User’s manual TL30100 DECT 6.
Congratulations on purchasing your new AT&T product. Before using this AT&T product, please thoroughly read this user’s manual for the information necessary to install your new AT&T product. For complete instructions, please refer to the manual provided with your TL32100/TL32200/TL32300 telephone. For customer service or product information, please visit our website at www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268. Model #: TL30100 Type: DECT 6.
Parts checklist Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary.
User’s manual TL30100 DECT 6.0 expansion handset for use with AT&T models TL32100/TL32200/TL32300 Table of contents Getting started Precautions for users of implanted cardiac pacemakers.............................26 Quick reference guide..................................2 Pacemaker patients.............................26 Charger installation........................................5 Especially about telephone answering systems...............................26 Battery installation and charging.........
You must install and charge the battery before using the cordless handset. See pages 5 and 6 for easy instructions. Your product may be shipped with a protective sticker covering the handset - remove it before use. For customer service or product information, visit our website at www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268. Avoid placing the telephone base too close to: • Communication devices such as television sets, VCRs, or other cordless telephones.
Getting started Quick reference guide MENU/SELECT DIR/VOLUME Press to scroll up while in menus. Press to display the menu. Press to increase the listening volume. Once in the menu, press to select an item or save an entry or setting. Press to show directory entries when the handset is not in use. OFF/CLEAR During a call, press to hang up. While entering names or numbers in the directory, press to move the cursor to the right.
Getting started Quick reference guide 0 MUTE/REMOVE While entering names in the directory, press to add a space. During a call, press to mute the microphone. While predialing, press to delete digits. 1 While reviewing the redial list, directory, speed dial list or caller ID history, press to delete an individual entry. While reviewing a caller ID history entry, press repeatedly to add or remove 1 in front of the telephone number before dialing or saving it in the directory.
Getting started Quick reference guide EQUALIZER During an outside call, intercom call, message or announcement playback, press to change the quality of the audio to best suit your hearing. The > symbol indicates the feature to select. Main menu Play messages Answering sys >Play messages Answering sys Directory Call log Intercom Ringers Settings Website Using menus Press MENU/SELECT to enter the main menu. Press Press DIR or CID to scroll through menu items.
Getting started Charger installation Install the charger as shown below. Plug the large end of the power adapter into an electrical outlet not controlled by a wall switch. Ensure the small end of the power adapter is plugged into the power jack on the back of the charger. Route the cord through the slot. IMPORTANT INFORMATION: Use only the power adapter provided with this product. To obtain a replacement, www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.
Getting started Battery installation and charging Battery installation Install the battery as shown below. 1. Plug the battery connector securely into the socket inside the handset battery compartment, matching the colorcoded label. 2. Insert the supplied battery with the label THIS SIDE UP facing up as indicated. 3. Align the cover flat against the battery compartment, then slide it upwards until it clicks into place.
Getting started Battery installation and charging Battery charging Once you have installed the battery, the screen indicates the battery status (see the table below). If necessary, place the handset in the charger to charge the battery. HANDSET 1 For best performance, keep the handset in the charger when not in use. The battery is fully charged after 16 hours of continuous charging. See Technical specifications on 11/20 10:30 page 33 for battery operating times.
Getting started Battery installation and charging NOTES: • If you are on a call in low battery mode, you hear four short beeps every 50 seconds. • When you place the handset in the charger, if no battery is installed in that handset, the CHARGE light is off and the screen shows NO BATTERY. Follow the instructions in Battery installation on page 6 to install the battery.
Adding the handset to your telephone base Adding and registering a handset About expansion handsets Before using a new TL30100 handset, you must register it with the AT&T TL32100/TL32200/TL32300 telephone system (purchased separately), the telephone system can accommodate up to five handsets. The handset with the TL32100 telephone comes as HANDSET 1.
