Data sheet | Item number: 231-139/001-000 THT male header; 1.0 x 1.0 mm solder pin; straight; Pin spacing 5 mm; 9-pole www.wago.com/231-139/001-000 Color: L = (Polzahl – 1) x Rastermaß + 8,2 mm Item description 10.05.
Data sheet | Item number: 231-139/001-000 www.wago.com/231-139/001-000 Item description Horizontal or vertical PCB mounting via straight or angled solder pins Pin cross-section: 1 x 1 mm With coding fingers Safety information 1: The MULTI CONNECTION SYSTEM (MCS) is designed without breaking capacity for compliance with DIN EN 61984. When used as intended, MCS Connectors shall not be connected/disconnected when live or under load.
Data sheet | Item number: 231-139/001-000 www.wago.com/231-139/001-000 Connection data No. of poles 9 Total number of potentials 9 Number of connection types 1 Number of levels 1 Geometrical Data Pin spacing 5 mm / 0.197 inch Width 48.2 mm / 1.898 inch Height 17 mm / 0.669 inch Height from the surface 12 mm / 0.472 inch Depth 8.4 mm / 0.331 inch Solder pin length 5 mm Solder pin dimensions 1 x 1 mm Drilled hole diameter (tolerance) 1.4(- … +0.
Data sheet | Item number: 231-139/001-000 www.wago.com/231-139/001-000 Environmental Requirements Limit temperature range -60 … +100 °C Commercial data Product Group 3 (Multi Conn. System) Country of origin DE GTIN 4044918863438 Approvals / Certificates Country specific Approvals Logo Approval Additional Approval Text Certificate name CB DEKRA Certification B.V. IEC 61984 NL-39756 CSA DEKRA Certification B.V. C22.2 1466354 CSA DEKRA Certification B.V. C22.
Data sheet | Item number: 231-139/001-000 www.wago.com/231-139/001-000 UR UL International Germany GmbH UL 1977 E45171 Subject to changes. WAGO Kontakttechnik GmbH & Co. KG Hansastr. 27 32423 Minden Phone: +49571 887-0 | Fax: +49571 887-169 Email: info.de@wago.com | Web: www.wago.com Do you have any questions about our products? We are always happy to take your call at {0}. 10.05.
