Specification Sheet

Fixture Type:
Catalog Number:
Project:
Location:
WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement program. APR 2017
waclighting.com
Phone [phone]
Fax [phone]
Headquarters/Eastern Distribution Center
44 Harbor Park Drive
Port Washington, NY 11050
Central Distribution Center
1600 Distribution Ct
Lithia Springs, GA 30122
Western Distribution Center
1750 Archibald Avenue
Ontario, CA 91760
TUBE ARCHITECTURAL DS-PD05
LED Pendant Mounts
24" Extension Rod
for additional
length up to 96"
+
ORDERING NUMBER
Model Diameter Watt Color Temp CRI Lumen CBCP
Efficacy
(Lm/W) Light Distribution Finish
DS-PD05 5” 27W
S927
S27
S930
S30
S35
S40
2700K
2700K
3000K
3000K
3500K
4000K
90
85
90
85
85
85
1680
1800
1700
1995
2190
2260
8526
9151
8639
10126
11118
11483
62
67
63
74
81
84
18°
BK
WT
BZ
GH
Black
White
Bronze
Graphite
N927
N27
N930
N30
N35
N40
2700K
2700K
3000K
3000K
3500K
4000K
90
85
90
85
85
85
1730
1855
1750
2055
2255
2330
5513
5918
5587
6548
7190
7426
64
69
65
76
84
86
25°
F927
F27
F930
F30
F35
F40
2700K
2700K
3000K
3000K
3500K
4000K
90
85
90
85
85
85
1725
1850
1745
2045
2245
2320
4246
4557
4302
5043
5537
5719
64
69
65
73
83
86
33°
PRODUCT DESCRIPTION
The latest energy efficient LED technology in an appealing cylindrical profile
delivers accent and wall wash lighting. Comes in various light distribution
and beam angle options.
FEATURES
• High performance exterior rated LED pendant
• Includes 45° swivel canopy and two field cuttable 24" rods
• Rods extendable up to 96" using DS-PDX24 accessory
• Solid aluminum construction
• 39° visual cutoff angle for glare control
• 5 year warranty
SPECIFICATIONS
Input:
Dimming:
Light Source:
Finish:
Standards:
Universal voltage 120V - 277VAC, 50/60Hz
Electronic low voltage (ELV) : 100% - 5% (120V only)
0-10V: 100% - 0% (120-277V)
High output 3 Step Mac Adam Ellipse COB
Rated life of 60,000 hours at L70
Electrostatically powder coated, white, black, bronze
and graphite
IP65 rated, ETL & cETL wet location listed
DS-PD05-_____-___
Example: DSPD05S930WT
6d”
5”
s”
2”
2 - 48"
5”
45°
Seismic swivel tilts up to 45 ° to
accomodate sloped ceiling
DS-PDX24
Operating Temperature: -40°F to 122°F (-40°C to 50°C)