Adding the handset to your telephone base Adding and registering a handset To register a handset to your telephone base: 1. Make sure the handset is out of the telephone base or charger and alternately shows 1.Press HS LOC on base 4 sec and 2.Then press # on handset before you begin the registration. 2. Press and hold HANDSET LOCATOR on the telephone base for about four seconds (until the IN USE light on the telephone base is on) and then release the button. 3. Press # (pound key) on the handset.
Adding the handset to your telephone base Deregistering all handsets You can deregister handsets. You may need to deregister your handsets if: • You have five registered handsets and need to replace a handset. -OR• You wish to change the designated handset number of your registered handsets. You must first deregister ALL the handsets, and then register each handset you wish to use again, one at a time.
Adding the handset to your telephone base Deregistering all handsets To register the handset(s) to the telephone base again, follow the registration instructions in Registering a handset on page 9. NOTES: • If the deregistration process is not successful, you might need to reset the system and try again. To reset, unplug the power from the telephone base and plug it back in. • You cannot deregister the handset(s) if any system handset is in use.
Appendix Troubleshooting If you have difficulty with your telephone, please try the suggestions below. For customer service, or to purchase accessories or replacement parts, visit our website at www.telephones.att.com, or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268. When you call for customer service, you will need the serial number or model number found on the bottom of the telephone base or charger. The handset registration is unsuccessful.
Appendix Troubleshooting I cannot get a dial tone. • First try all the suggestions above. • Move the cordless handset closer to the telephone base. You might have moved out of range. • If the previous suggestions don’t work, disconnect the telephone base from the telephone wall jack and connect to a different telephone. If there is no dial tone on that telephone either, the problem is in your wiring or telephone service. Contact your telephone service provider (charges may apply).
Appendix Troubleshooting My cordless handset isn’t performing normally. • Make sure the power cord is securely plugged into the telephone base. Plug the power adapter into a different, working electrical outlet not controlled by a wall switch. • Move the cordless handset closer to the telephone base. You might have moved out of range. • Reset the telephone base. Unplug the electrical power. Wait for 15 seconds then plug it back in.
Appendix Troubleshooting The batteries do not hold a charge. • If the cordless handset is in the telephone base or charger and the charge light does not come on, refer to the item The charge light is off on this page. • Charge the battery in the cordless handset for at least 16 hours. For optimum daily performance, return the cordless handset to the telephone base or charger when not in use.
Appendix Troubleshooting I get noise, static, or weak signals even when I’m near the telephone base. • If you subscribe to high-speed Internet service (DSL - digital subscriber line) through your telephone line, you must install a DSL filter between the telephone line cord and the telephone wall jack (see Telephone base and charger installation in the TL32100/TL32200/TL32300 user’s manual). The filter prevents noise and caller ID problems caused by DSL interference.
Appendix Troubleshooting I experience poor sound quality when using the speakerphone. • For increased sound quality while using the speakerphone, place the handset on a flat surface with the dial pad facing up. • When using a speakerphone, controlling background noise in your environment is essential. While you are listening to your party, press MUTE/REMOVE to temporarily turn your microphone off. When it is your turn to speak, remember to press MUTE/REMOVE again to turn the microphone on.
Appendix Troubleshooting • Do not install this telephone near a microwave oven or on the same electrical outlet. You may experience decreased performance while the microwave oven is operating. • If your telephone is plugged in with a modem or surge protector, plug the telephone (or modem/surge protector) into a different location. If this doesn’t solve the problem, relocate your telephone or modem farther apart from one another, or use a different surge protector.
Appendix Troubleshooting • Charge the battery in the cordless handset for at least 16 hours. For optimum daily performance, return the cordless handset to the telephone base or charger when not in use. • You may have too many extension telephones on your telephone line to allow all of them to ring simultaneously. Try unplugging one telephone at a time until the telephone starts ringing. • The layout of your home or office might be limiting the operating range.
