Data sheet | Item number:256-402
PCB terminal block; Push-button; 2.5 mm²; Pin spacing 5/5.08 mm; 2-pole;
CAGE CLAMP®; commoning option
www.wago.com/256-402
06.12.2018Page /1 7
L = (pole no. x pin spacing) + 2.9mm
Color:
Item description
PCB terminal strips with push-buttons and CAGECLAMP connection
®
Versions with Ex approval
Set to metric or inch pin spacing by compressing PCB terminal strips orpulling them apart
Ideal for in-the-field wiring thanks to simplified push-button actuation
Convenient, tool-free operation
Direct marking,Other variants can be requested via the WAGO sales department or, if necessary, configured at https://configurator.wago.com/:
Mixed-color terminal strips,Other colors,Other pole numbers,Versions for Ex e II and Ex i
Data
Electrical data
Ratings per IEC/EN 60664-1
Rated voltage (III / 3) 250 V
Rated impulse voltage (III / 3) 4 kV
Rated voltage (III / 2) 320 V
Rated impulse voltage (III / 2) 4 kV
Rated voltage (II / 2) 630 V
Rated impulse voltage (II / 2) 4 kV
