VIVOTEK
User's Manual - 7
General I/O Terminal Block
This video server provides a general I/O terminal block which is used to connect external input /
output devices. The pin denitions are described below.
CH 8
GND
CH 8
DI
CH 7
GND
CH 7
DI
CH 6
GND
CH 6
DI
CH 5
GND
CH 5
DI
CH 4
GND
CH 4
DI
CH 3
GND
CH 3
DI
CH 2
GND
CH 2
DI
CH 1
GND
CH 1
DI
CH 8
GND
CH 8
DO
CH 7
GND
CH 7
DO
CH 6
GND
CH 6
DO
CH 5
GND
CH 5
DO
CH 4
GND
CH 4
DO
CH 3
GND
CH 3
DO
CH 2
GND
CH 2
DO
CH 1
GND
CH 1
DO
GND GND
CH 8
Audio
out
CH 7
Audio
out
CH 6
Audio
out
CH 5
Audio
out
CH 4
Audio
out
CH 3
Audio
out
CH 2
Audio
out
CH 1
Audio
out
RS
485-
RS
485+
24V
AC
24V
AC
GND
DC
12V
USB & SD card
functions
are not available
on this unit.
USB function
is not available
on this unit.
■ VS8801
■ VS8401
GND N/A
CH 4
GND
CH 4
DI
CH 3
GND
CH 3
DI
CH 2
GND
CH 2
DI
CH 1
GND
CH 1
DI
GND N/A
CH 4
GND
CH 4
DO
CH 3
GND
CH 3
DO
CH 2
GND
CH 2
DO
CH 1
GND
CH 1
DO
CH 4
Audio
out
CH 3
Audio
out
CH 2
Audio
out
CH 1
Audio
out
RS
485-
RS
485+
24V
AC
24V
AC
GND
DC
12V
USB & SD card
functions
are not available
on this unit.
USB function
is not available
on this unit.
