Package Contents • VIZIO High Definition Soundbar • Wireless Subwoofer • Satellite Speakers with 20 foot speaker cable (2) • Power adapter for Soundbar • Power cable for subwoofer • Remote control and battery • Soundbar stands & screws (pre-installed) (2) • RCA stereo cable • User Manual • Quick Start Guide 1 Remove the plastic tab from the remote 2 Pairing The Soundbar operates in unison with the Wireless Subwoofer and they come paired from the factory.
Connect Equipment 3 Connect Equipment (CONTINUED) Digital Connection - Best Quality For best performance, use the OPTICAL jack on your Soundbar if your TV, Set-top Box, DVD Player, Home Theater System, etc. has an Optical digital audio output. 1. Turn off power to the Soundbar and the device. 2. Connect one end of the Optical (S/PDIF) cable (sold separately) to the digital audio output on the device. 3. Connect the other end of the Optical (S/PDIF) cable to the OPTICAL jack on the Soundbar. 4.
3 Connect Equipment (CONTINUED) 5 Connect Power - Subwoofer Connecting an iPod Dock (not included) 1. Connect one end of the AC adapter into the 100-240V AC jack on the back of the Subwoofer 2. Plug the other end into a wall outlet. 3. Turn the Power Switch to ON. L 1. Turn off power to the Soundbar and the MP3 Player. 4. Turn on the power to the Soundbar and MP3 Player. 2. Connect one end of the audio cable to the analog audio output on the MP3 player docking unit. 5.
7 Wall Mounting the SoundBar (optional) understanding the remote control The Soundbar can either be kept on the stand or mounted on the wall. If you choose to mount the Soundbar on the wall, follow the instructions below for removing the stand. 1. Remove the stands from their original configuration as shown in Figure 1. 3. Connect Audio and Video Cables to your Sound Bar (see Connecting Equipment on page 15 for detailed steps). 4.
help topics No power • Press the Power button on the remote control or the top of the Soundbar. • Make sure power cords are securely connected to the electrical outlet and on the back of the Soundbar and Subwoofer. • Make sure the power LEDs on the power adapters are glowing green. • Plug another electrical device to the power outlet to verify that the outlet is working. No Sound • Press the Volume + (Up) button on the remote control or the top of the Soundbar.
