HRLED251E
1" LEDme® Downlight
2”
3”
38”
5s”
min 15”
max 242”
FINISHES
BN GM WT
PRODUCT DESCRIPTION
Square recessed trim with interior open reector. IC-Rated housing
included with trim, can be used as new construction or remodel.
FEATURES
• 1" aperture
• Cutout: 22”
• Less than z” thick, super low prole die-cast aluminum trim
• Sold as new construction, may be re-congured in the eld for remodel
• Narrow ood beam spread
• 25° visual cut-o angle
• 80,000 hour rated life
• 5 year WAC Lighting product warranty
SPECIFICATIONS
Construction: Die-cast aluminum trim and aluminum heat sink.
Housing and junction box are 20 gauge steel painted black.
Frame and hanger bars are heavy gauge galvanized steel.
J-Box: Seven knockouts and four Romex® style wiring connectors provided for
ease of installation. Rated for branch wiring.
Driver: Electronic driver, 120VAC/60Hz input, 4W max output.
Power factor >0.9. Dimming with thermal protection.
Light Source: Includes one 3W ANSI compliant Warm/Neutral LED
for the nest color consistency possible. Replacement modules available.
Dimming: May be dimmed to 10% with electronic low voltage (ELV) dimmer.
Mounting: Supplied with hanger bars, adjustable from 15"-242"
to accommodate various joist constructions and grid sizes.
Hanger bars include a captive mounting "screw-nail" for ease of installation.
For remodel installation, three heavy gauge inner retention clips push
out onto ceiling or other mounting surface to rmly hold housing in place.
Accommodates surface up to 1" thick.
Minimum plenum height of 4" required. 22" cutout hole.
Finish: Available in White (WT) powder coat paint and electroplated
Brushed Nickel (BN) and Gun Metal (GM).
Rating: IC-Rated: Suitable for direct contact with insulation.
Standards: ETL & cETL Damp Location Listed
ORDER NUMBER
Model # Color Temp Finish
HRLED251E 27
30
35
40
2700K
3000K
3500K
4000K
BN
GM
WT
Brushed Nickel
Gun Metal
White
REPLACEMENT MODULES
Model # Color Temp
RM1X3271DL
RM1X3301DL
RM1X3351DL
RM1X3401DL
2700K
3000K
3500K
4000K
HR-LED251E – –
Example: HRLED251E-40-GM
FIXTURE PERFORMANCE
Model # Color Temp Watt Lumens CBCP Beam CRI
HRLED251E27
2700K 3.5W* 245 530 35° 85
HRLED251E30 3000K 3.5W* 250 540 35° 85
HRLED251E35 3500K 3.5W* 270 573 35° 85
HRLED251E40 4000K 3.5W* 285 608 35° 85
*Power consumption may vary depending on eciency of the system being used.