Appendix Troubleshooting • Your caller must be calling from an area that supports caller ID. • Both your and your caller’s telephone service providers must use caller ID compatible equipment. • Make sure the home area code is set correctly in the telephone (see Home area code in the TL32100/TL32200/ TL32300 user’s manual).
Appendix Troubleshooting • In a few rare instances, the USB port on your computer may not have enough power. In these instances, try using a USB hub with its own external power supply. • If you are using a firewall, it may prevent access to your nontraditional telephone service. Contact your service provider for more information. Common cure for electronic equipment: If the telephone is not responding normally, try resetting the telephone. Do the following in the order listed: 1.
Appendix Maintenance Taking care of your telephone • Your cordless telephone contains sophisticated electronic parts, so it must be treated with care. • Avoid rough treatment. • Place the handset down gently. • Save the original packing materials to protect your telephone if you ever need to ship it. Avoid water • Your telephone can be damaged if it gets wet. Do not use the handset in the rain, or handle it with wet hands. Do not install the telephone base near a sink, bathtub or shower.
Appendix Important safety information This symbol is to alert you to important operating or servicing instructions that may appear in this user’s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock. Safety information • Read and understand all instructions in the user’s manual. Observe all markings on the product. • Avoid using a telephone during a thunderstorm. There might be a slight chance of electric shock from lightning.
Appendix Important safety information Especially about cordless telephones • Privacy: The same features that make a cordless telephone convenient create some limitations. Telephone calls are transmitted between the telephone base and the handset by radio waves, so there is a possibility that your cordless telephone conversations could be intercepted by radio receiving equipment within range of the cordless handset.
Appendix Important safety information Precautions for users of implanted cardiac pacemakers Cardiac pacemakers (applies only to digital cordless telephones): Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the interference between portable wireless telephones and implanted cardiac pacemakers. Supported by the U.S.
Appendix FCC Part 68 and ACTA This equipment complies with Part 68 of the FCC rules and with technical requirements adopted by the Administrative Council for Terminal Attachments (ACTA). The label on the back or bottom of this equipment contains, among other things, a product identifier in the format US:AAAEQ##TXXXX. This identifier must be provided to your telephone service provider upon request.
Appendix FCC Part 68 and ACTA If this product has memory dialing locations, you may choose to store emergency telephone numbers (e.g., police, fire, medical) in these locations. If you do store or test emergency numbers, please: • Remain on the line and briefly explain the reason for the call before hanging up. • Perform such activities in off-peak hours, such as early morning or late evening.
Appendix FCC Part 15 This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Appendix Limited warranty The AT&T brand is used under license - any repair, replacement or warranty service, and all questions about this product should be directed to our website at www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268. 1.
Appendix Limited warranty • PRODUCT that has been damaged due to repair, alteration, or modification by anyone other than an authorized service representative of the manufacturer; or • PRODUCT to the extent that the problem experienced is caused by signal conditions, network reliability or cable or antenna systems; or • PRODUCT to the extent that the problem is caused by use with non-AT&T accessories; or • PRODUCT whose warranty/quality stickers, PRODUCT serial number plates or electronic serial numbers ha
Appendix Limited warranty 6. What must you return with the PRODUCT to get warranty service? You must: a. Return the entire original package and contents including the PRODUCT to the service location along with a description of the malfunction or difficulty; and b. Include a “valid proof of purchase” (sales receipt) identifying the PRODUCT purchased (PRODUCT model) and the date of purchase or receipt; and c. Provide your name, complete and correct mailing address, and telephone number. 7.
Appendix Technical specifications RF frequency band 1921.536MHz – 1928.448MHz Channels 5 Operating temperature 32°F – 122°F 0°C – 50°C Handset voltage DC2.4V Charger voltage (AC adapter output) AC6V @300mA Operating times* Talk time (handset): up to seven hours Talk time (speakerphone): up to five hours Standby: up to seven days * Operating times vary depending on your actual use and the age of the battery. DECT 6.0 digital technology Telecommunications (DECT) 6.
