0 indicates auto tuning. The user may press to fine-tune the image. When the to set image is O.K., press the image settings.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Email & FTP Email When the SMTP server support SMTP authentication, users need to give the valid user name and password to send email via the server. “Sender email address”, the email address of the sender. There are two external mail server can be configured, primary and secondary email server, The network camera will use primary server as default , and use secondary server when primary server is unreachable.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions conform to that of the external FTP server. Some FTP servers cannot accept preceding slash symbol before the path without virtual path mapping. Refer to the instructions for the external FTP server for details. The folder privilege must be open for upload. http:///setup/mailftp.html is the domain name or original IP address of the Network Camera.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Motion detection “Enable motion detection” Check this option to turn on motion detection. Click on this button to add a new window. At most three windows can exist simultaneously. Use the mouse to click, hold, and drag the window frame to resize or the title bar to move. Clicking on the ‘x’ at the upper right-hand corner of the window to delete the window. Remember to save in order to validate the changes.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Application settings The server provides two kinds of applications, snapshot and videoclip. There are two independent snapshot items to set, and they are named as Snapshot #1 and Snapshot #2. The status, schedule, trigger condition, and action of three applications are summaried in the application page. The user can click on Snapshot #1, Snapshot #2 or Video Clip to enter the detail setting page.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions send when a condition is triggered. “Delay second(s) before detecting next motion” Set the time delay before restarting to check on the triggering condition when the current condition is triggered. Sequential operation “Snapshot interval (seconds)” Network Camera will send snapshots at the specified intervals to the external server using the method selected below.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 37
VIVOTEK - A Leading Provider of Multimedia Communication Solutions 38 - User's Manual
VIVOTEK - A Leading Provider of Multimedia Communication Solutions System log The Network camera support log the system messages on remote server. The protocol is compliant to RFC 3164. If you have external Linux server with syslogd service, use “-r” option to turn on the facility for receiving log from remote machine. Or you can use some software on Windows which is compliant to RFC 3164.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Viewing system parameters Click on this link on the configuration page to view the entire system’s parameter set. The content is the same as those in CONFIG.INI.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Maintenance Three actions can be selected “reboot” click the reboot button to restart system “factory default” Click on Factory default button on the configuration page to restore the factory default settings. Any changes made so far will be lost and the system will be reset to the initial factory settings. The system will restart and require the installer program to set up the network again.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Appendix A. Troubleshooting Status LED The following table lists the LED patterns in general.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions lists the commands in URL format corresponding to the basic functions of the erase Network Camera. Get server parameter values Note: This request require administrator access Method: GET/POST Syntax: http:///cgi-bin/admin/getparam.cgi?[] [&…] where the should be [_] or [.] If you do not specify the any parameters, all the parameters on the server will be returned.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions Context-Length: 33\r\n \r\n network.ipaddress=192.168.0.123\r\n Set server parameter values Note: This request require administrator access Method: GET/POST Syntax: http:///cgi-bin/admin/setparam.cgi? [nosync=&]= [&=…][&return=] parameter value description _. value to assigned Assign to the parameter _..
VIVOTEK - A Leading Provider of Multimedia Communication Solutions where is =\r\n [] Only the parameters that you set and readable will be returned. Example: Set the IP address of server to 192.168.0.123 Request: http://myserver/cgi-bin/admin/setparam.cgi?Network_IPAddress=192.168.0.123 Response: HTTP/1.0 200 OK\r\n Content-Type: text/html\r\n Context-Length: 33\r\n \r\n network.ipaddress=192.168.0.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions ntp timezone -12 ~ 12 time zone, 8 means GMT +8:00 (r/w) updateinterval <8> 0 ~ 2592000 0 to Disable automatic time adjustment, (r/w) otherwise, it means the seconds between NTP automatic update interval.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions usercount 1 ~ 21 The current account number on the server (r) including root.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions mailto2 mailuser2 mailpass2 returnemail localftpport ftp1
VIVOTEK - A Leading Provider of Multimedia Communication Solutions rtspport <554> videoport audioport accessname <5558> number less audio Channel port for RTP <5556> Group: IPFilter NAME VALUE DESCRIPTION allowstart_<0~9> 1.0.0.0 (r/w) ~ Allowed 255.255.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions 640x480 (for Video resolution 640 x 480 computer) color 0 monochrome (r/w) 1 color quality 0 fix bit rate (r/w) 1 fix quantization quant 1 lowest quality of video (r/w) 2 lower quality of video 3 normal quality of video 4 higher quality of video 5 highest quality of video bitrate 20000 set bit rate to 20K bps (r/w) 30000 set bit rate to 30K bps 40000 set bit rate to 40K bps 50000 set bit rate to 50K bps 6
VIVOTEK - A Leading Provider of Multimedia Communication Solutions whitebalance 0 auto white balance (r/w) (in CMOS 1 fixed indoor(3200K) version only) 2 fixed fluorescent (5500K) 3 fixed outdoor( > 5500K) flip 1 flip image (r/w) 0 normal image mirror 1 mirror image (r/w) 0 normal image imprinttimestam 1 Overlay time stamp on video p Do not overlay time stamp on video 0 (r/w) Group: Audio NAME VALUE DESCRIPTION type AAC4 (for computer) set codec to AAC (r/w) GAMR (for mobil
VIVOTEK - A Leading Provider of Multimedia Communication Solutions contrast <-5 ~ 5> Adjust contrast of image according to (r/w) hue mode settings. <0> <-5 ~ 5> Adjust hue of image according to mode (r/w) settings.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions dyn-interfree.it <1> hostname Text string shorter than Your dynamic hostname. (r/w) 127 characters. usernameemail Text string shorter than 63 Your user or email to login ddns service (r/w) characters. provider passwordkey Text string shorter than 20 Your password or key to login ddns service (r/w) characters.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions serverip Log server IP address <514> Server port used for log (r/w) serverport (r/w) Application page CGI command Note: This request requires administrator privilege. Method: GET/POST Syntax (For snapshot): http:///cgi-bin/admin/gen-new-eventd-conf.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions [&_maxsize=] [&_md_win=] [&_md_delay=] [&_sq_interval=] [&_send_method=] [&_ftp_suffix=] Return: HTTP/1.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions send_method ftp_suffix mail Send snapshot by mail ftp Send snapshot by ftp 0/1 Enable/Disable file name prefix Capture single snapshot Note: This request require normal user privilege Method: GET/POST Syntax: http:///cgi-bin/video.jpg Server will return the most up-to-date snapshot in JPEG format. The size and quality of image will be set according to the video settings on the server. Return: HTTP/1.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions delete Remove an account from server. When using this method, “username” field is necessary, and others are ignored. edit Modify the account password and privilege. When using this method, “username” field is necessary, and other fields are optional. If not specified, it will keep original settings.
VIVOTEK - A Leading Provider of Multimedia Communication Solutions \r\n \r\n Configuration file Note: This request requires administrator privilege Method: GET/POST Syntax: http:///cgi-bin/admin/configfile.cgi Server will return the up-to-date configuration file. Return: HTTP/1.
