User guide

1 ANALOG 2

INPUTS

SPEAKER OUTPUTS

BANANA

1 2 3 4 5

Power

The power switch is located on the back panel of the Wadia Intuition 01 right above

the AC inlet.

When the apparatus is switched on, a sequence of tests indicating the name Wa-

dia and after this the product name and the currently selected input appear on the

screen. After this sequence, four lit points that form a square are shown in the cen-

tre of the display, indicating that the apparatus is ready for use.

Selecting the required input

Press keys 1 or 2 to scroll left and right among the various inputs and select the one

that is required.

If, for example, the USB input is currently active, pressing key 1 activates the Toslink

optical input.

The same logic is also valid for the remote control, using the keys on its vertical axis.

Note : The input selector has a memory, therefore the apparatus re-

members the name of the last input used by the user before switching

off, and re-proposes it when the device is switched on the next time.

Adjusting the volume

The volume level is controlled by keys 4 and 5 on the front panel, or by the remote

control using the 2 keys on its horizontal axis.

The keys must be kept pressed to increase or decrease the volume until the required

level is obtained; the volume scale is divided into 100 steps that are well represent-

ed on the apparatus display and which can be read even from a distance.

Front Panel

1 Select the previous input

2 Select the next input

3 Display

4 Volume down

5 Volume up

Note: The 1,2,4,5 buttons are placed under the fabric that covers the

display and are located by 4 small white lighting spots.
