Manual

23
Radius Bar
(3) Turret Cap
Retaining Screws
The Vortex Razor HD 1–4x24 Riflescope
BDC
Reference
Marks
Elevation Knob
Waterproof Yes
Fogproof Argon gas purging
Length 10.3 inches (261.2mm)
Mounting Length 6.4 inches (162.6mm)
Weight 20.2 ounces (628.3g)
Eye Relief 3.9 inches (99.6 mm)
Field of View 94.5–24.2 feet/100 yards (18–4.6°)
Reticle Style CQMR-1
Windage 200 MOA Total Travel
Elevation 200 MOA Total Travel
Turret Adjustment 24 MOA Per Rotation
1/4 MOA Per Click
Recoil Tested Rated for 50 BMG
Battery CR2032
Razor 1–4x24 Riflescope Specifications
Accessories included with the Razor HD
Flip cap lens cover with killFLASH
®
ARD
Cleaning cloth
Dimensions
.5”
6.4” (162.6mm)
(91.4mm)
10.3” (261.2mm)
1.3”
(33.0mm)
1.7”
(43.2mm)
(Eyepiece)
3.0”
(76.2mm)
2.0”
(50.8mm)
(12.7mm)
3.6”
Magnification
Adjustment Ring
Windage
Adjustment Knob
Reticle Focus
Illumination Knob
Objective Lens
Elevation
Adjustment Knob
Battery Cover
MagView
Fast Focus
Eyepiece
Dual Use: Shooting Tactical / Hunting
Zero Reference
Line
