22W EXTERMINATOR II – model: 1023
LEDme® H/L/J Track Luminaire
SPECIFICATIONS
Construction: Die-cast aluminum with removable front cap for easy
change of lenses or accessories
Power Consumption: 22W
Light Source: High output COB LED
Input: 120VAC 50/60 Hz
Dimming: 100%-5% Electronic Low Voltage
Finish: Powder coated Black and White,
Anodized brushed nickel
Standards: UL&cUL Listed, Energy Star® rated
FEATURES
• Accommodates one lens accessory and one glare control accessory
• Reectors and LED modules can be purchased separately
for alternative beam angles and color temperatures
• 365° horizontal rotation and 180° vertical aiming
• 50,000 hour rated life
• 5 year WAC Lighting product warranty
PRODUCT DESCRIPTION
LEDme® Exterminator oers superior light output in a small, unobtrusive
design. Developed for upscale residential and commercial environments.
FLAT LENS ACCESSORIES
Amber
Blue
Green
Red
Yellow
UV Filter
Frosted
Spread
Beam Elongating
LENS-16-AMB
LENS-16-BLU
LENS-16-GRN
LENS-16-RED
LENS-16-YEL
LENS-16-UVF
LENS-16-FR
LENS-16-SPR
LENS-16-BEL
System Beam Color Temp CRI Lumens Ecacy CBCP Finish
H
L
J
H TRACK
L TRACK
J/J2 TRACK
1023N 18°
827
927
830
930
835
840
2700K
2700K
3000K
3000K
3500K
4000K
85
90
85
90
85
85
1755
1505
1860
1590
1975
2030
80
68
85
72
90
92
9962
8559
10560
9030
11231
11527
BN
BK
WT
Brushed Nickel
Black
White
1023F 38°
827
927
830
930
835
840
2700K
2700K
3000K
3000K
3500K
4000K
85
90
85
90
85
85
1690
1455
1790
1535
1905
1955
77
66
81
70
87
89
4049
3565
4398
3761
4677
4801
– – –
Example: H-1023N-927-BK
ORDER NUMBER
REFLECTORS
18°
38°
RF-S
RF-F
LED MODULES
2700K
2700K
3000K
3000K
3500K
4000K
CRI 85
CRI 90
CRI 85
CRI 90
CRI 85
CRI 85
BXRC-27E1000-D-73
BXRC-27G1000-D-73
BXRC-30E1000-D-73
BXRC-30G1000-D-73
BXRC-35E1000-D-73
BXRC-40E1000-D-73
GLARE CONTROL  CROSS LOUVER
LENS16PCRLWT
LENS16PCRLBK
LENS16PCRLBN
White
Black
Brushed Nickel
GLARE CONTROL  SNOOT
LENS16SNOOTWT
LENS16SNOOTBK
LENS16SNOOTBN
White
Black
Brushed Nickel
